Canadian Timber Collection Granby Cabin Assembly Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Canadian Timber
Granby
Cabin Assembly Instructions
Requirements:
2 People (recommended)
Rubber Mallet
Carpenter's Level
Tape Measure
Cordless Drill
Phillips & Robertson Drill Bits
2" (51mm) hole saw
¼" (6mm) Nut Driver Bit
Step Ladder
Carpenter's Hammer
Utility Knife
It is highly recommended to view the assembly video prior to starting assembly!
View the assembly process
Manufactured by:
tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Granby Cabin and is the answer not in the manual?

Questions and answers

Related Manuals for Canadian Timber Collection Granby Cabin

Summary of Contents for Canadian Timber Collection Granby Cabin

  • Page 1 Canadian Timber Granby Cabin Assembly Instructions Requirements: 2 People (recommended) Rubber Mallet Carpenter’s Level Tape Measure Cordless Drill Phillips & Robertson Drill Bits 2” (51mm) hole saw ¼” (6mm) Nut Driver Bit Step Ladder Carpenter’s Hammer Utility Knife It is highly recommended to view the assembly video prior to starting assembly! View the assembly process Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...

  • Page 2: Parts List

    Canadian Timber Granby Cabin Assembly Instructions Parts List Part # Description Quantity 603317 2x6x62 -3/4" Headers for Floor (Marked) 603318 2x6x60" Floor Joists 603319 2x6x60" Flooring Boards 603321 60" Flooring Board (5" Wide) Marked Floor Starter 603325 71" Bottom Front Wall Starter Piece (with Door Cutout) 603327 71"...
  • Page 3 Canadian Timber Granby Cabin Assembly Instructions Index Parts List Base Preparation Cabin Assembly Roof Installation Bench Installation Electric Heater Installation (Option) Care &Maintenance Warranty Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 4 Canadian Timber Granby Cabin Assembly Instructions Sauna Base Preparation Make sure the base for your sauna is level with a slight slope to the back for drainage. A solid base for your sauna is recommended and can be made from any of the following.

  • Page 5: Cabin Assembly

    Canadian Timber Granby Cabin Assembly Instructions Cabin Assembly Start the assembly of your Granby Cabin by laying out the front and back base plates and the 7 – base supports. The front and back pieces will be “marked” where each of the base supports will be placed.
  • Page 6 Canadian Timber Granby Cabin Assembly Instructions Cabin Assembly To start the assembly of the floor, locate the stave that is labelled “ Floor Starter” Ensure the “floor Starter” stave is flush with the inside of the front and side base plates.
  • Page 7 Canadian Timber Granby Cabin Assembly Instructions Cabin Assembly Repeat this process until all the floor staves have been placed. Place 3 -3” (76mm) screws into each of the side supports. Locate the wall stave labelled “Door”. Fasten the front starter door stave with 2 - 3” (76mm) screws to secure it to the floor.
  • Page 8 Canadian Timber Granby Cabin Assembly Instructions Cabin Assembly Repeat this process for the rear starter stave. Place one of the wall staves across the front and rear of the sauna and using the provided “hit block” tap it so the groove goes tight into the starter staves.
  • Page 9 Canadian Timber Granby Cabin Assembly Instructions Cabin Assembly Continue with the front wall by placing one of the short wall staves on both ends and tapping them so the groove goes tight on to the front starter stave and secure it with a 5” (127mm) screw into each notch.
  • Page 10 Canadian Timber Granby Cabin Assembly Instructions Cabin Assembly Repeat the process with 1 of the short wall staves on each side on the front of the sauna. Continue alternating the side wall staves and the front and back wall staves one more row and then insert the door in between the front wall staves.
  • Page 11 Canadian Timber Granby Cabin Assembly Instructions Cabin Assembly Place the gable ends onto the front and rear walls and tap tightly into the staves below then secure with 5” (127mm) screws into the ends in the pre drilled holes. Place the center roof support beam into the slots on the top of the triangle pieces.

  • Page 12: Roof Assembly

    Canadian Timber Granby Cabin Assembly Instructions Roof Assembly To start the assembly of the roof, locate the 2 roof starter pieces. This is 2 boards wide with a notch cut out. Align the notch with the edge of the triangle pieces and use 2 –...
  • Page 13 Canadian Timber Granby Cabin Assembly Instructions Roof Assembly Secure the front trim pieces to the roof staves on either side with 3 – 2 ½” (64mm) screws per trim piece ensuring they are flush to the roof. Repeat on the back side of the sauna.
  • Page 14 Canadian Timber Granby Cabin Assembly Instructions Roof Assembly Overlap the panels one ridge and continue securing to the roof with a full shingle then a half shingle. Repeat the above step with the 2 and 3 row of shingles. For the 3rd row, use the thinner shingles.
  • Page 15 Canadian Timber Granby Cabin Assembly Instructions Install the outer door handle (small) at the desired height using 2 – 2 ½” (64mm) screws in the pre-drilled holes. Install the inner door handle (large) horizontally at the desired height. Ensure the handle is level and secure using 2 –...

  • Page 16: Bench Assembly

    Canadian Timber Granby Cabin Assembly Instructions Bench Assembly Start the assembly of your benches by placing the 2 tier bench support along the wall. Using a pencil, trace the top and front of the upper and lower bench. Mount one of the wall mount bench brackets flush to the line on the upper bench and secure with 3 –...
  • Page 17 Canadian Timber Granby Cabin Assembly Instructions Bench Assembly Repeat the process for the bottom bench. Screw the bench supports to the floor and back wall using 2” (51mm) screws. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...

  • Page 18: Electric Heater Installation

    Canadian Timber Granby Cabin Assembly Instructions Electric Heater Installation Measure the width of the stove mounting holes. Measure the height of the mounting holes and add 6”. (152mm) Transfer the measurements to the back wall of sauna. Ensure the heater will be centered between the benches.
  • Page 19 Canadian Timber Granby Cabin Assembly Instructions Electric Heater Installation Hang the heater on the 2 screws and tighten to secure stove in position. Locate the pieces for your heater guard. Stand the 2 Assembled side pieces of the heater guard on edge with pre-drilled holes on the bottom.
  • Page 20 Canadian Timber Granby Cabin Assembly Instructions Electric Heater Installation Center the guard around the heater and secure to wall with the pre placed screws. Ensure the guard is level and secure the other side. Wash the layer of rock dust off of the sauna rocks before using them.

  • Page 21: Care And Maintenance

    Canadian Timber Granby Cabin Assembly Instructions Care & Maintenance Interior It is recommended to vacuum or sweep out the inside of your sauna frequently to remove dirt and other debris. Under normal conditions, a slight wash of the floor and benches with warm soapy water several times a year will maintain its cleanliness.

  • Page 22: Warranty

    Granby Cabin Assembly Instructions Warranty Canadian Timber Collection Saunas warrants our saunas against defects in materials and workmanship under normal/residential use for a period of three (3) years, as applicable, from the date of receipt of the product by the original end-user consumer. This warranty does not apply to normal wear and tear and/or natural weather conditions.
