USER's MANUAL
VESTA
VT525P/625P
FCC Information
NOTE:
This equipment has been tested and found to comply with
the limits for a Class B device ,pursuant to Part 15 of the
FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation, This equipment generates, uses and
can radiate radio frequency energy and if not installed and
used in
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vesta VT525P
Summary of Contents for Vesta VT525P
- Page 1 USER’s MANUAL VESTA VT525P/625P FCC Information NOTE: This equipment has been tested and found to comply with the limits for a Class B device ,pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a...
- Page 2 accordance with the instructions may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be checked by switching the equipment off and on, the user should correct the interference by one or more of the following measures.
-
Page 3: Installation Of Ups
when the input AC power is disconnected. CAUTION isk of electric shock,Battery Circuit is not isolated from AC input, hazardous voltage may exist between battery terminals and ground. Test before touching. It has a total harmonic distortion of 44% and maximum single Notice- harmonic of 32.4%.The UPS is designed to be for use with Computer loads only. - Page 4 INTRODUCING THE FRONT PANEL AND REAR PANEL AND ADDITIONAL PARTS Front Panel Explanation LED’s 1.Line ( Green LED remains at a standstill when Utility Normal . Green LED flashes every 3 seconds when Utility Failure . Green LED flashes every second when Battery Low .
- Page 5 IEC3203. Computer Interface True RS232 communication Protocol . 4. RJ11/RJ45 Jacks MODEM INTERNET/NET Work Protection 5. Site Wiring Fault Indicator : For 115Vac system only. 6. AC Fuse Holder. W/fuse VT525P/110Vac/6A VT525P/115Vac/6A VT525P/220Vac/4A VT525P/230Vac/4A VT625P/110Vac/8A VT625P/115Vac/8A VT625P/220Vac/6.5A VT625P/230Vac/6.5A Checklist When your UPS malfunctions during operation, you may check the list below for proper adjustment.
