- Page 1 FT6380-50 Instruction Manual Manual de Instrucciones CLAMP ON EARTH TESTER MEDIDOR DE RESISTENCIA DE TIERRA TIPO PINZA EN/ES July 2021 Revised edition 1 FT6380B983-01 (B981-02) 21-07H HIOKI FT6380B983-01...
- Page 2 HIOKI FT6380B983-01...
-
Page 3: Table Of Contents
Data hold function (Holding the measured value) ..37 Backlight function (Making measurements in a dark location) ....37 Filter function (Rejecting noise) ......... 38 Alarm function (Judging measured values and sounding an alarm) .. 39 HIOKI FT6380B983-01 FT6380B983-01... - Page 4 General Specifications ........57 Input, Output, and Measurement Specifications 58 Function specifications ........64 Chapter 4 Maintenance and Service Cleaning ............65 Troubleshooting ..........66 Inspection and Repair ..........66 Before returning for repair .......... 66 Errors and Operating Status ......67 HIOKI FT6380B983-01...
-
Page 5: Introduction
Introduction Introduction Thank you for purchasing the Hioki FT6380-50 Clamp on Earth Tester. To obtain maximum performance from the instrument, please read this manual first, and keep it handy for future refer- ence. Trademarks • Microsoft Excel is a registered trademark or trademark of Microsoft Corporation in the United States and other coun- tries. -
Page 6: Verifying Package Contents
In particular, check the accessories, panel switches, and connectors. If damage is evident, or if it fails to operate according to the specifications, contact your authorized Hioki distributor or reseller. Confirm that these contents are provided. □... -
Page 7: Option (Sold Separately)
Option (sold separately) Option (sold separately) The option listed below is available for the instrument. To order an option, please contact your authorized Hioki distributor or reseller. Options are subject to change. Check Hioki’s website for the latest information. □... -
Page 8: Safety Information
Indicates that using the instrument in an external magnetic field of exceeding 30 A/m is prohibited. Indicates that the instrument may be connected to or disconnected from a live circuit. Indicates whether the power is on or off. HIOKI FT6380B983-01... - Page 9 Equipment Directive (WEEE Directive) in EU member states. Indicates that the instrument complies with stan- dards imposed by EU directives. Other Symbols Indicates a prohibited action. Indicates the location of reference information. (p. #) Information displayed on the screen is enclosed in brackets. HIOKI FT6380B983-01...
- Page 10 This screen is displayed when the clamp sensor is not completely closed during use of the resistance measurement function. Symbols for Various Standards Hioki expresses accuracy as error limit values specified in terms of percentages of reading. Refers to the displayed value of the measur- Reading ing instrument.
- Page 11 Use of a measurement instrument that is not CAT-rated in CAT II to CAT IV measurement applications could result in a severe accident, and must be carefully avoided. HIOKI FT6380B983-01...
-
Page 12: Operating Precautions
Before using the instrument for the first time, verify that it oper- ates normally to ensure that no damage occurred during storage or shipping. If you find any damage, contact your authorized Hioki distributor or reseller. Instrument Installation Operating temperature: -10°C to 50°C (14°F to 122°F) (Be sure to use batteries that are suited for use under the envi- ronmental conditions in which you are using the instrument.) - Page 13 To avoid electric shock when measuring live lines, wear appropriate protective gear, such as insulated rubber gloves, boots and a safety helmet. HIOKI FT6380B983-01...
- Page 14 To prevent possible damage, avoid using in dusty or wet environments. • Do not slant the instrument or place it on top of an uneven sur- face. Dropping or knocking down the instrument can cause injury or damage to the instrument. HIOKI FT6380B983-01...
- Page 15 1.0 mm in diameter. The equipment inside the enclo- sure is protected against entry by solid foreign objects larger than 1.0 mm in diameter. 0: The equipment inside the enclosure is not protected against the harmful effects of water. HIOKI FT6380B983-01...
- Page 16 Operating Precautions HIOKI FT6380B983-01...
-
Page 17: Chapter 1 Overview
Overview Chapter 1 1.1 Product Overview The FT6380-50 Clamp on Earth Tester makes grounding resis- tance measurements simply by being clamped to multiple- grounded ground wires. No auxiliary grounding rod is needed, and there is no need to disconnect the ground wire from the grounding rod. -
Page 18: Features
The instrument uses a white LED for excellent visibility so that dis- play values can be read clearly, even in dark locations. Auto-power-save (APS) function (p.54) An auto-power-save function keeps batteries from running down when you forget to turn off the instrument. HIOKI FT6380B983-01... -
Page 19: Filter Function (Rejecting Noise)
Internal memory (p.42) The instrument’s internal memory can record up to 2,000 measured values. Automatic measurement report function using your mobile communication device (p.46) The wireless communication function enables your mobile commu- nication device to create measurement reports on-site easily. HIOKI FT6380B983-01... -
Page 20: Names And Functions Of Parts
• Holds the measured value display or cancels hold mode. • To cancel auto-power-save mode, press the power key while holding down the HOLD key. Backlight key • Turns the backlight on and off. A/Ω key • Switches between resistance measurement mode and current measurement mode. HIOKI FT6380B983-01...
