Murata LBEE58D1VF-TEMP Instruction Manual page 12

C2 GND
C14 AON_RFACMN_LDO
_IN
C15 GND
D1 LF_CLK_IN
D2 PCIE_RST#
D14 GND
D15 RFA17_LDO_IN
E1 BT_I2S0_SDO/EDL_
MODE
E2 BT_I2S0_SCK/BT_SL
IMBUS_CLK
E14 CLK_REQ_IN
E15 GND
F1 BT_I2S0_SDI/BT_SLI
MBUS_DATA
F2 BT_I2S0_WS
F14 GND
F15 WLAN_EN
G1 BT_SENS_RXD
G2 BT_SENS_TXD/CPU_
INIT_RESET
G14 GND
G15 BT_EN
H1 XTAL_GND
H2 XTAL_GND
H14 GND
H15 LAA_AS_EN
J1 XTALI
J2 XTAL_GND
J14 WL_PA_MUTE
J15 WL_TXEN
K1 XTAL_GND
K2 XTAL_GND
K14 LAA_TXEN
K15 LAA_RX
L1 BT_UART_CTS
L2 BT_UART_RXD
L14 GND
L15 GND
M1 BT_UART_TXD
M2 BT_UART_RTS
< Specification may be changed by Murata without notice >
Preliminary Specification Number : SP-8D1VF-H
GND -
P VDD_PMU_A
ON_I
GND -
I/O GPIO GPIO_14
I/O GPIO GPIO_57
GND -
P VDD19_PMU_
RFA_I
I/O GPIO GPIO_6
I/O GPIO GPIO_7
I CLK_REQ_IN
GND -
I/O GPIO GPIO_4
I/O GPIO GPIO_5
GND -
I WLAN_EN
I/O GPIO GPIO_9
I/O GPIO GPIO_8
GND -
I BT_EN
GND -
GND -
GND -
I LAA_AS_EN
I XTALI
GND -
I/O GPIO GPIO_43
I/O GPIO GPIO_41
GND -
GND -
I/O GPIO GPIO_40
I/O GPIO GPIO_42
I/O GPIO GPIO_2
I/O GPIO GPIO_0
GND -
GND -
I/O GPIO GPIO_1
I/O GPIO GPIO_3
Preliminary & Confidential
Murata Manufacturing Co., Ltd.
11 / 31
1.9 V input for 1.7 V
output LDO
clock request signal
Enable WLAN
Enable BT
Enable LTE-U Antenna
Sharing
