A.1
M-011.1-MGAS-ENG
Documento:
12/2001
Edizione:
Rev.:
MINIGAS
Control Panel
Installation and Programming Manual
NOTIFIER ITALIA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MINIGAS and is the answer not in the manual?

Questions and answers

Related Manuals for Notifier MINIGAS

Summary of Contents for Notifier MINIGAS

  • Page 1 M-011.1-MGAS-ENG Documento: 12/2001 Edizione: Rev.: MINIGAS Control Panel Installation and Programming Manual NOTIFIER ITALIA...

  • Page 2: Table Of Contents

    14 – MAIN POWER SUPPLY – Current draw calculation ..…………………………………………….. 14.1 Current draw calculation in stand-by condition ………………………………………………. 14.2 Current draw calculation in pre-alarm and alarm condition …………………………………. INDICE Installation and Programming Manual MINIGAS 2001 NOTIFIER ITALIA Doc. M-661.1-GL91B-ENG Rev. A.1 2_Minigas2001-user-eng...

  • Page 3: General Description

    1 – GENERAL DESCRIPTION MINIGAS is a microprocessor fire alarm control panel with 2 detection zones. Each zone (or Line) can hold up to 3 gas detectors. The control panel's cabinet is provided for wall mounting. The control panel houses a 24 Vdc regulated power supply to drive the control panel, all connected detectors, and re-charge the stand-by battery.

  • Page 4: Inside

    Zone in SHORT-CIRCUIT. • Zone with WIRE CUT. 3 – KEYBOARD DESCRIPTION 3.1 Password access level 2 Password keys Password code := 1 2 3 4 Pag. 2 Installation and Programming Manual MINIGAS 2001 NOTIFIER ITALIA Doc. M-011.1-MGAS-ENG Rev. A.1 2_Minigas2001-user-eng...

  • Page 5: Control Panel's Operational Description

    Press 1 time the relative key to mask the line. The unmask status is indicated from relative led. With masked threshold, led is off; with unmasked threshold, led is on. NOTE : A line is mask when both levels are mask. MINIGAS 2001 Installation and Programming Manual Pag. 3 2_Minigas2001-user-eng Doc.
  • Page 6 To reset detector lines (in case of trouble or alarm) press the reset key after pressing the acknoledge key (ACK). NOTE: Please refer to control panel's flow-charts. Pag. 4 Installation and Programming Manual MINIGAS 2001 NOTIFIER ITALIA Doc. M-011.1-MGAS-ENG Rev. A.1 2_Minigas2001-user-eng...

  • Page 7: Front Panel Indications

    LAMP-TEST Without not silenced alarms and troubles, if you press LAMP-TEST key, all led are on for 5 seconds. 4 – FRONT PANEL INDICATIONS MINIGAS 2001 Installation and Programming Manual Pag. 5 2_Minigas2001-user-eng Doc. M-011.1-MGAS-ENG Rev. A.1...
  • Page 8 N.B. : When for one line the 2 thresholds (pre-alarm and alarm) are cut out, the line is totally excluded; cut line and short circuit troubles are not detected. Pag. 6 Installation and Programming Manual MINIGAS 2001 NOTIFIER ITALIA Doc. M-011.1-MGAS-ENG Rev. A.1 2_Minigas2001-user-eng...

  • Page 9: Access Level

    Reset delay : every 60 s • BATTERY FAULTY Indication : Power supply trouble Activation delay : every 60 s Reset delay : every 60 s MINIGAS 2001 Installation and Programming Manual Pag. 7 2_Minigas2001-user-eng Doc. M-011.1-MGAS-ENG Rev. A.1 NOTIFIER ITALIA...

  • Page 10: Prealarm And Alarm Management

    Alarm and prealarm leds of zone blink or remain ON according to the condition on the line. (if it is active or not) Pag. 8 Installation and Programming Manual MINIGAS 2001 NOTIFIER ITALIA Doc. M-011.1-MGAS-ENG Rev. A.1 2_Minigas2001-user-eng...

  • Page 11: General Pre-Alarm And Alarm

    With the reset key it is possible to reset the luminous indications relative to setted troubles already active are again reproposed. MINIGAS 2001 Installation and Programming Manual Pag. 9 2_Minigas2001-user-eng Doc.

