Sharp QT-CD131H Service Manual page 29

NO. PART CODE
C207~210 RC-GZA475AF1H
C211 RC-GZA227AF1A
C212 RC-GZA106AF1C
C215,216 VCQYKA1HM683K J
C217,218 VCQYKA1HM122K J
C217,218 VCQYKA1HM222K J
C219,220 RC-GZA105AF1H
C221,222 VCKYPA1HB102K
C223,224 RC-GZA476AF1C
C225 RC-GZA227AF1E
C226 VCKYPA1HF223Z
C227 RC-GZW478AF1E
C228 RC-GZA105AF1H
C229,230 RC-GZA107AF1A
C231,232 VCQYKA1HM104K J
C233,234 RC-GZV108AF1A
C250 VCKYPA1HF223Z
C301,302 VCKYPA1HF223Z
C351 VCQYKA1HM222K J
C352 RC-GZA227AF1A
C353 VCQYKA1HM223K J
C354 VCQYKA1HM562K J
C501 RC-GZA106AF1C
C502 VCKYPA1HF223Z
C503 RC-GZA107AF1A
C504 VCKYPA1HF223Z
C505 RC-GZA225AF1H
C506~508 VCKYPA1HF223Z
C509,510 VCKYPA1HF103Z
C511 RC-GZA104AF1H
C512 VCKYPA1CU473M J
C513 VCKYPA1HF103Z
C530 VCKYPA1HF223Z
C651~654 VCKYPA1HF223Z
C701,702 VCKYPA1HF223Z
C704 RC-GZA107AF1A
C705 VCKYPA1HF223Z
C740 VCKYPA1HF103Z
C741 RC-GZA335AF1H
C801 VCKYPA1HF103Z
C802 RC-GZA476AF1C
C803 RC-GZA104AF1H
C804 VCKYPA1HB102K
C805,806 VCTYPA1CU333M J
C807 RC-GZA104AF1H
C808 VCTYPA1CU683M J
C809 VCTYPA1CU473M J
C810 VCKYPA1HB181K
C811 VCTYPA1CU104M J
C812 VCKYPA1HB331K
C813 VCTYPA1CU104M J
C814 VCTYPA1CU103M J
C815 VCKYPA1HB472K
C816 VCKYPA1HB102K
C817 RC-GZA474AF1H
C818 RC-GZA105AF1H
C819 RC-GZA476AF1C
C820 VCKYPA1HB332K
C821 RC-GZA105AF1H
C822 VCKYPA1HB221K
C830 VCCCPA1HH2R0C J
C831 VCKYPA1HB272K
C832 VCCCPA1HH270J
C833 VCKYPA1HB102K
C834 VCTYPA1CU333M J
C835 RC-GZA104AF1H
C837 RC-GZA106AF1C
C838 VCTYPA1CU103M J
C839 RC-GZA105AF1H
C840 RC-GZA334AF1H
C841,842 VCTYPA1CU473M J
C843 RC-GZA107AF1A
C844 RC-GZA337AF1A
C845 RC-GZA475AF1H
C846 RC-GZA337AF1A
C847 VCTYPA1CU103M J
C848 RC-GZA105AF1H
C849 VCKYPA1HF223Z
C850 VCTYPA1CU104M J
PRICE
DESCRIPTION
RANK
AB 4.7 µF,50V,Electrolytic
J
[132H Only]
AB 220 µF,10V,Electrolytic
J
[132H Only]
AB 10 µF,16V,Electrolytic
J
[132H Only]
AB 0.068 µF,50V,Mylar
AA 0.0012 µF,50V,Mylar [132H]
AA 0.0022 µF,50V,Mylar [131H]
AB 1 µF,50V,Electrolytic
J
AA 0.001 µF,50V
J
AB 47 µF,16V,Electrolytic
J
AB 220 µF,25V,Electrolytic
J
AB 0.022 µF,50V
J
AG 4700 µF,25V,Electrolytic
J
AB 1 µF,50V,Electrolytic
J
AB 100 µF,10V,Electrolytic
J
AB 0.1 µF,50V,Mylar
AD 1000 µF,10V,Electrolytic
J
AB 0.022 µF,50V
J
AB 0.022 µF,50V
J
AA 0.0022 µF,50V,Mylar
AB 220 µF,10V,Electrolytic
J
