8.5.

DC/RF Characteristics for IEEE802.11a - 5GHz

Normal Condition : 25deg.C, Supply voltage is typ value in "4. operating condition"
54Mbps mode unless otherwise specified.
Items
Specification
Mode
Channel frequency (spacing)
Current Consumption
(a) Tx mode
(b) Rx mode
Transmitter
Power Levels (Power setting : 18dBm)
Spectrum Mask
(a) at fc +/- 11MHz
(b) at fc +/- 20MHz
(c) at fc > +/-30MHz
Constellation Error
Spurious Emissions (BW=100kHz)
(a) 30MHz -1GHz
(b) 1GHz – 26GHz
Receiver
*PER< 10%
Minimum Input Level
8.6. DC/RF Characteristics for IEEE802.11n(HT20) - 5GHz
Normal Condition : 25deg.C, Supply voltage is typ value in "4. operating condition"
MCS7 mode unless otherwise specified.
Items
Specification
Mode
Channel frequency
Current Consumption
(a) Tx mode
(b) Rx mode
Transmitter
Power Levels(Power setting : 17dBm)
Spectrum Mask
(a) at fc +/- 11MHz
(b) at fc +/- 20MHz
(c) at fc > +/-30MHz
Constellation Error
*
measured at full packet channel estimation
Spurious Emissions (BW=100kHz)
(a) 30MHz -1GHz
(b) 1GHz – 26GHz
Receiver
*PER< 10%, LDPC enabled
Minimum Input Level
< Specification may be changed by Murata without notice >
Preliminary Specification Number : SP-8D1VF-H
min.
min.
15.5
-
-
-
-
-
-
min.
-
min.
min.
14.5
-
-
-
-
-
-
min.
-
Preliminary & Confidential
Murata Manufacturing Co., Ltd.
Contents
IEEE802.11a-5GHz
OFDM
5180MHz to 5825MHz
Typ. Max.
- 360
- 100
Typ. Max.
18 20.5
- -20
- -28
- -40
- -25
- -36
- -30
Typ. Max.
- -65
Contents
IEEE802.11n-5GHz
OFDM
5180MHz to 5825MHz
Typ. Max.
- 310
- 100
Typ. Max.
17 19.5
- -20
- -28
- -40
- -27
- -36
- -30
Typ. Max.
- -64
18 / 31
Unit
mA
mA
Unit
dBm
dBr
dBr
dBr
dB
dBm
dBm
Unit
dBm
Unit
mA
mA
Unit
dBm
dBr
dBr
dBr
dB
dBm
dBm
Unit
dBm
