Configuration

Configuration

Overview

Rolec charge points have been tested for use with our preferred partner Monta but can
be managed by any charging application that properly complies with the Open
Chargepoint Protocol (OCPP) 1.6J.
If the Monta service is NOT going to be used, several other service providers are available
within the configuration application. Whilst these providers have been tested and work
with the charge point, you may need assistance from the chosen provider to establish a
working connection to their network.
NOTE: Compliance with OCPP 1.6J does not guarantee compatibility 'straight out of the
box'. There are many variables within the specification that can influence the features
that are available.
There is also the option to use service providers that are not listed. Again, you may require
assistance from the service provider to complete the configuration and Rolec cannot
guarantee that all features will be available.
IMPORTANT: Charge point management/operation applications such as that provided
by Monta, or any other service provider, are NOT part of the Rolec product and any
agreements, contracts or fees related to their services will be between you and your
chosen provider.

Required Items

To connect to the charge point using the EV Connect and Monta applications you will
need the following items:
1. A smart phone with a camera, QR code reader software, and Bluetooth and
internet connectivity.
2. Monta Application – available from the Apple or Google App stores (as
appropriate to your type of phone).
3. Monta QR Code label(s) - Most charge points will be supplied with a Monta QR
code label(s) already attached. If this is not the case, the label supplied with the
charge point should be attached close to the socket to which it applies.
4. Rolec Charge point ID label – This is a removable label attached to a red and
black 'tag' that is supplied with the charge point and usually hung on one of the
sockets or attached to the enclosure.
Following Installer installation and configuration of the charge point, the
removeable label may have been attached to the front of this Manual or to
the installation test report, or to the property's fuse box/consumer unit.
There is an identical label attached to the communications board inside the
charge point enclosure.