AB 0.022 µF,50V,Mylar
AA 0.0056 µF,50V,Mylar
AB 10 µF,16V,Electrolytic
J
AB 0.022 µF,50V
J
AB 100 µF,10V,Electrolytic
J
AB 0.022 µF,50V
J
AB 2.2 µF,50V,Electrolytic
J
AB 0.022 µF,50V
J
AB 0.01 µF,16V
J
AB 0.1 µF,50V,Electrolytic
J
0.047 µF,16V
AB 0.01 µF,16V
J
AB 0.022 µF,50V
J
AB 0.022 µF,50V
J
AB 0.022 µF,50V
J
AB 100 µF,10V,Electrolytic
J
AB 0.022 µF,50V
J
AB 0.01 µF,16V
J
AB 3.3 µF,50V,Electrolytic
J
AB 0.01 µF,16V
J
AB 47 µF,16V,Electrolytic
J
AB 0.1 µF,50V,Electrolytic
J
AA 0.001 µF,50V
J
AB 0.033 µF,16V
AB 0.1 µF,50V,Electrolytic
J
AB 0.068 µF,16V
AB 0.047 µF,16V
J AA 180 pF,50V
AB 0.1 µF,16V
J AA 330 pF,50V
AB 0.1 µF,16V
AE 0.01 µF,16V
AB 0.0047 µF,50V
J
AA 0.001 µF,50V
J
AA 0.47 µF,50V,Electrolytic
J
AB 1 µF,50V,Electrolytic
J
AB 47 µF,16V,Electrolytic
J
AA 0.0033 µF,50V
J
AB 1 µF,50V,Electrolytic
J
J AA 220 pF,50V
AA 2 pF (CH),50V
AA 0.0027 µF,50V
J
J AA 27 pF (CH),50V
AA 0.001 µF,50V
J
AB 0.033 µF,16V
AB 0.1 µF,50V,Electrolytic
J
AB 10 µF,16V,Electrolytic
J
AE 0.01 µF,16V
AB 1 µF,50V,Electrolytic
J
AA 0.33 µF,50V,Electrolytic
J
AB 0.047 µF,16V
AB 100 µF,10V,Electrolytic
J
AB 330 µF,10V,Electrolytic
J
AB 4.7 µF,50V,Electrolytic
J
AB 330 µF,10V,Electrolytic
J
AE 0.01 µF,16V
AB 1 µF,50V,Electrolytic
J
AB 0.022 µF,50V
J
AB 0.1 µF,16V
NO. PARTS CODE
C851 VCKYPA1HF223Z
C867,868 RC-GZA225AF1H
C869,870 VCKYPA1HB222K
C873 VCKYPA1HF103Z
C887 VCKYPA1HF223Z
C889 RC-GZA106AF1C
C890 RC-GZA107AF1A
RESISTORS
J6 VRD-ST2EE820J
R1 VRD-ST2EE220J
R2 VRD-ST2CD104J
R3 VRD-ST2CD333J
R4 VRD-ST2CD100J
R5 VRD-ST2CD103J
R6 VRD-ST2EE681J
R7 VRD-ST2CD472J
R8 VRD-ST2CD473J
R9 VRD-ST2CD104J
R10 VRD-ST2CD683J
R11 VRD-ST2CD563J
R12 VRD-ST2CD472J
R13 VRD-ST2EE391J
R14 VRD-ST2CD103J
R15 VRD-ST2CD122J
R16 VRD-ST2CD222J
R17 VRD-ST2CD103J
R18 VRD-ST2CD473J
R19 VRD-ST2CD103J
R20 VRD-ST2CD682J
R21 VRD-ST2CD562J
R22,23 VRD-ST2CD473J
R24 VRD-ST2CD392J
R25 VRD-ST2CD333J
R26 VRD-ST2CD152J
R27 VRD-ST2CD473J
R28 VRD-ST2CD103J
R29 VRD-ST2CD122J
R30 VRD-ST2CD153J
R31 VRD-ST2CD102J
R32 VRD-ST2CD333J
R33,34 VRD-ST2CD472J
R35,36 VRD-ST2CD103J
R37,38 VRD-ST2CD332J
R39 VRD-ST2CD103J
R40 VRD-ST2CD473J
R41 VRD-ST2CD223J
R42 VRD-ST2CD472J
R43 VRD-ST2CD473J
R44 VRD-ST2EE271J
R45 VRD-ST2EE221J
R46~48 VRD-ST2CD563J
R49 VRD-ST2CD272J
R50~52 VRD-ST2CD102J
