Summary of Contents for Goldline SAB301GL
- Page 2 Installation ———–——————–8 Start Using your cooktop———–—13 Maintenance and troubleshooting—-15 Servicing———————————19 Model numbers covered in this manual: SAB301GL, SAB302GL, SAB2GL, SAB3GL, SAB402GL SAB603S, SAB4GL SAB704S, SAB5GL NOTE: & , which will enable you to get the most out of your appliance.
- Page 3 This manual explains the proper installation and use of your appliance, please read it carefully before using even if you are familiar with the product. The manual should be kept in a safe place for future reference. In case of failure, only the Authorized Technical Service may repair this hob.
- Page 4 1.2m in length. • If you are required to transport the Goldline product to the company or its service agent, you must ensure it is safely disconnected by a qualified tradesman and securely packed and insured. The company does not accept any responsibility for loss or damage of the Goldline product prior to it being received by the company or its service agent.
- Page 5 Toughened glass Trivet SEMI RAPID Model number shown SAB4GL Wok — Wok Burner R — Rapid Burner SR — SemiRapid Burner Aux — Auxiliary Burner CONTROL KNOBS Layout for different models will vary. Please see SPEC table for burner details of each model. Page 4...
- Page 6 Accessory Name Picture ( for reference only, physical unit maybe different) Quantity User Manual Installation clip Screws ST4.2x18 Adhesive sealing tape Natural gas regulator Test point adapter Page 5...
- Page 7 Page 6...
- Page 8 Bench cut out and cooktop dimension by model number. See specs table on page 6 for details of bench cut out and other important information for each model. The following is a guide to your installation layout. According to Australian regulations, the minimum clearance between a gas cooktop element or burner component is: 600mm of vertical clearance to a combustible surface, and 200mm of horizontal distance to a vertical •...
- Page 9 Apply the adhesive sealing tape to the underside lip of the burner box. Shown at G opposite. Place burner box into cutout hole and fit clamping brackets to clamp the hotplate to the bench. Fit burners and trivet. Replace burners and ensure they are correctly repositioned over the ignitor (S) thermocouple (T).
- Page 10 75mm at any point in its length. After having installed hotplate, the GPO must always be in an accessible position Wiring diagram for: SAB301GL, SAB302GL, SAB402GL SAB2GL Wiring diragram for: SAB3GL...
- Page 11 4. Gas connection Install in accordance with relevant gas standards and/or codes of practice applicable. Connect the elbow fitting to the appliance gas manifold connection, and check that seals between the elbow and manifold connection are in place and in good condition.
- Page 12 After connecting to gas, check for leaks using soapy solution, never a naked flame. Fit the duplicate data plate (supplied in separate bag) on a surface adjacent to the hotplate, for example, the inside of the cupboard door so it is clearly visible for any service technician.
- Page 13 The hotplates are fitted with mains powered electronic spark ignitors, so must be connected to mains power supply (i.e. nominal 220 -240V AC) to operate. If power is not available, the hotplate will still work but the burners will have to be lit with a match.
- Page 14 For the best efficiency and to ensure pan handle does not over heat, place the pan centrally on the burner and adjust the flame height so all the flame remains under the pan. NOTE: Enclosure may be circular or square Page 13...
- Page 15 Cleaning and maintenance should be carried out with the appliance cold, especially when cleaning the enamel parts. Avoid using alkaline or acid substances (lemon juice, vinegar etc.) on the surface. GLASS PANEL The glass must be cleaned regularly (e.g. weekly) to ensure long life expectancy of the hot plate. Ensure the hot plate has cooled.
- Page 16 Before Installation: Before cutting into any bench tops, ensure the minimum clearances to walls, adjacent surfaces and overhead surfaces required by the relevant gas appliance installation code (see above) will comply. Dimensions are specified in millimeters (mm) Overhead cupboards and range hood = 600 mm. Side and rear clearance = 200 mm to any burner edge for any combustible surface. TO BE INSTALLED ONLY BY AN AUTHORIZED PERSON Electrical connection.
- Page 17 • GAS CONVERSION (LPG TO NG) If the required gas conversion kit is not supplied with your appliance, you can order one from GOLDLINE. Gas conversion shall only be carried out by an authorized service technician. The conversion kit contains: NG regulator •...
-
Page 18: Troubleshooting
TROUBLESHOOTING Servicing of the hotplate must only be done by an authorized service representative (see back of this booklet) and the hotplate must not be modified. Power must be disconnected before any servicing or maintenance is con- ducted. Abnormal conditions include: Excessively yellow or sooting flame type. -
Page 19: Servicing Instructions
SERVICING INSTRUCTIONS WARNING! DANGER 240 VOLTS 50Hz DISCONNET POWER BEFORE SERVICING UNIT DO NOT MODIFY THIS APPLIANCE MINOR ADJUSTMENT Access to By-Pass Screw Light the burner and turn to minimum setting (marked small flame). • • The flame should be on minimum setting and should not extinguish when passing from maximum setting to low setting. - Page 20 Commonwealth of Australia and excludes any services resulting from accident damage, alterations, misuse, fire, flood or acts of God. The Goldline appliance(s) must be installed by an authorised person, or this warranty will be null and void. Installation must be carried out in accordance with the installation instructions.
