Murata LBEE58D1VF-TEMP Instruction Manual page 10

Q2 6.625 0.8
Q14 6.625 6.2
Q15 6.625 6.65
R1 7.075 0.35
R2 7.075 0.8
R14 7.075 6.2
R15 7.075 6.65
S1 7.525 0.35
S2 7.525 0.8
S14 7.525 6.2
S15 7.525 6.65
T1 7.975 0.35
T2 7.975 0.8
T3 7.975 1.25
T4 7.975 1.7
T5 7.975 2.15
T6 7.975 2.6
T7 7.975 3.05
T8 7.975 3.5
T9 7.975 3.95
T10 7.975 4.4
T11 7.975 4.85
T12 7.975 5.3
T13 7.975 5.75
T14 7.975 6.2
T15 7.975 6.65
V1 8.425 0.35
V2 8.425 0.8
V3 8.425 1.25
V4 8.425 1.7
V5 8.425 2.15
V6 8.425 2.6
V7 8.425 3.05
V8 8.425 3.5
V9 8.425 3.95
V10 8.425 4.4
V11 8.425 4.85
V12 8.425 5.3
V13 8.425 5.75
V14 8.425 6.2
V15 8.425 6.65
