54cm 4* Icebox Fridge
MRF54W/BK White & Black
Please read these instructions carefully before attempting to install or use this appliance.
We recommend that you keep these instructions in a safe place for future reference.
THE PERFECT BALANCE OF FUNCTION AND STYLE
THE PERFECT BALANCE OF FUNCTION AND STYLE
LAUNDRY - DISHWASHING - COOKING - COOLING
LAUNDRY - DISHWASHING - COOKING - COOLING
Installation and Operating Instructions
Installation and Operating Instructions
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for montpellier MRF54W
Summary of Contents for montpellier MRF54W
- Page 1 Installation and Operating Instructions Installation and Operating Instructions 54cm 4* Icebox Fridge MRF54W/BK White & Black Please read these instructions carefully before attempting to install or use this appliance. We recommend that you keep these instructions in a safe place for future reference.
- Page 2 Welcome Thank you for choosing this Montpellier appliance. Our appliances have been designed to provide you with the best combination of style, reliability and performance to give you years of trouble-free use. You may be familiar with a similar product, but please take time to read these instructions carefully before installing or using your appliance to ensure you get the most from your purchase.
-
Page 3: Table Of Contents
CONTENTS 1 SAFETY INSTRUCTIONS ................4 1.1 General Safety Warnings ....................4 1.2 Installation warnings .......................8 1.3 During Usage........................8 2 DESCRIPTION OF THE APPLIANCE ............10 2.1 Dimensions ........................11 3 USING THE APPLIANCE ................12 3.1 Thermostat Setting .......................12 3.2 Temperature Settings Warnings ...................13 3.3 Accessories ........................14 3.3.1 Ice Tray (In some models) ..................14 3.3.2 The Plastic Scraper (In some models) ..............14... -
Page 4: Safety Instructions
1 SAFETY INSTRUCTIONS 1.1 General Safety Warnings Read this user manual carefully. WARNING: Make sure that the appliance is left to stand for a minimum of 4 hours before being turned on for the first time. WARNING: Keep ventilation openings in the appliance enclosure or in the built-in structure clear of obstruction. - Page 5 If your appliance uses R600a as a refrigerant (this information will be provided on the label of the cooler) you should take care during transportation and installation to prevent the cooler elements from being damaged. R600a is an environmentally friendly and natural gas, but it is explosive.
- Page 6 • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
- Page 7 To avoid contamination of food, please respect the following instructions: • Opening the door for long periods can cause a significant increase of the temperature in the compartments of the appliance. • Clean regularly surfaces that can come in contact with food and accessible drainage systems •...
-
Page 8: Installation Warnings
1.2 Installation warnings performance of your refrigerator. • Clearance of at least 150 mm is required Before using your refrigerator for the first at the top of your appliance. Do not place time, please pay attention to the following anything on top of your appliance. points: •... - Page 9 Packaging and the Environment high alcohol content vertically in the fridge compartment and make sure their Packaging materials protect tops are tightly closed. your machine from damage that • When removing ice from the ice-making may occur during transportation. compartment, do not touch it. Ice may The packaging materials are cause frost burns and/or cuts.
