- Page 1 Technical Specifications ® DECTRIS EIGER 2 S 1M-RW Document Version v1.8.1 DECTRIS Ltd. 5405 Baden-Daettwil Switzerland www.dectris.com...
- Page 2 Document Version v1.8.1 © Copyright 2023 DECTRIS Ltd.
-
Page 3: Table Of Contents
EIGER2 S 1M-RW Detector ........ - Page 4 Cleaning and Maintenance ......... . 28 TROUBLESHOOTING ® DECTRIS EIGER 2 S 1M-RW Technical Specifications v1.8.1...
-
Page 5: Document History
Fixed EIGER2 vacuum operation and updated trademarks. v1.8.0 2022-03-22 Documenting new features from release 2022.1 v1.8.1 2023-02-10 Updated frame rates and 8 bit mode for X and XE systems. ® DECTRIS EIGER 2 S 1M-RW Technical Specifications v1.8.1 iii | 31... -
Page 6: General Information
1. GENERAL INFORMATION 1.1. Contact and Support Address: DECTRIS Ltd. Taefernweg 1 5405 Baden-Daettwil Switzerland Phone: +41 56 500 21 02 Fax: +41 56 500 21 01 Homepage: http://www.dectris.com/ Email: support@dectris.com Should you have questions concerning the system or its use, please contact us via telephone, mail or fax. -
Page 7: Warranty Information
(in particular information, images or ® materials), unless otherwise indicated. Without the written permission of DECTRIS it is prohibited to integrate the protected contents in this publication into other programs or other websites or to use them by any other means. -
Page 8: Use Of The Eiger2 S 1M-Rw
2. USE OF THE EIGER2 S 1M-RW The EIGER2 S 1M-RW hybrid-photon-counting (HPC) detector system has been designed for the detection of X-rays pro- duced by synchrotrons or laboratory sources. It is intended for indoor use only. For other applications, please contact ®... -
Page 9: Technical Specifications
114 mm x 133 mm x 242.2 mm Weight 4.7 kg Overvoltage category Means of protection I (power supply – Mean Well GST160A12) Pollution degree Single threshold. Using two thresholds halves the frame rate. ® DECTRIS EIGER 2 S 1M-RW Technical Specifications v1.8.1 4 | 31... -
Page 10: Ratings
Information Please consult the user documentation of the Mean Well GST160A12 power supply unit for details. Caution Only use the power supply delivered with the EIGER2 S 1M-RW. Table 3.3: Power Supply Unit Ratings Power supply unit power input 85 VAC to 264 VAC 47 Hz to 63 Hz 1 A to 1.85 A... -
Page 11: Detector Control Unit
Dimensions (W x H x D) 270 mm x 393 mm x 436 mm Weight 17.5 kg −1 Typical flow 3 L min Maximum operation pressure 3 bar ® DECTRIS EIGER 2 S 1M-RW Technical Specifications v1.8.1 6 | 31... -
Page 12: Ambient Conditions
The EIGER2 S 1M-RW detector is designed for indoor use only. The ambient conditions shown in table 3.6 must be satis- fied. The stated values are for the ambient conditions. -
Page 13: Detector Dimensions And Connectors
3D step files of the EIGER2 S 1M-RW detector are available on request. Please contact DECTRIS technical support for more information. Figure 4.1: Drawing of the EIGER2 S 1M-RW Detector (also printed separately in the user documentation folder) ® DECTRIS EIGER 2 S 1M-RW Technical Specifications v1.8.1... -
Page 14: Front Side Of The Detector
Do not apply any force on the screws, the screws do not need to be tightened to hold the cover in place and excessive force can damage the housing. Figure 4.2: The EIGER2 S 1M-RW Detector with the Cover Removed (front view) ®... -
Page 15: Back Side Of The Detector
4.1.3. Back Side of the Detector Figure 4.3: The EIGER2 S 1M-RW Detector (back view) ® DECTRIS EIGER 2 S 1M-RW Technical Specifications v1.8.1 10 | 31... -
Page 16: Status Leds
Do not replace the optical transceivers, as proper function of the detector system cannot be guaranteed otherwise. Please contact support@dectris.com if you need replacement transceivers. Caution There must be a 2 x LC/UPC duplex fiber optic con- nectors point-to-point connection between detector and detector control unit. -
Page 17: Detector Control Unit
Caution For in-vacuum operation do not use the standard con- nectors. A specific vacuum feedthrough set containing ® all required parts is available from DECTRIS 4.2. Detector Control Unit 4.2.1. Configuration Caution Do not access or modify the operating system of the detector control unit. - Page 18 All image data on the detector control unit will be permanently lost. Information Briefly pushing the power button on the front panel will shut down the detector control unit. May take up to 1 min. ® DECTRIS EIGER 2 S 1M-RW Technical Specifications v1.8.1 13 | 31...
