- Page 1 80x40 assembly instructions bolt 16x levelers 4x rubber bumper 7x allen key 9268855—04/07 Page 1 of 5...
- Page 2 80x40 assembly instructions 1. Insert bolt (A) through predrilled hole in bracket and into predrilled hole in leg panel as shown. Tighten using allen key (D). 9268855—04/07 Page 2 of 5...
- Page 3 80x40 assembly instructions 2. Insert leveler (B) into predrilled hole in bottom of leg as shown. If neccessary, adjust by hand when leveling table on floor after completed table assembly. 9268855—04/07 Page 3 of 5...
- Page 4 80x40 assembly instructions 3. Insert brackets on legs into openings in center panel as shown. Insert bolt (A) into pre-dilled holes on bottom faces of center panel as shown. Tighten using allen key (D). 9268855—04/07 Page 4 of 5...
- Page 5 80x40 assembly instructions 4. Insert rubber bumpers (C) into predrilled holes in top of center panel and legs as shown. Carefully set table top into place. PLEASE NOTE: GLASS TOP AND METAL FRAME ARE PACKED IN SEPERATE CARTONS CARE INSTRUCTION Hardware may loosen over time.
