  • Page 1 MINIATURE TWO-POINT PROBE ADAPTER PRF-922A-B User Manual...

  • Page 3: Table Of Contents

    General Specifi ca ons Copyright © 2012 by Prostat® Corpora on. All rights reserved. Printed in the United States of America. No part of this manual may be used or reproduced in any manner whatsoever without wri en permission. For informa on contact Prostat Corpora on, 1072 Tower Lane, Bensenville, IL 60106 USA Prostat is the registered trademark of Prostat®...

  • Page 4: Introduc On & Descrip On

    4. Overall size of the PRF-922A-B Adapter is 0.50 inches in diameter by 2.7 inches long. This op - mal size and shape make the fi xture very comfortable and easy to handle. Its outer housing is made of black anodized aluminum.
  • Page 5 Never, under any condi ons, exceed 500 volts during fi xture test or repair. B. Other Opera onal Precau ons 1. Do Not Use the PRF-922A-B Micro Probe Adapter if it fails to func on during its con nuity inspec on test.

  • Page 6: Prf-922A-B Miniature Two-Point Adapter Moun Ng Opera On

    7. Do not a empt to measure energized materials or circuits with the PRF-922A-B 8. Do not use the PRF-922A-B with any host fi xture other than a PRF-912B, or PRF-914B. The host fi xture must meet all performance and safety elements outlined herein.
  • Page 7 PRF-922A-B Miniature Two-Point Probe Adapter 2. Loosen PRF-922A-B Adapter locking screw. Loosen them by turning clock-wise (Do not remove screws all the way). 3. Slip PRF-922A-B onto host fi xture un l contact is made with host concentric ring 4. Hold host and adapter assembly ver cally and in con- tact with hard table surface, press to compress both host fi...
  • Page 8 1. To confi rm general setup and func on of the PRF-922A-B and host assembly, place the elec- trodes against a clean metal surface. For example, the plated metal side of the PTB-920, Dual Surface Test Bed.
  • Page 9 1. Place material to be measured on an insulated test bed, the clean insulated surface (Black, labeled side) of the PTB-920, or an insulated acrylic plate. 2. Posi on the PRF-922A-B ver cally directly over test area and lower it un l the spring-loaded electrodes makes direct contact with the material under test.

  • Page 10: Handling & Maintenance

    Figure 7: Measuring Jedec Tray IV. Handling & Maintenance A. PRF-922A-B Miniature 2-Point Adapter Fixture 1. Store the PRF-922A-B in a clean, dry environment with probe cover Pull spin straight out installed for environmental and mechanical protec on. 2. Periodically, remove the spring-loaded test pins. Clean the spring-...
  • Page 11 PRF-922A-B Miniature Two-Point Probe Adapter c. Clean and dry the pin socket moun ng disk twice to insure cleanliness and minimum leak- age (maximum resistance) between pin sockets d. Carefully re-install the spring-loaded test probes, and fully re-seat them in their sockets...

  • Page 12: Warranty Informa On

    V. Warranty Informa on Prostat Warranty Prostat Corpora on expressly warrants that for a period of one (1) year from the date of pur chase, that Prostat instruments will be free from defects in material (parts) and workmanship (labor). If Prostat receives no ce of such defect during the warranty period, Prostat will replace at its expense such parts that it determines to be defec ve.

  • Page 13: General Specifi Ca Ons

    PRF-922A-B Miniature Two-Point Probe Adapter PRF-922A-B Miniature Two-Point Adapter & PRV-913B Verifi er Specifi ca ons PRF-922A-B Miniature Two-Point Micro Probe Adapter Physical Dimensions: Length: 1.9 inches (48mm) without probe cover. 2.7 inches (68mm) with probe cover. Probe diameter 0.5 inches (12.7mm). Probe cover outer diameter 0.63 inches (16mm).
  • Page 14 PRF-922A-B Two-Point Probe Adapter NOTES Rev. A / September 2007...
  • Page 16 Specifi ca ons are subject to change without no ce. All Prostat trademarks and trade names are the property of Prostat Corpora on. All other trademarks and trade names are the property of their respec ve companies. P R O F E S S I O N A L...