-
Page 19: Connectors
DATA 2 -> det2 The unused data ports are closed with an EMI plug. Do not re- move the plugs. 2 x Power AC Connector (redundant power supply) ® DECTRIS EIGER 2 S 1M-RW Technical Specifications v1.8.1 14 | 31... -
Page 20: Thermal Stabilization Unit
See DELL owner’s manual for further details. 4.3. Thermal Stabilization Unit A thermal stabilization unit is required for the operation of the EIGER2 S 1M-RW detector system. The hoses and the detector are equipped with self-sealing valves to avoid dripping when connecting or disconnecting the tubes. -
Page 21: In-Vacuum Operation
Prior to powering up and operating the detector in-vacuum the thermal stabilization unit has to be set to a temperature of 17 °C for at least 30 min. ® DECTRIS EIGER 2 S 1M-RW Technical Specifications v1.8.1 16 | 31... -
Page 22: Installing The Detector System
Caution ® ® The screws holding the Mylar frame are close to the Mylar foil, be careful that the screw driver does not slip and damage the frame. ® DECTRIS EIGER 2 S 1M-RW Technical Specifications v1.8.1 17 | 31... - Page 23 For mechanical protection the cover can be mounted, but the sensors are still unprotected from humidity and dust. ® Figure 5.1: The EIGER2 S 1M-RW Detector without the cover and Mylar frame in place (front view). ®...
-
Page 24: Mounting
173200.M.00.L10 Freigegeben Title Date of Issue EIGER2 1M-RW Outline 05.10.2021 DECTRIS Ltd. Taefernweg 1 5405 Baden-Daettwil, Switzerland Comment / Item number Sheet We reserve all rights in connection with this 2 / 2 document. Without our agreement it may be neither copied nor made accessible to a third party. -
Page 25: Mounting From Below
The detector should be mounted using the four internal M6x1 threads as shown in figure 5.3 (indicated with yellow circles). Figure 5.3: Drawing of the EIGER2 S 1M-RW Detector Base Plate (also printed separately in the user documentation folder) Caution The four M6 screws must not intrude into the detector more than 10 mm. -
Page 26: Grounding Of The Detector
(see section 3.3). The EIGER2 S 1M-RW detector has to be connected to a dry air (or nitrogen) source to avoid humidity and condensation damage when it is outside of the storage box. For information on system connections, refer to the section 4.1.5 and for storage of the detector system refer to the section 7.5. -
Page 27: In-Vacuum Use
The EIGER2 S 1M-RW is delivered with a 30 m long optical fiber cable. The connection to the detector consists of 2 x LC/UPC duplex fiber optic connectors. -
Page 28: Checking The Connection
The EIGER2 S 1M-RW detector is water-cooled and must be connected to a dedicated thermal stabilization unit. The detector is supplied with quick coupling connectors to connect the cooling tubes to the thermal stabilization unit. Optional 90°-angled connectors can also be supplied. -
Page 29: Mounting The Detector Control Unit
The mains plug of the detector control unit has to be connected to a grounded power outlet. The detector control unit can be mounted in a standard 19 inch rack, which has to be properly grounded. ® DECTRIS EIGER 2 S 1M-RW Technical Specifications v1.8.1... -
Page 30: Temperature And Humidity Control
6. TEMPERATURE AND HUMIDITY CONTROL The EIGER2 S 1M-RW detector has a combined temperature and humidity sensor. The temperature and humidity control shuts down the detector when the humidity or the temperature of the sensor exceeds the following limits: Table 6.1: Temperature and Humidity Limits... -
Page 31: Operation Procedure
• Do not remove the nitrogen/dry air connection. It is a requirement that it is left at the recommended flow rate according to section 5.5. Warning As long as the detector power cable is connected, the detector has to be considered under power. ® DECTRIS EIGER 2 S 1M-RW Technical Specifications v1.8.1 26 | 31... -
Page 32: Vacuum Operation
To see if a detector is vacuum compatible, check whether the vacuum compatibility option is included in the order confir- ® mation received from DECTRIS 7.4.1. Ambient Conditions for In-Vacuum Use For in-vacuum operation of the detector following conditions must be fulfilled: Table 7.1: In-Vacuum Operating Conditions... -
Page 33: Storing The Detector
The detector housing can be cleaned with a soft tissue. The EIGER2 S 1M-RW detector does not require any maintenance. The coolant liquid has to be replaced every 12 months. For information on the coolant liquid, see section 4.3. -
Page 34: Troubleshooting
Table 8.1 provides an overview of possible problems with the detector system and instructions in order to solve the problems. If the problem you are experiencing is not listed below or if the instructions do not help, please contact support@dectris.com. - Page 35 Ambient humidity around the detector Shut down the detector immediately exceeds the operating conditions. and check the humidity. Power up the detector only when the ambient hu- midity has been reduced. ® DECTRIS EIGER 2 S 1M-RW Technical Specifications v1.8.1 30 | 31...
- Page 36 ”DECTRIS INSTANT RETRIGGER”, ”DECTRIS MYTHEN”, ”DECTRIS PILATUS”, ”DECTRIS QUADRO”, ”DECTRIS SANTIS”, ”DECTRIS SÄNTIS”, ”DECTRIS SINGLA”, ”DECTRIS TITLIS”, ”DETECTING THE FUTURE” © 2/ 2023 DECTRIS Ltd., all rights reserved • Subject to technical modifications. ® DECTRIS EIGER 2 S 1M-RW Technical Specifications v1.8.1...
