RS 1000 Switch Router
Getting Started Guide
Release 8.0
36-018-07 Rev. 0A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RS 1000 and is the answer not in the manual?

Questions and answers

Related Manuals for Riverstone Networks RS 1000

Summary of Contents for Riverstone Networks RS 1000

  • Page 1 RS 1000 Switch Router Getting Started Guide Release 8.0 36-018-07 Rev. 0A...
  • Page 2 THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Changes Riverstone Networks, Inc., and its licensors reserve the right to make changes in specifications and other information contained in this document without prior notice. The reader should in all cases consult Riverstone Networks, Inc., to determine whether any such changes have been made.
  • Page 3 Operation of this equipment in a residential area is likely to cause interference in which case the user will be required to correct the interference at his own expense. Riverstone Networks RS 1000 Switch Router Getting Started Guide iii...
  • Page 4 Ringer Equivalence Numbers of all the devices does not exceed 5. iv Riverstone Networks RS 1000 Switch Router Getting Started Guide...
  • Page 5 Do not use optical instruments to view the laser output. The use of optical instruments to view laser output increases eye hazard. When viewing the output optical port, power must be removed from the network adapter. Riverstone Networks RS 1000 Switch Router Getting Started Guide v...
  • Page 6 This equipment complies with Part 68 of the FCC rules, FCC Registration Number 6TGUSA-46505-DE-N Riverstone Networks Inc. Model WICT1-12 Made in the USA. On the DS1/E1 WAN Module of this equipment is a label that contains, among other information, the FCC registration number and Ringer Equivalence Number (REN) for this equipment.
  • Page 7 The termination on an interface may consist of any combination of devices subject only to the requirement that the sum of the Ringer Equivalence Numbers of all the devices does not exceed 5. Riverstone Networks RS 1000 Switch Router Getting Started Guide vii...
  • Page 8 IMPORTANT: BEFORE UTILIZING THE PRODUCT, CAREFULLY READ THIS LICENSE AGREEMENT. This document is a legal agreement ("Agreement") between You, the end user, and Riverstone Networks, Inc. ("Riverstone"). BY USING THE ENCLOSED SOFTWARE PRODUCT, YOU ARE AGREEING TO BE BOUND BY THE TERMS AND CONDI- TIONS OF THIS AGREEMENT AND THE RIVERSTONE STANDARD LIMITED WARRANTY, WHICH IS INCORPO- RATED HEREIN BY REFERENCE.
  • Page 9 Licensed Materials will be resolved in state or federal courts located in Santa Clara County, California, U.S.A.. You consent to the personal jurisdiction of and waive any objections to venue in such courts. Riverstone Networks RS 1000 Switch Router Getting Started Guide ix...
  • Page 10 STANDARD LIMITED WARRANTY Limited Warranty Riverstone Networks, Inc. (“Riverstone”) warrants that for a period of one (1) year from the date of shipment from Riverstone that the Riverstone hardware purchased by Customer (“Hardware”) will be free from defects in materials and workmanship under normal use.
  • Page 11 ESSENTIAL PURPOSE. THE TOTAL CUMULATIVE LIABILITY TO CUSTOMER, FROM ALL CAUSES OF ACTION AND ALL THEORIES OF LIABILITY, WILL BE LIMITED TO AND WILL NOT EXCEED THE PUR- CHASE PRICE OF THE PRODUCT PAID BY CUSTOMER. Riverstone Networks RS 1000 Switch Router Getting Started Guide xi...
  • Page 12 Santa Clara, CA 95054 Conformance to Directive(s)/Product EC Directive 89/336/EEC EC Directive 73/23/EEC Standards EN 55022 EN 50082-1 EN 60950 Equipment Type/Environment Networking equipment for use in a commercial or light-industrial environment xii Riverstone Networks RS 1000 Switch Router Getting Started Guide...

  • Page 13: Table Of Contents

    Installing the RS 1000 into an Equipment Rack ....... . .
  • Page 14 Index ............I-1 xiv Riverstone Networks RS 1000 Switch Router Getting Started Guide...
  • Page 15 Figure 3-10 Installing the RS 1000 chassis in an equipment rack ......
  • Page 16 Riverstone Networks RS 1000 Switch Router Getting Started Guide...
  • Page 17 ISO 7-layer model and RS 1000 capabilities ........
  • Page 18 Troubleshooting..............A-1 xviii Riverstone Networks RS 1000 Switch Router Getting Started Guide...

