Summary of Contents for Avid Power ACVB432
- Page 1 MODEL: ACVB432 2x20V MAX BRUSHLESS CORDLESS BLOWER...
- Page 2 SYMBOLS SYMBOL NAME DESIGNATION/EXPLANATION Safety Alert Precautions that involve your safety. To reduce the risk of injury, user must read Read the user’s manual and understand user’s manual before using this product. Wear eye protection that is marked to Eye protection comply with ANSI Z87.1 when operating this equipment.
-
Page 3: General Power Tool Safety Instr Uctions
GENERAL POWER TOOL SAFETY INSTR UCTIONS Read all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Retain this manual for future reference. 1. Work area safety a. Keep work area clean and well lit. Cluttered or dark areas invite accidents. b. - Page 4 GENERAL POWER TOOL SAFETY INSTR UCTIONS connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energising power tools that have the switch on invites accidents. d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury.
- Page 5 GENERAL POWER TOOL SAFETY INSTR UCTIONS 7. Check for damaged parts a. Before using the tool, carefully check it for damage to ensure that it will operate properly and perform its intended function. b. Check for misalignment and seizure of moving parts, breakage of parts and any other conditions that may effect its operation.
- Page 6 SPECIFIC SAFETY WARNINGS FOR BLOWER Keep a safety distance of 5 m around you. „ Be familiar with your surroundings and pay attention to potential dangers that may be overlooked when working. „ Carefully inspect the surface to be cleaned and remove all wires, stones, cans and other foreign bodies.
-
Page 7: Specifications
SPECIFICATIONS Voltage: 2x20V Max No-load speed: 9000-23000 RPM(4 speeds+ Turbo) Max. Air speed: 100 MPH / Turbo: 130 MPH Max. Air volume: 353 CFM / Turbo: 485 CFM Includes: 1pc cordless leaf blower 1pc blower pipe 2pc battery pack 1pc charger 1pc user manual DESCRIPTION 1. - Page 8 ASSEMBLY If any parts are damaged or missing do not operate this product until the parts are replaced. Do not attempt to modify this product or create accessories not recommended for use with this product. Do not connect to power supply until assembly is complete.
- Page 9 ASSEMBLY To remove the battery pack Press the battery release button , Slide the battery pack backward, and then pull or lift the battery out of the tool. NOTE: Before using the blower for the first time, please full charge the battery pack at first.
- Page 10 Switching On/Off(Fig.4) Battery indicator Air speed indicator The cordless leaf blower may only be used with two batteries of the AVID POWER. Before switching the device on, make sure that it is not touching any objects. Ensure secure positioning. „ Press and hold the ON/OFF button to start the blower.
- Page 11 OPERATING „ The battery indicator is used to show the remaining power of the battery pack. „ Air speed indicator shows four different air speed during your job. „ To switch off, briefly press the ON/OFF button. Using the Blower „...
-
Page 12: Maintenance
MAINTENANCE In order to avoid personal injury and the risk of fire and electric shock, remove the battery pack before adjusting, inspecting, or cleaning the blower. When servicing, use only identical replacement parts. Use of any other parts could create a hazard or cause product damage. „... -
Page 13: Troubleshooting
TROUBLE SHOOTING Read instruction manual first! Remove battery pack from the tool before making adjustments or assembling accessories. Problem Possible Cause Possible Solution Battery pack not Check battery pack installation installed properly Unit will not start Battery pack not Check battery pack charging charged requirements Battery pack not... -
Page 14: Parts List
PARTS LIST Description Blower Tube Blower Rectifier Diffusion Duct Blower Rectifier Cover Right Handle Self Tapping Screw St4*8 Right Housing Self Tapping Screw St4*16 Right Connecting Seat Switch Panel Brushless Motor Assembly Controller Left Handle Left Connecting Seat Left Housing Strap Hook Air Inlet Hood Upper Battery Holder... -
Page 15: Schematic Drawing
SCHEMATIC DRAWING...
Need help?
Do you have a question about the ACVB432 and is the answer not in the manual?
Questions and answers
Need a battery charger for an Avid Power 2x20 Max Brushless Cordless Blower ACVB432. Need to know the cost and where to .
