Murata XBSC Series Assembly page 4

XBSC/UBDC/UBSC/BBSC/ULSC 100 µm & 400 µm -
Assembly by soldering
Capacitor size
Silicon Capacitor
Type
0201M
0201
0402M
0402
0603
Assembly Note – Ref : ASNUBSC1.6
FBC-0003-01
Figure 1.7: design of the substrate
Die pad
(µm)
600 x 600 150 x 100
800 x 600 400 x 150
1000 x 500 Diam 90
1200 x 700 500 x 300
1800 x 1100 900 x 400
size
(µm) Max (a)
300
600
200
700
1100
Rev 1.2
Metal track width
(µm)
Min (b) Optimum (c)
150 225
400 500
100 150
500 600
900 1000
Rev. 1.6
4
