Built in 59ltr Single Fan Oven
MSFO59X - Stainless Steel
MSFO59B - Black
Please read these instructions carefully before attempting to install or use this appliance.
We recommend that you keep these instructions in a safe place for future reference.
THE PERFECT BALANCE OF FUNCTION AND STYLE
LAUNDRY - DISHWASHING - COOKING - COOLING
Installation and Operating Instructions
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for montpellier MSFO59X
Summary of Contents for montpellier MSFO59X
- Page 1 LAUNDRY - DISHWASHING - COOKING - COOLING Installation and Operating Instructions Built in 59ltr Single Fan Oven MSFO59X - Stainless Steel MSFO59B - Black Please read these instructions carefully before attempting to install or use this appliance. We recommend that you keep these instructions in a safe place for future reference.
- Page 2 Welcome Thank you for choosing this Montpellier appliance. Our appliances have been designed to provide you with the best combination of style, reliability and performance to give you years of trouble-free use. You may be familiar with a similar product, but please take time to read these instructions carefully before installing or using your appliance to ensure you get the most from your purchase.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Safety Instructions............4 How to Save Energy............5 Unpacking.................5 Description of the Appliance..........6 Installation.................7 Operation.................9 Prior to First Use...............9 Mechanical Timer.............9 Oven.................10 Cleaning and Maintenance..........11 Operation in Case of Emergency ........13 Baking in the Oven............14 Technical Information.... -
Page 4: Safety Instructions
SAFET The appliance becomes very hot during operation. Take care not to touch the heating elements inside the oven. WARNING :Accessible parts may become hot during use. To avoid burns, young children should be kept away. The mains lead of adjacent appliances may be damaged by hobs or stuck between the oven doors , creating a short circuit , therefore keep them at a safe distance from the appliance. -
Page 5: How To Save Energy
HOW TO SAVE ENERGY Using energy in a responsible way not only saves money, but also helps the environment. So let's save energy! And this is how you can do it: Make use of residual heat from the oven. If the cooking time is greater than 40 minutes, switch off the oven 10 minutes before the end time. -
Page 6: Description Of The Appliance
DECRIPTION OF THE APPLIANCE 1 Temperature control knob Oven function selection knob 3 Oven temperature indicator light Oven door handle Mechanical timer & Manual Mode... -
Page 7: Installation
INSTALLATION INSTALLING THE OVEN The kitchen should be dry and have effective ventilation, according to the existing technical provisions. The mains lead behind the oven must be placed in such manner to avoid touching the back panel of the oven, because of the heat it develops during operation Remove any packaging materials (foils, artificial foam, nails, etc.) from the reach of children, as they can be dangerous. - Page 8 INSTALLATION 21.5 Electrical connection Warning! All electrical work must be carried out by a suitably qualified and authorised electrician. No changes to the the electricity supply should be carried out unless by a qualified person . Before attempting the connection, check whether the voltage indicated on the rating plate ●...
-
Page 9: Operation
Colour code L = exterior live wires (black or brown) N = neutral (blue) Ensure correct N-connection! E = earth (green/yellow) OPERATION Prior to first use eRemove packaging, clean the interior of the oven. eRemove and wash the oven fittings with warm water and washing-up liquid. eSwitch on the ventilation in the room, or open a window. -
Page 10: Oven
4. The oven will then begin to heat up. 5. The timer will sound at the end of the cooking time. Caution! DO NOT turn the mechanical timer clockwise from 120 to � Manual Cooking Operation When cooking without the need for the mechanical timer, set the timer knob to the "Hand" position. Using manual control overrides the timer therefore the oven will not automatically turn itself off. -
Page 11: Cleaning And Maintenance
CLEANING AND MAINTENANCE Oven Shelf Levels Baking pans and accessories (oven grid, baking tray, etc) may be inserted into the oven in 5 positions. Appropriate levels are indicated in the tables that follow. Always count levels from the bottom upwards! Picture used is for illustration purposes only By ensuring proper cleaning and maintenance of your oven you can have a significant influence on the continuing fault-free operation of your appliance. - Page 12 Replacement of the Oven Light Bulb Before any maintenance involving electrical parts , the appliance must be is begun disconnected from the power supply. If the oven has been in use, the oven allow cavity and the heating elements cool down before attempting any maintenance. Unscrew the protective cover.
-
Page 13: Operation In Case Of Emergency
Removal of the internal glass panel Unscrew and unfasten the plastic latch that is in the corner at the top of the door. Next take glass from second blocking mechanism. After cleaning, insert the glass panel and screw the blocking mechanism back into place OPERATION IN CASE OF EMERGENCY In the event of an emergency，you should:... -
Page 14: Baking In The Oven
PROBLEM REASON ACTION 1.The appliance does not work Break in power supply Check the household fuse box; if there is a blown fuse replace it with a new one Check if function knob/temperature Wrong function chosen knob is set to the correct position. 2.The oven lighting does not The bulb is loose or damaged Tighten or replace the faulty bulb... - Page 15 Cheesecake is undercooked Next time reduce the baking temperature and extend the baking time. Warnings regarding the baking tables • The tables indicate the temperature range. Always select lower temperature first. You can always increase the temperature if the item needs more baking. •...
- Page 16 As stainless steel dishes reflect the heat, they are not recommended. If you cover your roast or wrap it in foil, it will preserve its juices and the oven will remain clean. The roast will cook quicker if it is left uncovered. Large roasts can be placed ...
- Page 17 Grilling • Take extra precautions when grilling. Intensive heat from the infrared element makes the oven and the accessories extremely hot. Use protective gloves and barbecue tools. • Perforated roast may produce spurting of hot grease.U se long grill tongs to prevent skin burns and protect your eyes.
-
Page 18: Technical Information
Pork scrag end 1500 160-180 100-180 Pork knuckle 1000 160-180 120-160 Roast beef fillet 1500 190-200 40-80 TECHNICAL INFORMATION Model MSFO59X / MSFO59B Voltage rating 220-240V 50Hz Total power 2000W Top element Grill element 2000W Bottom element Circular element 1600W ... - Page 19 Your 2 year Manufacturer's guarantee THIS DOES NOT AFFECT YOUR STATUTORY RIGHTS. Your new Montpellier appliance carries a free guarantee which protects you against the cost of repairs during the first 24 months from date of purchase provided that: Any claim is accompanied by evidence of the model reference, model serial number and proof of purchase, such as a Sales Receipt, showing that the appliance was purchased within the 24 months prior to the date of claim.
- Page 20 Montpellier Domestic Appliances Ltd. Unit 1, Tewkesbury Retail Park, Northway Lane, Tewkesbury, Gloucestershire GL20 8JU www.montpellier-appliances.com The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