  • Page 19: About This Guide

    The complete syntax for all Command Line Riverstone RS Switch Router Command Line Interface (CLI) commands Interface Reference Manual Console and SYSLOG messages Riverstone RS Switch Router Message Reference Manual Riverstone Networks RS 1000 Switch Router Getting Started Guide 1-1...
  • Page 20 Related Documentation About This Guide 1-2 Riverstone Networks RS 1000 Switch Router Getting Started Guide...

  • Page 21: Introduction

    These layers are based on the International Standards Organization (ISO) 7-layer reference model. Here is an example of that model. The RS 1000 operates within the layers that are not shaded. Notice that layer 2 is divided into a MAC layer, an LLC layer, and an LLC2 layer. The RS 1000 operates at the MAC and LLC layers.

  • Page 22: Specifications

    Introduction SPECIFICATIONS The RS 1000’s hardware provides high-speed performance regardless of any performance monitoring, filtering, Quality of Service (QoS), or Access Control Lists (ACLs) enabled through the software. Performance is not compromised. The following table lists the RS 1000’s technical specifications.
  • Page 23 Port mirroring Traffic from specific ports • Traffic to specific expansion slots (line cards) • RMON RMON v1/v2 for each port • Management SNMP • Emacs-like Command Line Interface (CLI) Riverstone Networks RS 1000 Switch Router Getting Started Guide 2-3...

  • Page 24: Software Overview

    L2 lookup table on the line card that received the packet from the network. The L2 lookup table indicates the exit port(s) for the bridged packet. If the packet is addressed to the RS 1000’s own MAC address, the packet is routed rather than bridged.
  • Page 25 Note By default, the RS 1000 uses one MAC address for all interfaces. The RS 1000 can be configured to have a separate MAC address for each IP interface and a separate MAC address for each IPX interface. When the RS 1000 receives a packet whose destination MAC address is one of the RS 1000’s IP or IPX interface MAC addresses, the line card that...

  • Page 26: Layer-4 Switching

    Layer-4 Flows – The RS 1000 can store layer-4 flows on each line card. A layer-4 flow consists of the source and destination addresses in the IP or IPX packet combined with the TCP or UDP source and destination port number (for IP) or the source and destination socket (for IPX).

  • Page 27: Statistics

    2.3.7 Statistics The RS 1000 can provide extensive statistical data on demand. You can access the following types of statistics: Layer-2 RMON and MIB II Statistics – Port statistics for normal packets and for errors (packets in, packets out, CRC errors, and so on) Layer-3 RMON v2 Statistics –...

  • Page 28: Management Platforms

    Chapter 4, "Initial Configuration." SNMP MIBs and traps – The RS 1000 supports SNMP v1/v2 and many standard networking MIBs. The RS 1000’s SNMP agent is accessed using integration software such as HP OpenView 5.x on Windows NT or Solaris 2.x, or Aprisma SPECTRUM on Windows NT or Solaris 2.x.

  • Page 29: Motherboard

    Section 2.4.4, "Line Cards." External Controls and Connections The RS 1000 has the following external controls and ports used for managing the RS 1000: • Male DB-9 Data Communications Equipment (DCE) port for serial connection to a terminal or PC running terminal emulation software.

  • Page 30: Power Supplies

    2.4.3 Power Supplies The RS 1000 uses one power supply, either an AC power supply or a DC power supply. You can make a choice of supply depending on your needs. AC Power Supply A single AC power supply provides enough current to operate a fully configured chassis. On the back end of the supply is the AC power cord socket.

  • Page 31: Figure 2-3 Dc Power Supply Back Side With Wiring Block

    (–) terminal, marked RTN; and a safety ground, marked GND. The DC supply is designed to be powered by a 48 Volt DC source. Use 12-gauge to 14-gauge wire to connect the 48-Volt source to the RS 1000’s DC power supply. Use 12- to 14-gauge wire for the safety ground.

  • Page 32: Line Cards

    3 inches of clearance on each side of the chassis. 2.4.4 Line Cards The following section describes the various line cards that can be installed in the RS 1000: 100BASE-FX Line Card The 100BASE-FX line card uses multimode fiber cable (MMF) to connect to the network.