  • Page 12: Electric Features

    Max 24 V/3 A resistive, 1 free contact. General Trouble Max 24 V/1 A resistive, 1 free contact (norm. energ.) Pre-alarm Max 24 V/1 A resistive, 1 free contact. Pag. 10 Installation and Programming Manual MINIGAS 2001 NOTIFIER ITALIA Doc. M-011.1-MGAS-ENG Rev. A.1 3_Minigas2001-install-eng...

  • Page 13: Installation

    Wires connecting detectors, auxiliary devices and power supply may be passed on through the lateral holes running them along the cabinet internal side providing sufficient length especially for those connected to the CNA terminal block. MINIGAS 2001 Installation and Programming Manual Pag. 11 3_Minigas2001-install-eng Doc.

  • Page 14: Power Supply And Battery Connection

    3 x 1,5 mm² ATTENTION: Unused lines must always terminate with a 2,2KΩ, 5%, 1/4 W resistance on the panel terminal block to prevent a line cut signal. Pag. 12 Installation and Programming Manual MINIGAS 2001 NOTIFIER ITALIA Doc. M-011.1-MGAS-ENG Rev. A.1 3_Minigas2001-install-eng...

  • Page 15: Auxiliary Alarm Devices

    • GENERAL TROUBLE OUTPUT: n. 1 potential-free contact with N.A. or N.C. output selectable by jumper (JGST refer to base board). All these contacts are potential-free, isolated from internal circuitry contacts. MINIGAS 2001 Installation and Programming Manual Pag. 13 3_Minigas2001-install-eng Doc.

  • Page 16: Front Panel Layout

    10.5 Frontal board topographical Pag. 14 Installation and Programming Manual MINIGAS 2001 NOTIFIER ITALIA Doc. M-011.1-MGAS-ENG Rev. A.1 3_Minigas2001-install-eng...

  • Page 17: Base Board Layout

    10.6 Base board topographical MINIGAS 2001 Installation and Programming Manual Pag. 15 3_Minigas2001-install-eng Doc. M-011.1-MGAS-ENG Rev. A.1 NOTIFIER ITALIA...

  • Page 18: Gas Detection Lines Operation

    JGST jumper RL Gen. Trouble COMMON RL Pre-alarm NO-NC selectable by JPRALL jumper RL Pre-alarm COMMON RL Alarm NO-NC selectable by JALL jumper RL Alarm COMMON Pag. 16 Installation and Programming Manual MINIGAS 2001 NOTIFIER ITALIA Doc. M-011.1-MGAS-ENG Rev. A.1 3_Minigas2001-install-eng...

  • Page 19: Connector Cna Base Board"N2Ba

    NORMAL TRACKING mode In NORMAL mode the OPEN COLLECTOR output and the relative led zone memorize the events; in TRACKING they follow the events recording in real time. MINIGAS 2001 Installation and Programming Manual Pag. 17 3_Minigas2001-install-eng Doc. M-011.1-MGAS-ENG Rev. A.1...

  • Page 20: Main Power Supply - Current Draw Calculation

    ( ______ ) 0,010 EMA1224BR sounders ( ______ ) 0,018 Other devices powered ( ______ ) ( ______ ) from Minigas panel: ( ______ ) ( ______ ) bells, sounders …. TOTAL Total B Pag. 18 Installation and Programming Manual...
  • Page 21 ( ______ ) Total current necessary Total C Total secondary ampere hours calculated multiply by the derating factor (1,2) Total C x 1,2 = ( ______ ) MINIGAS 2001 Installation and Programming Manual Pag. 19 3_Minigas2001-install-eng Doc. M-011.1-MGAS-ENG Rev. A.1 NOTIFIER ITALIA...
  • Page 22 M-011.1-MGAS-ENG Documento: 12/2001 Edizione: Rev.: All rights reserved. All specifications are subject to change without notice. Delivery times depend on product availability. NOTIFIER ITALIA S.r.l. Via Grandi, 22 - 20097 San Donato Milanese (MI) Tel.: 02/51897.1 (ISDN) Fax: 02/5189730 http://www.notifier.it...
