Summary of Contents for bendlabs Two Axis
- Page 1 Two Axis Development Kit Getting Started Guide...
- Page 2 T W O A X I S D E V E L O P M E N T K I T Getting Started Guide Bend Labs 1649 W 1700S • Suite 100 Salt Lake City, UT 84105 www.bendlabs.com...
- Page 3 T able of Contents Precautions ................1 Device Setup ................2 Expected Output ..............3 Additional References .............. 4...
- Page 4 Precautions Two Axis angular displacement sensor is NOT 5 V tolerant. Requires 1.62 - 3.6 V regulated supply for proper operation. Don’t pull the sensor by the wires Don’t strain the sensor more than 15%...
- Page 5 Device Setup 1: Connect Two Axis sensor to the included trinket M0 as shown below: 2: Set up Trinket M0 Arduino IDE o Follow Adafruit’s guide found at https://learn.adafruit.com/adafruit- trinket-m0-circuitpython-arduino/arduino-ide-setup to get the Trinket M0 up and running in the Arduino IDE.
- Page 6 1: Click on tools and then Serial Plotter in the Arduino IDE or CTRL+SHIFT+L to verify that angular data coming from the Two Axis sensor is correct. (Note that touching the sensor while coupled to AC power can cause 60 Hz line noise).
- Page 7 Additional References Pin Diagram:...
