3.2.3

GMAP 6.0 user interface

Introduction
The touchscreen provides the user interface for controlling the system and monitoring
procedures. An on-screen keyboard is displayed automatically when required.
The following sections describe the menus on the GMAP 6.0 user interface.
Sepax start menu
The following illustration shows the Sepax start menu that is shown after start-up.
1
Part
1
2
3
Home menu
The following illustration shows the Home menu that is shown after login.
Sepax C-Pro Operating Instructions 29350570 AE OM-3074
2
Description
Log in. For user login.
About. Displays system information.
Shutdown. Shuts down the system.
3 System description
3.2 Touchscreen user interface
3.2.3 GMAP 6.0 user interface
3
38