  • Page 33: Figure 2-5 1000Base-Sx Line Card

    Maximum of 275 meters (902 feet) segment length for 62.5 micron fiber-optic cable, based on installed fiber bandwidth • Maximum of 550 meters (1804 feet) segment length for 50 micron fiber-optic cable, based on installed fiber bandwidth Riverstone Networks RS 1000 Switch Router Getting Started Guide 2-13...

  • Page 34: Figure 2-6 1000Base-Lx Line Card

    The 1000BASE-LX line card provides the same features as the 1000BASE-SX line card, and supports both single-mode fiber (SMF) and MMF. Figure 2-6 shows the front panel of the 1000BASE-LX line card. G3M-GLXB9-02 1000BASE-LX Link Link Figure 2-6 1000BASE-LX line card 2-14 Riverstone Networks RS 1000 Switch Router Getting Started Guide...

  • Page 35: Table 2-10 1000Base-Lx Line Card Specifications

    Off – There is no cable is plugged into the port. Per-port Rx Green – Indicates when the port receives packets. Orange – Indicates when the port receives flow-control packets. Riverstone Networks RS 1000 Switch Router Getting Started Guide 2-15...

  • Page 36: Figure 2-7 1000Base-Lh Line Card

    MIC can be used for transmit or receive • 10 micron single-mode fiber-optic cable • Maximum 70 kilometers (229,659 feet) segment length for 10 micron SMF fiber-optic cable 2-16 Riverstone Networks RS 1000 Switch Router Getting Started Guide...

  • Page 37: Figure 2-8 Front Panel Of Dual Serial Wan Line Card

    WAN port. Figure 2-8 shows the front panel of the Dual Serial WAN line card. G2M-SERAC-02 Dual Serial Link Figure 2-8 Front panel of Dual Serial WAN line card Riverstone Networks RS 1000 Switch Router Getting Started Guide 2-17...

  • Page 38: Figure 2-9 Front Panel Of Quad Serial - C/Ce Wan Line Card

    Riverstone Networks, Inc. Connector cables for WAN line cards may be ordered from Riverstone offers the following four cables, used to connect the RS 1000 to standard CSU/DSU modules: Table 2-15 Dual Serial port to CSU/DSU cables Riverstone Part Number...

  • Page 39: Figure 2-10 Lfh-60 High Density Connector

    P2_RXD_A P1_DSR_B P2_DTR_A P1_DTR_B P2_RXC_B P1_MODE[1] P2_SCTE_B P1_LL_A P2_RXC_A P1_GND P2_SCTE_A P1_SHIELD Figure 2-10 shows the pin positions in the LFH-60 high density connector. Figure 2-10 LFH-60 high density connector Riverstone Networks RS 1000 Switch Router Getting Started Guide 2-19...

  • Page 40: Figure 2-11 Front Panel Of Dual Hssi Wan Line Card

    50-pin High Speed Serial Interface (HSSI) connector • Recommended 3 meters (10 feet) segment length for standard WAN line card-to-CSU/DSU data port. Riverstone. Connector cables for WAN line cards may be ordered from 2-20 Riverstone Networks RS 1000 Switch Router Getting Started Guide...

  • Page 41: Figure 2-12 50-Pin Hssi Connector

    Dual HSSI line card or the remote HSSI CSU/DSU data port. Figure 2-12 shows the pin positions in the 50-pin HSSI connector. Figure 2-12 50-pin HSSI connector Riverstone Networks RS 1000 Switch Router Getting Started Guide 2-21...

  • Page 42: Figure 2-13 Multi-Rate Wan Line Card With One T1 Wic

    When lit, this amber LED on the left side of the line card indicates that the line card is offline (powered off). The Offline LED also is lit briefly during a reboot or reset of the RS 1000 but goes out as soon as the CPU discovers the line card.

  • Page 43: Figure 2-15 Clear Channel T3 And E3 Wics

    Table 2-23 Specifications for Clear Channel T3 WIC card Port-type Specification • Clear Channel T3 75-ohm coaxial BNC connectors • ANSI T1.102, T1.107, and T1.404a compliant • Supports M23 and C-bit framing • B8ZS Riverstone Networks RS 1000 Switch Router Getting Started Guide 2-23...