R55 VRD-ST2CD103J
R56 VRD-ST2CD470J
R101,102 VRD-ST2CD331J
R103,104 VRD-ST2CD223J
R105,106 VRD-ST2CD153J
R107,108 VRD-ST2CD102J
R109,110 VRD-ST2CD121J
R113,114 VRD-ST2CD822J
R115~118 VRD-ST2CD392J
R119,120 VRD-ST2CD332J
R121,122 VRD-ST2CD102J
R123,124 VRD-ST2CD822J
R125 VRD-ST2CD684J
R150 VRD-ST2EE221J
R151,152 VRD-ST2CD562J
R153,154 VRD-ST2CD682J
R155,156 VRD-ST2CD273J
R157,158 VRD-ST2CD473J
R157,158 VRD-ST2CD563J
R159~164 VRD-ST2CD273J
R165,166 VRD-ST2CD684J
R167,168 VRD-ST2CD472J
R201,202 VRD-ST2CD104J
R203,204 VRD-ST2CD103J
R205,206 VRD-ST2CD472J
R207,208 VRD-ST2CD123J
R209,210 VRD-ST2CD223J
– 2 –
QT-CD131H/132H
PRICE
DESCRIPTION
RANK
AB 0.022 µF,50V
J
AB 2.2 µF,50V,Electrolytic
J
AA 0.0022 µF,50V
J
AB 0.01 µF,16V
J
AB 0.022 µF,50V
J
AB 10 µF,16V,Electrolytic
J
AB 100 µF,10V,Electrolytic
J
J AA 82 ohms,1/4W
J AA 22 ohms,1/4W
J AA 100 kohm,1/6W
J AA 33 kohms,1/6W
J AA 10 ohm,1/6W
J AA 10 kohm,1/6W
J AA 680 ohms,1/4W
J AA 4.7 kohms,1/6W
J AA 47 kohms,1/6W
J AA 100 kohm,1/6W
J AA 68 kohms,1/6W
J AA 56 kohms,1/6W
J AA 4.7 kohms,1/6W
J AA 390 ohms,1/4W
J AA 10 kohm,1/6W
J AA 1.2 kohms,1/6W
J AA 2.2 kohms,1/6W
J AA 10 kohm,1/6W
J AA 47 kohms,1/6W
J AA 10 kohm,1/6W
J AA 6.8 kohms,1/6W
J AA 5.6 kohms,1/6W
J AA 47 kohms,1/6W
J AA 3.9 kohms,1/6W
J AA 33 kohms,1/6W
J AA 1.5 kohms,1/6W
J AA 47 kohms,1/6W
J AA 10 kohm,1/6W
J AA 1.2 kohms,1/6W
J AA 15 kohms,1/6W
J AA 1 kohm,1/6W
J AA 33 kohms,1/6W
J AA 4.7 kohms,1/6W
J AA 10 kohm,1/6W
J AA 3.3 kohms,1/6W
J AA 10 kohm,1/6W
J AA 47 kohms,1/6W
J AA 22 kohms,1/6W
J AA 4.7 kohms,1/6W
J AA 47 kohms,1/6W
J AA 270 ohms,1/4W
J AA 220 ohms,1/4W
J AA 56 kohms,1/6W
J AA 2.7 kohms,1/6W
J AA 1 kohm,1/6W
J AA 10 kohm,1/6W
J AA 47 ohms,1/6W
J AA 330 ohms,1/6W
J AA 22 kohms,1/6W
J AA 15 kohms,1/6W
J AA 1 kohm,1/6W
J AA 120 ohms,1/6W
J AA 8.2 kohms,1/6W
J AA 3.9 kohms,1/6W
J AA 3.3 kohms,1/6W
J AA 1 kohm,1/6W
J AA 8.2 kohms,1/6W
J AA 680 kohms,1/6W
J AA 220 ohms,1/4W
J AA 5.6 kohms,1/6W
J AA 6.8 kohms,1/6W
J AA 27 kohms,1/6W
J AA 47 kohms,1/6W [131H]
J AA 56 kohms,1/6W [132H]
J AA 27 kohms,1/6W
J AA 680 kohms,1/6W
J AA 4.7 kohms,1/6W
J AA 100 kohm,1/6W [132H Only]
J AA 10 kohm,1/6W [132H Only]
J AA 4.7 kohms,1/6W [132H Only]
J AA 12 kohms,1/6W [132H Only]
J AA 22 kohms,1/6W [132H Only]
