Innovative Marine AUQA Gadget BioSkim DC User Manual

Advertisement

Quick Links

WARNING
WARNING
READ ALL SAFETY INSTRUCTIONS BEFORE USE.
To avoid electric shock, special care should be taken since water is employed in the
use of aquarium equipment. For each of the following situations, do not attempt to
repair yourself. Return the appliance to an authorized service facility for service or
discard the appliance.
If the appliance falls into water, DO NOT reach for it! First unplug it and then retrieve
it. If the electrical component of the appliance gets wet, unplug the appliance
immediately.
Carefully examine the appliance after installation. It should not be plugged in if
there is water on parts not intended to be wet.
Do not operate any appliance if it has a damaged cord or plug, or if it is
malfunctioning or if it is dropped or damaged in any manner.
To avoid the possibility of the appliance plug or receptacle getting wet, position
aquarium to one side of a wall mounted receptacle to prevent water from dripping
onto the receptacle plug. A "Drip Loop" should be arranged by the user for EACH
cord connecting an aquarium appliance to a receptacle. The "Drip Loop" is that part
of the cord below the level of the receptacle or the connector if an extension cord is
used. This "Drip Loop" prevents water travelling along the cord and coming in
contact with the receptacle. If the plug or the receptacle does get wet DO NOT
unplug the cord. Disconnect the fuse to the circuit breaker that supplies power to
the appliance. Then unplug and examine for the presence of water in the receptacle.
Close supervision is necessary when any appliance is used by or near children.
To avoid injury, do not contact moving parts or hot parts such as heaters, re ectors,
lamps bulbs and etc.
Always unplug an appliance from the outlet when not in use, before putting on or
taking o parts, and before cleaning. Never yank the cord to pull plug from outlet.
Grasp the plug and pull to disconnect.
Do not use an appliance for other than intended use. The use of attachments not
recommended or sold by the appliance manufacturer may case an unsafe condition.
Do not install or store the appliance where it will be exposed to the weather or to
temperatures below freezing.
Make sure an appliance is securely installed before operating it.

Advertisement

loading
Need help?

Need help?

Do you have a question about the AUQA Gadget BioSkim DC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Innovative Marine AUQA Gadget BioSkim DC

  • Page 1 WARNING WARNING READ ALL SAFETY INSTRUCTIONS BEFORE USE. To avoid electric shock, special care should be taken since water is employed in the use of aquarium equipment. For each of the following situations, do not attempt to repair yourself. Return the appliance to an authorized service facility for service or discard the appliance.
  • Page 2: How To Assemble

    WARNING HOW TO ASSEMBLE Read and observe all the important notices on the appliance. This appliance has a polarized plug (one blade is wider than the other). As a safety feature, this plug will t in a polarized outlet only one way. If the plug does not t fully in the outlet, reverse the plug.
  • Page 3: Parts List

    BioSkim DC - 7209 PARTS LIST BioSkim Lid 720601 BioSkim Black Oring 720602 BioSkim Collection Cup 720603 BioSkim Body 720906 BioSkim DC Pump 720607 BioSkim Volute 720909 BioSkim Venturi Tube 720804 BioSkim Wing Nut 720812 BioSkim Adj. Hanger 720811 BioSkim Venturi Elbow 720813 BioSkim Silencer Tube 720604...
  • Page 4 HOW TO USE / INSTALL There are two way to place your External Silencer. Find the appropriate column in which the BioSkim DC will t. The column must have a water line that is constant for Figure A - Attach the Venturi Tube to the venturi port the BioSkim DC to work properly.
  • Page 5 HOW TO USE / INSTALL Use the Adjustable Hanger to rest on a ba e wall. Hang the EXTERNAL SILENCER over the rear of your aquarium and plug in your skimmer.
  • Page 6: How To Disassemble

    HOW TO DISASSEMBLE You can adjust the height of your COLLECTION CUP to Unplug the BioSkim DC from electrical outlet before your desired height level by moving the COLLECTION performing any maintenance. CUP up and down and setting it with the BLACK O-RING. Remove skimmer out from designated skimmer column.
  • Page 7 www.innovative-marine.com...