  • Page 44: Table 2-24 Specifications For Clear Channel E3 Wic Card

    Table 2-25 Pin assignments for T1 and E1 WICs WIC Line Card Connector Pin Number RJ-48c/RJ-45 Connector at Other End of Segment reserved reserved reserved reserved reserved reserved reserved reserved 2-24 Riverstone Networks RS 1000 Switch Router Getting Started Guide...

  • Page 45: Table 2-26 Leds For Multi-Rate Wan Line Card And Wics

    Flashing Green – indicates that the port’s transceiver is receiving data. Blinking Yellow – the Red alarm. Indicates a loss of signal (LOS) or loss of framing (LOF) on the Rx side. Riverstone Networks RS 1000 Switch Router Getting Started Guide 2-25...

  • Page 46: Figure 2-16 Front Panel Of 10/100Base-Tx Line Card

    This amber LED on the left side of the line card indicates that the line card is offline. It is also lit briefly during a reboot or reset of the RS 1000 and goes out as soon as the control module discovers and properly initializes the module.
  • Page 47 Activity The amber LED on the right side of each port connector flashes each time the port sends or receives packets. Riverstone Networks RS 1000 Switch Router Getting Started Guide 2-27...
  • Page 48 Hardware Features Introduction 2-28 Riverstone Networks RS 1000 Switch Router Getting Started Guide...

  • Page 49: Hardware Installation

    • Never operate the RS 1000 with exposed expansion slots. • Never operate the RS 1000 if it becomes wet or the area where it has been installed is wet. 3.1.2 Preventing Equipment Damage To prevent damage to the RS 1000 components, observe the following warnings.

  • Page 50: Hardware Specifications

    3.3.1 Verifying Your Shipment Before you begin installing your RS 1000, check your shipment to ensure that everything you ordered arrived securely. Open the shipping box(es) and verify that you received the following equipment: 3-2 Riverstone Networks RS 1000 Switch Router Getting Started Guide...

  • Page 51: Installing Line Cards

    Installing Line Cards Before installing the RS 1000 into an equipment rack, it is recommended that you first install any expansion line cards that you may have ordered with the unit. Installing expansion line cards before rack mounting will prevent the need to remove the RS 1000 from its rack and remove the mounting hardware from the RS 1000 chassis.

  • Page 52: Figure 3-1 Removing The Rs 1000'S Cover

    Figure 3-1 Removing the RS 1000’s cover Slide the cover away from the front of the RS 1000 about one-half inch (1/2”), then lift the cover away. Be careful not to damage or remove any EMI gaskets around the edges of the cover.

  • Page 53: Figure 3-4 "Extended" Emi Face Plate

    Line up the two screw holes at the back of the line card and insert the vertical female connector at the back of the line card into the male connector on the RS 1000’s motherboard. Riverstone Networks RS 1000 Switch Router Getting Started Guide 3-5...

  • Page 54: Multi-Rate Wan Line Card And Wics

    RS 1000 10/100 MGMT CONSOLE Figure 3-6 Installing a line card Replace the cover of the RS 1000, and secure it using the #2 Phillips-head screwdriver and the four screws previously removed. 3.3.3 Multi-rate WAN Line Card and WICs This section describes the procedure for installing the Multi-rate WAN line-card. Additionally, if your configuration uses either a Clear Channel T3 or E3 WIC, you must consider the setting of the WIC module’s grounding-jumpers.

  • Page 55: Figure 3-7 Jumper Position On Clear Channel T3 And E3 Wics

    Because of its design, the Multi-rate WAN line card requires a somewhat different installation procedure. The following describes how to install a Multi-rate WAN line card and its WAN Interface Cards (WIC). Riverstone Networks RS 1000 Switch Router Getting Started Guide 3-7...

  • Page 56: Figure 3-8 Removing The Stand-Offs On The Motherboard

    Figure 3-1). Slide the cover away from the front of the RS 1000 about one-half inch (1/2”), then lift the cover away. Be careful not to damage or remove any EMI gaskets around the edges of the cover. Use the #2 Phillips-head screwdriver to remove the four mounting screws that secure the cover plate...

