SmartClip
Wire Disengagement Instrument
Technique and Maintenance Guide
Disengagement
1
1. Approach archwire with disengagement instrument from occlusal or gingival side. (Figure 1)
2. Place instrument hooks under archwire keeping the bracket between the instrument hooks.
(Figure 2)
3. Squeeze handles. (Figure 3)
Note: Repeat procedure for each bracket.
Slide Replacement
5
1. Using a pointed object, approach tab.
2. Push tab. (Figure 5)
3. Remove slide. (Figure 6)
4. Obtain new slide. Note: Ensure proper orientation of slide. (Figure 7)
5. Push slide while holding handles in closed position. (Figure 8)
Appliance
™
2
6
3
7
4
8
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for 3M SmartClip SL3
Summary of Contents for 3M SmartClip SL3
- Page 1 SmartClip Appliance ™ Wire Disengagement Instrument Technique and Maintenance Guide Disengagement 1. Approach archwire with disengagement instrument from occlusal or gingival side. (Figure 1) 2. Place instrument hooks under archwire keeping the bracket between the instrument hooks. (Figure 2) 3. Squeeze handles. (Figure 3) Note: Repeat procedure for each bracket.
- Page 2 2510 Conway Avenue Health Care Division 3M and SmartClip are trademarks St. Paul, MN 55144-1000 USA 300 Tartan Dr. of 3M. Used under license in Canada. London, ON N5V 4M9 Canada Phone 1-800-423-4588 © 3M 2016. All rights reserved. 3M.com/ortho...
