Caution
● This brief description does not replace the operating instructions!
● You absolutely must observe all instructions in the operating instructions for use
and safety of the product!
Information
The current operating instructions are available in German, English, Spanish, Ital-
ian and French and can be downloaded directly from the KEBA website (http://
www.keba.com/kemes). If you require the operating instructions in another lan-
guage, please contact KEBA.
Original language: German
Bluetooth declaration
The Bluetooth
Inc. and each use of this trademark by KEBA is licensed. Other trademarks and
brands are the property of their respective owners.
Information for the Canadian market
This Class B digital apparatus meets all requirements of the Canadian Interference-
Causing Equipment Regulations.
Specifications are subject to change due to further technical developments.
Details presented may be subject to correction.
All rights reserved.
Gewerbepark Urfahr, 4041 Linz, Austria,
KEBA AG Head-
Phone: +43 732 7090-0, Fax: +43 732 7309-10,
quarters:
keba@keba.com
For information about our subsidiaries please look at www.keba.com.
V 1.05
KeMes A1xx/ A2xx Brief description
®
trademark and logos are registered trademarks of Bluetooth SIG,
Valid for firmware version 2.0 and later