  • Page 57: Installing The Rs 1000 Into An Equipment Rack

    Installing the RS 1000 into an Equipment Rack The RS 1000 is designed to be installed in a standard 19” equipment rack. To install the RS 1000 in an equipment rack, use the following procedure. You will need a #2 Phillips-head screwdriver to perform this procedure.

  • Page 58: Figure 3-10 Installing The Rs 1000 Chassis In An Equipment Rack

    RS 1000 is powered off. Align one of the mounting brackets over the corresponding holes in the side of the RS 1000. The mounting bracket is correctly positioned when the side with two open mounting holes is flush with the front of the RS 1000.

  • Page 59: Management Ports

    Connecting the Serial Management Cable Use the serial cable to connect the RS 1000 to a terminal (or to a PC running terminal emulation software) to perform initial setup and configuration. The RS 1000’s serial cable is a female to female DB-9 crossover cable.

  • Page 60: Figure 3-13 Rs 1000'S 10/100Base-Tx Management Port

    Unused Unused a. The left hand column pin assignments are for the male DB-9 connector on the RS 1000. Pin 2 (TXD or “transmit data”) must emerge on the management console’s end of the connection as RXD (“receive data”). Connecting a 10/100BASE-TX Management Cable Use the RJ-45 10/100BASE-TX DTE port for connecting the RS 1000 to your network for in-band management through either Telnet or SNMP.

  • Page 61: Table 3-2 Table

    Unused Unused a. The right hand column pin assignments are for the RJ-45 connector on the RS 1000. Pin 1 (TXD or “transmit data”) must emerge on the management console’s end of the connection as RXD (“receive data”). Riverstone Networks RS 1000 Switch Router Getting Started Guide 3-13...
  • Page 62 Installing the Hardware Hardware Installation 3-14 Riverstone Networks RS 1000 Switch Router Getting Started Guide...

  • Page 63: Initial Configuration

    If this is the first time you have powered on the RS 1000, it boots automatically using the software image on the internal flash memory. While the software is booting, the amber Offline LED on the front of the RS 1000 is lit.
  • Page 64 When the software is fully booted, the following messages appears on the management console: Press RETURN to activate console... As prompted, press Return (or Enter) to activate the Command Line Interface (CLI) on the console. 4-2 Riverstone Networks RS 1000 Switch Router Getting Started Guide...
  • Page 65 ” appears while booting the RS 1000, the SYS-E-NOFLASHCARD system has not detected its internal flash memory. If this occurs, reboot the system. If the system still does not recognize its memory, contact Riverstone Networks Technical Support. Riverstone Networks RS 1000 Switch Router Getting Started Guide 4-3...

  • Page 66: Starting The Command Line Interface

    Return; the factory default passwords for all access levels is blank. 4.2.1 CLI Access Modes The CLI has four levels of access, each of which provides the ability to perform specific operations on the RS 1000 (see Table 4-1).

  • Page 67: Basic Line Editing Commands

    Ctrl+p Scroll to previous command in command history Ctrl+u Erase entire line Ctrl+x Erase from cursor to end of line Ctrl+z Exit current access mode to previous access mode Riverstone Networks RS 1000 Switch Router Getting Started Guide 4-5...

  • Page 68: Configuration Changes And Saving The Configuration File

    The commands from the Startup configuration file and any configuration commands that you have made active from the scratchpad. Startup The configuration file that the RS 1000 uses to configure itself when the system is powered on. Caution The active configuration remains in effect only during the current power cycle.

  • Page 69: Saving The Active Configuration To The Startup Configuration File

    Are you sure you want to overwrite the Startup configuration? [n] The new configuration changes are added to the Startup configuration file located in the RS 1000’s boot flash. Riverstone Networks RS 1000 Switch Router Getting Started Guide 4-7...

  • Page 70: Viewing The Current Configuration

    .” For example, if you enable STP on all ports on the RS 1000, but the RS 1000 contains only one line card, the configuration lines that enable STP will be applied to all ports on all other line cards as they are added to the system.

