Specifications

Power supply
AC
Battery
Power consumption
Frequency range
FM 87.50 MHz to 108.00 MHz (50 kHz steps)
DAB/DAB+ BAND III
5A to 13F (174.928 MHz to 239.200 MHz)
Terminal
Headphones
Speaker
Full range
Output power
Battery life
Power Manganese
source R14 battery
FM Approx. 9 H
DAB/DAB+ Approx. 12 H
Dimensions (W x H x D)
Mass
With batteries
Without batteries
Operating temperature range
Operating humidity range
35% to 80% RH (no condensation)
Power consumption in standby mode
Note:
Specifications are subject to change without notice. Mass
and dimensions are approximate.
4
AC 230 V to 240 V, 50 Hz
DC 6 V (4 x R14/LR14, C)
Stereo, 3.5 mm jack (16 Ω)
10 cm (4 Ω)
2 W (RMS 10% THD)
Alkaline
LR14 battery
Approx. 30 H
Approx. 40 H
251 mm x 138 mm x 91 mm
0°C to +40°C
0.6 W (approximate)

Troubleshooting

General
Sound is distorted or no sound.
7 W
• Adjust the volume.
• Check and adjust the antenna.
• Move the unit to another location and do a full
scan again.
• An AC mains lead or fluorescent light is near the
cables. Keep other appliances and cords away
from the cables of this unit.
Reception is poor or beat sound is heard.
• Keep the antenna away from computers, TVs,
other cables and cords. Move mobile telephones
away from the unit if the interference is apparent.
Messages
"Service not available"
• No DAB reception.
"No DAB station"
• No DAB station available.
• Check the antenna.
• Move the unit to another location and do a full
1.3 kg
scan again.
1.0 kg
"Time Not saved"
• The changes made to the time was not saved,
the changes will be lost.
"Alarm Not saved"
• The changes made to the alarm was not saved,
the changes will be lost.
