Summary of Contents for TMS T DASH 1
-
Page 2: Table Of Contents
........................... - 13 - HANGE SETTINGS ............................. - 14 - IRMWARE UPDATE SCREENSAVER ............................- 15 - SPECIFICATIONS ............................- 15 - HANDLING PRECAUTIONS ......................... - 16 - DISCLAIMER .............................. - 16 - V1.10 TMS Products B.V. ©2023 - 1 -... -
Page 3: Introduction
White font = better than previous Green font = personal best • Advanced settings possible via Bluetooth In the box T DASH 1 including Quick start guide Accessories (not included) • Racelink Pro, MYLAPS #10C010 or Racelink Club #10C100 •... -
Page 4: Installation
M8 connector pin-out M8 circular sensor connector i.e.; Binder 718 series Brown = 12VDC Blue = Ground Black = CAN high White = CAN low V1.10 TMS Products B.V. ©2023 - 3 -... -
Page 5: Measurements
Do not install the T DASH in a place where it is in a spray of water in rainy racing conditions Power up System information Start up screen 2 seconds speed 2 seconds speed Diagnostics V1.10 TMS Products B.V. ©2023 - 4 -... -
Page 6: Racelink Diagnostics
The connected power voltage of the Racelink is shown here. Above 10V this number will turn green. When the Bluetooth icon appears, a T DASH app is connected to the T DASH V1.10 TMS Products B.V. ©2023 - 5 -... -
Page 7: Speedometer
‘Press to set laptrigger’ text shows in red font, GPS accuracy is too low to set a lap trigger. Make sure your Racelink (GPS antenna) has a clear view to the sky. V1.10 TMS Products B.V. ©2023 - 6 -... -
Page 8: Clear Laptrigger
When in lap timer mode, stand still and start a new session to go to the diagnostic screen first. Acknowledge Clear trigger After acknowledging the clear trigger. T DASH will ask to set the laptrigger again when you start driving and the T DASH is in Speedometer mode. V1.10 TMS Products B.V. ©2023 - 7 -... -
Page 9: Gps Lap Timer
Flags not active Like in high end race series, color coding is used to classify lap times: Best lap time (green) after 3 laps Faster lap than previous (white) Slower lap than previous (yellow) V1.10 TMS Products B.V. ©2023 - 8 -... -
Page 10: Start A New Free Practice Session
While in lap timer mode and as long as the up button is pushed the T-DASH will show the last lap times set. After power down the lap times list will be cleared. Last lap Recall laps Next session Oldest lap V1.10 TMS Products B.V. ©2023 - 9 -... -
Page 11: On Board Marshalling
T DASH cannot be guaranteed! Important: Always keep observing the marshal posts and personnel around the track. Pay extra attention to the marshal posts in above situations or when the T DASH doesn’t show any information! V1.10 TMS Products B.V. ©2023 - 10 -... -
Page 12: Available Marshalling Screens
Available marshalling screens Green Yellow flag Double yellow Full Course Yellow Red flag Blue flag Black flag Code 60 Safety car Checkered flag Behavior Mechanical V1.10 TMS Products B.V. ©2023 - 11 -... - Page 13 Slippery Rain White flag Standing start Rolling start Pit in left Pit in right Pit in closed Next slow Slow zone Virtual Safety Car V1.10 TMS Products B.V. ©2023 - 12 -...
-
Page 14: Settings
Only change this setting when you are an expert on CAN busses and also have set the Racelink CAN bus settings to the right value. ‘Unit’ Set display units to Metric (kilometers) or Imperial (miles). V1.10 TMS Products B.V. ©2023 - 13 -... -
Page 15: Firmware Update
After the update is finished, the T DASH will restart. The screen will be blank for a few seconds. After the update the Device version of the Firmware should be the same as the Available version. Go to settings > Current version > Firmware: V1.10 TMS Products B.V. ©2023 - 14 -... -
Page 16: Screensaver
Full Color 160 x 128 OLED 33.5 x 26.8mm 170 degree viewing angle CAN termination Yes, 120R. On request without. CAN baud rate 1Mb, adjustable CAN ID (flag ack) 0x201 hexadecimal, adjustable For USA, pending FCC approval V1.10 TMS Products B.V. ©2023 - 15 -... -
Page 17: Handling Precautions
The sale of products, services of goods governed under this publication are covered by TMS Products B.V. standard Terms and Conditions of Sales and can be found here: https://tmsproducts.com/terms-and-conditions/ Always keep observing the marshal posts and personnel around the track! TMS Products B.V.