  • Page 71: Setting The Basic System Information

    System name • System location • Contact name (the person to contact regarding this RS 1000) • IP address for the management port on the RS 1000 Some of the commands in this procedure accept a string value. String values can Note be up to a maximum of 255 characters in length including blank spaces.
  • Page 72 Use the command to set the IP address and netmask for the en0 Ethernet interface add ip interface. The en0 Ethernet interface is used by the RS 1000’s management port. Here is an example: interface add ip en0 address-netmask 16.50.11.22/16...
  • Page 73 When the CLI displays the following message, enter to save the changes to the Startup configuration file: Are you sure you want to overwrite the Startup configuration [no]? y %CONFIG-I-WRITTEN, file copied successfully Riverstone Networks RS 1000 Switch Router Getting Started Guide 4-11...

  • Page 74: Setting Up Passwords

    Notice that the passwords are shown in the Active configuration in an encrypted format. Passwords also appear this way in the Startup configuration. To keep your passwords secure, the RS 1000 does not have a command for displaying passwords in an unencrypted format.

  • Page 75: If You Forget Your Passwords

    4.5.1 If You Forget Your Passwords If you forget your passwords follow this procedure to regain access to your RS 1000. To perform this procedure, you must use a terminal or PC running terminal Note emulation software that is connected directly to the RS 1000 through its DB-9 console port.
  • Page 76 <image name> skipconfig=yes Here is an example: rs-boot> boot /pc-flash/boot/rs80 skipconfig=yes When the RS 1000 finishes booting, enter the following commands (when prompted, answer rs> enable rs# copy startup to scratchpad rs# config rs(config)# system set password login none...

  • Page 77: Setting Up Snmp

    SETTING UP SNMP To use SNMP to manage the RS 1000, you need to set up an SNMP community and specifying the IP address of the target host for SNMP traps. Otherwise, the RS 1000’s SNMP agent runs in local trap process mode, unless disabled using the command.

  • Page 78: Improving Snmp Security

    Applying ACLs to SNMP When using SNMP v1 or v2, it is important to protect your RS 1000 by applying an Access Control List (ACL) to the SNMP agent to prevent unauthorized access and route your SNMP traffic through trusted networks only.

  • Page 79: Supported Mibs

    Initial Configuration Setting Up SNMP For additional information about RS 1000 security and ACLs, see the Riverstone RS Switch Router User Guide. 4.6.3 Supported MIBs The following lists the MIBs that are supported by the RS 1000 SNMP agent. Table 4-4...

  • Page 80: Setting The Dns Domain Name And Address

    For example, you can use a device’s name (which the DNS server knows) when using the command. ping If you want the RS 1000 to access a DNS server, use the following procedure to specify the domain name and IP address for the DNS server. Ensure that you are in Enable mode by entering the command in the CLI.
  • Page 81 PING rs.mktg.mrb.com (16.50.11.22): 56 data bytes 64 bytes from 16.50.11.22: icmp_seq=0 ttl=255 time=0 ms --- rs.mktg.mrb.com ping statistics --- 1 packets transmitted, 1 packets received, 0% packet loss round-trip min/avg/max = 0/0/0 ms Riverstone Networks RS 1000 Switch Router Getting Started Guide 4-19...

  • Page 82: Setting The Syslog Parameters

    %CONFIG-I-SAVED configuration saved to Startup configuration The RS 1000 writes the SYSLOG messages to a SYSLOG daemon on UDP port 514. You can set the CLI to send all or only some of the message types. By default, the CLI sends warning, error, and fatal messages but not informational messages to the specified SYSLOG server.
  • Page 83 To activate the SYSLOG commands, use the command. Enter to activate the save active changes. Up to four SYSLOG servers can be configured for each RS. Note Riverstone Networks RS 1000 Switch Router Getting Started Guide 4-21...
  • Page 84 Setting the SYSLOG Parameters Initial Configuration 4-22 Riverstone Networks RS 1000 Switch Router Getting Started Guide...

  • Page 85: Managing Software

    ” indicates that the RS 1000 is set to use the factory-installed pc-flash software on its internal flash memory. Copy the upgrade system software onto a TFTP server that the RS 1000 can access. (Use the command to verify that the RS 1000 can reach the TFTP server.) ping...
  • Page 86 (version 8.1.0.0) ros8000 (version 8.0.0.0) [selected for next boot] Use the command to select the image file that the RS 1000 will use when system image choose rebooted. Here is an example: system image choose ros8100 Found image in slot0 Making image ros8100 (version 8.1.0.0) the active image...

