Azoteq IQ Switch ProxSense Series Quick Start Manual
Hide thumbs
Also See for IQ Switch ProxSense Series:
- Design manual (54 pages) ,
- Programming and gui manual (18 pages) ,
- User manual (17 pages)
Advertisement
Step 1: Insert a Module
Insert a module into the dip socket (J1) on the main board.
Check the Key!
Figure 1.1
Step 2: Jumpers
Ensure
the
jumper
Ensure the jumper on W2 is placed in any
position.
Step 3: Power
Place two 3V coin-cell batteries in the battery terminal at the back.
Move the Slide switch (S1) to the "ON" position.
IQ Switch
ProxSense
uick-Start guide for the
IQS127 Evaluation Kit
Key
Main-board
on
W1
is
placed.
®
™
Series
Module-Board
Ensure switch S2 is placed in the "SENSE"
position.
Function
Dual Output
Switch Replacement
Touch on Module
Driven Shield
Single Output
Touch on main-
board
Evaluate shielding
Dual Output
Switch Replacement
With backlight
activation. Touch on
Main Board
Serial Data
Raw Data
Streaming
View data on PC.
Touch on Main
Board