-
Page 10: Description Of The Appliance
2 DESCRIPTION OF THE Freezer Compartment (Freezer): Most Efficient use of energy is ensured in the APPLIANCE configuration with the drawers and bins are on stock position. This appliance is not intended to be used as a built-in appliance. This presentation is only for information about the parts of the appliance. -
Page 11: Dimensions
2.1 Dimensions Overall dimensions the height, width and depth of the appliance without the handle. Overall space required in use 658,5 Space required in use 1134,5 the height, width and depth of the appliance including the handle, plus the space necessary for free 692,8 circulation of the cooling air, plus the height, width and depth of the... -
Page 12: Using The Appliance
3 USING THE APPLIANCE Thermostat settings: 1 – 2 : For short-term storage of food “Door Open” Indicator; 3 – 4 : For long-term storage of food The "Door Open" indicator on the handle 5 : Maximum cooling position. The shows whether the door has closed properly appliance will work longer.If required, or whether it remains open. -
Page 13: Temperature Settings Warnings
Winter Switch: If ambiant temperature Super switch is below 16 C, this switch shall be used (In some models) as winter switch and it keeps your fridge above 0 C while freezer is below -18 C in low ambiants. 3.2 Temperature Settings Warnings •... -
Page 14: Accessories
3.3 Accessories not place warm foods in fridge.Place them when they are cool, otherwise the Visual and text descriptions in the temperature/humidity inside the fridge will accessories section may vary according increases, reducing the fridge’s efficiency. to the model of your appliance. •... -
Page 15: Freezer Compartment
4.2 Freezer Compartment iced and rotted, bacterial load increases above 8 °C, and spoils. • The freezer is used for storing frozen • Do not put hot food in the refrigerator food, freezing fresh food, and making ice immediately, wait for the temperature cubes. - Page 16 • If the freezer door has been left open for pose a danger to your health and cause a long time or not closed properly, frost problems such as food poisoning. will form and can prevent efficient air NOTE: If you attempt to open the freezer circulation.
-
Page 17: Cleaning And Maintenance
Maximum storage time Vegetables and Fruits Preparation (months) Cut the stem, cut into two pieces, remove the core Pepper 8 - 10 and boil in water Spinach Wash and boil in water 6 - 9 Remove the leaves, cut the heart into pieces and Cauliflower 10 - 12 leave it in water with a little lemon juice for a while... -
Page 18: Defrosting
5.1 Defrosting process. Remove all dislodged frost from the cabinet floor. It is not necessary to Defrosting the Refrigerator switch off the appliance for the removal Compartment of thin frost. • For the removal of heavy ice deposits, disconnect the appliance from the mains supply, empty the contents into cardboard boxes and wrap in thick blankets or layers of paper to keep cool. -
Page 19: Shipment And Repositioning
to the mains supply and leave for 2 to • It is possible to change the opening 3 hours on setting number MAX before direction of the door on models with introducing the food back into the freezer. handle on the side of the door or without handles. -
Page 20: Tips For Saving Energy
tubes of the system. • The appliance you have purchased is designed for domestic use only. It is not Water flowing noise occurs: Due suitable for commercial or common use. to water flowing to the evaporation If the consumer uses the appliance in a container. -
Page 21: Technical Data
The technical information is situated in Visit our website to: the rating plate on the internal side of the www.montpellier-appliances.com appliance and on the energy label. The QR code on the energy label supplied with the appliance provides a web link to... -
Page 22: Product Information Sheeet
MRF54W/BK Model identifier: Type of refrigerating appliance: Low-noise appliance: Design type: freestanding Other refrigerating Wine storage appliance: appliance: General product parameters: Parameter Value Parameter Value Height 838 Overal dimensions Width 540 Total volume (dm³ or l) (millimetre) Depth 595 Energy efficiency class... - Page 23 Energy efficiency class Minimum duration of the guarantee offered by the manufacturer: 24 months Additional information: Weblink to the manufacturer's website, where the information in point4(a) Annex of Commission Regulation (EU) 2019/2019 is found: https://www.montpellier-appliances.com/ Page 2 / 2 EN - 23...
-
Page 24: Here For You
Your 2 year Manufacturer's guarantee THIS DOES NOT AFFECT YOUR STATUTORY RIGHTS. Your new Montpellier appliance carries a free guarantee which protects you against the cost of repairs during the first 24 months from date of purchase provided that: Any claim is accompanied by evidence of the model reference, model serial number and proof of purchase, such as a Sales Receipt, showing that the appliance was purchased within the 24 months prior to the date of claim. - Page 25 Montpellier Domestic Appliances Ltd. Unit 1, Tewkesbury Retail Park, Northway Lane, Tewkesbury, Gloucestershire GL20 8JU www.montpellier-appliances.com The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