  • Page 87: Upgrading Boot Prom Software

    Copy the upgrade boot PROM image software onto a TFTP server that the RS 1000 can access. (Use command to verify that the RS 1000 can reach the TFTP server.) ping If the TFTP server is one or more hops away from the RS 1000, add a route to the Note TFTP server’s network using the command.
  • Page 88 Active-CM: Programming complete. Reboot the RS 1000. Enter the command to verify that the new boot PROM software is in the system show version internal memory of the RS 1000’s motherboard. 5-4 Riverstone Networks RS 1000 Switch Router Getting Started Guide...

  • Page 89: Loading Software From The Network

    Typically, the RS 1000 loads its operating software from the flash memory contained on the motherboard. Alternately, the RS 1000 can be configured to ignore its internal flash image and obtain its software from a network server. The RS 1000 can obtain its image software from either a TFTP or BootP/TFTP server.
  • Page 90 RS 1000 can reach the TFTP server. ping Reboot the RS 1000. As the RS 1000 initializes, it ignores the software image on the internal flash and retrieves its operating software from the TFTP server at 134.152.176.5...

  • Page 91: Loading Image Software From A Bootp/Tftp Server

    The RS 1000 contains a BootP client and can be configured to obtain its image software from a BootP/TFTP server. Using the BootP client allows the RS 1000 to obtain its software network address from the server using only its MAC address.
  • Page 92 Build date: Mon Dec 25 23:56:47 2000 File: kernel (3568593 bytes) Loading kernel (base 0x80001000, size 50528) (base 0x8000d560, size 3507312) 100% - kernel loaded... Press RETURN to activate console . . . 5-8 Riverstone Networks RS 1000 Switch Router Getting Started Guide...

  • Page 93: Troubleshooting

    System Image Software." You are unable to access the configuration From the CLI, type to access the Enable enable commands in the CLI. mode, then type to access the Configure configure mode. Riverstone Networks RS 1000 Switch Router Getting Started Guide A-1...
  • Page 94 You are unable to ping a certain host. Create and add an IP or IPX interface for the host. See the Riverstone RS Switch Router User Guide for information. A-2 Riverstone Networks RS 1000 Switch Router Getting Started Guide...
  • Page 95 Command Line Interface BootP/TFTP server........5-7 management port ....... 2-9 configuring......... 5-7 management port, cable installation 3-11 bootsource ..........4-13 community string........4-15 ............ 2-4 bridging configuration address-based........2-4 Riverstone Networks RS 1000 Switch Router Getting Started Guide Index-1...
  • Page 96 ............. 2-1 Quad Serial - C/CE ......2-20 flow ACLs LFAP ............2-7 layer-3 ..........2-6 line cards..........2-12 ..........2-6 layer-4 line editing commands......4-5 flow switching .......... 2-6 load balancing...........2-7 flow-based bridging........2-4 Index-2 Riverstone Networks RS 1000 Switch Router Getting Started Guide...
  • Page 97 L3 lookup tables ........ 2-5 1000Base-LX........2-14 routing protocols .......2-2, 1000Base-SX ........2-13 RS 1000 1000-Mbps........2-16 default name........4-4 100Base-FX ........2-12 security..........2-6 serial......... 2-17 dual gigabit ..........2-16 HSSI..........2-20 Riverstone Networks RS 1000 Switch Router Getting Started Guide Index-3...
  • Page 98 ......4-15 initial configuration system show version......5-1, MIBs ..........4-17 privilege ........... 4-15 security..........4-16 supported MIBs ....... 4-17 TACACS ..........2-6 ........4-16 trap-source TACACS+ ..........2-6 software upgrade ........5-1 Index-4 Riverstone Networks RS 1000 Switch Router Getting Started Guide...
  • Page 99 ........4-4 configuration....4-10 viewing active viewing current configuration ....4-8 VLAN protocols........2-2 VLANs port-based .......... 2-4 ........2-4 protocol-based secondary IP addresses ...... 2-5 ........2-8 VPN persistence Riverstone Networks RS 1000 Switch Router Getting Started Guide Index-5...

  • Page 100: Index

    Index Index-6 Riverstone Networks RS 1000 Switch Router Getting Started Guide...
