ONU1910-1GF-W USER MANUAL
ONU1910-1GF- W Us er Manual
Copyright © 2009-2022 FS.COM All Rights Reserved.

Advertisement

loading
Need help?

Need help?

Do you have a question about the ONU1910-1GF-W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for FS ONU1910-1GF-W

Summary of Contents for FS ONU1910-1GF-W

  • Page 1 ONU1910-1GF-W USER MANUAL ONU1910-1GF- W Us er Manual Copyright © 2009-2022 FS.COM All Rights Reserved.
  • Page 2 ONU1910-1GF-W USER MANUAL Contents 1 FS ONU1910-1GF-W User Manual ..................... 1.1 Introduction ................................. .11.2 Hardware Connection ..............................11.3 Computer Setting ............................... . 21.4 Wizard Setting ................................41.5 System Wireless Setting .............................. 51.6 User Tips ..................................7...

  • Page 3: Hardware Connection

    1 FS ONU1910-1GF-W User Manual 1.1 Introduction FS ONU1910-1GF-W is a high-end integrated broadband access device that is flexible and user-friendly, conforming to the IEEE802.11b/g/n standard. It can provide high-performance broadband access services for home users and individual businesses. Its main characteristics: ...

  • Page 4: Computer Setting

    ONU1910-1GF-WUSER MANUAL Flicker: The optical power received by the ONU is lower than the threshold of the optical receiver Off: The system is not powered on or the wireless interface does not connect to any network device; WIFI Wireless status indicator Green On: The wireless interface has been connected, but there is no data transmission.
  • Page 5 ONU1910-1GF-WUSER MANUAL Double click “Internet Protocol 4 (TCP/IPv4)” as shown in the following figure: On the page of Internet Protocol 4 (TCP/IPv4) Properties, select “Obtain an IP address automatically” and “Obtain DNS server address automatically”, and then click “OK”.

  • Page 6: Wizard Setting

    ONU1910-1GF-WUSER MANUAL 1.4 Wizard Setting Open the web browser. Enter 10.0.0.10 in the address bar and click “Enter” to the the web interface. Then enter the UserName (admin by default) and Password (super&123 by default) respectively in the interface UserLogin After Login, click “Status”...
  • Page 7 ONU1910-1GF-WUSER MANUAL On page of WLAN Basic Settings, you can tick or not tick Disable WLAN Interface to disable WiFi. And you can also modify the wireless name, authentication mode and password Click "Apply Changes" to proceed to the next step 1.5 System Wireless Setting If you want to use the wireless network, please make sure your PC is equipped with the wireless adapter card, then do as following steps.
  • Page 8 ONU1910-1GF-WUSER MANUAL Click “Wireless Network Connection” Click the “Refresh” button, select the wireless network name of the terminal device, and double-click the name...
  • Page 9 ONU1910-1GF-WUSER MANUAL Enter the password and click "OK". Reset Please reset your router if you forget its username and password. Reset method: Keep your router powered on and press the reset key “RESET” with a toothpick or a clip for 10 seconds and the router will reboot. Caution: The configuration parameters of the router will return to the default setting after reset.
  • Page 10 ONU1910-1GF-WUSER MANUAL select “service” after the page is unfolded. Find “WLAN AutoConfig” and ensure it is enabled; check whether there is wireless signal if keep the laptop closer to the wireless router. retry to connect other wireless adapter card if the above solutions are unsatisfactory. If not, reset the wireless route...
