- Page 1 PSR4000 PSK4 PSK4 Flush SPK004 LED004 PSR4000 PSK4 PSK4 Flush SPK004 LED004 Owner’s Manual Digital Parking Sensor Systems V1.2...
-
Page 2: Kit Contents
The Parking Sensor Systems are used for the rear placement only, these are not recommended for front mounted bumpers. The use of Rydeen Parking Sensor system should never replace normal operational and safety precautions needed for reversing a vehicle. Caution should always be taken in ANY vehicle operation. -
Page 3: Technical Information
3) PSK4 Flush Extension Cable Sensor Wire 7.5ft 13ft O rings 4) SPK004 5) LED004 Speaker 3M Tape 10.5ft 2. Technical Information 1) Basic Specification Specifications Direction indicator (LED display is included ) Display Detecting distance 0- 8.0 feet for flat surfaces; 0- 4.0 feet for human or uneven surfaces Universal sensors. - Page 4 2) Wire Connection Diagram Sensor wire (7.5ft) Extension wire (13ft) 3) LED Display and Speaker Alarm Conditions Rear sensors (AL. BL. CR. DR./2RL. 2RR): Accurate display of distance and the correct sound tips Detection distance Display ( unit: feet) Distance (unit: feet/meter) Level definition Using buzzer only /Alarming sound...
- Page 5 3) Spray and paint Apply a thin coat of paint. Let it dry then paint again for better paint coating coverage. For PSR4000/PSK4 Paint the plastic rings together with the sensor heads. After Painting the sensors, let them completely dry before installing the silicon ring Depending on the vehicle body color , place white silicon rubber rings for a lighter color vehicle, place black rings for a dark color vehicle.
- Page 6 4. Sensor Head Angle Optional Take the silicone ring out if already installed Make sure that the degree marking is on the Insert the silicone top of the sensor ring into the sensor - 5 -...
- Page 7 5. Systems Overview For Passenger Cars Speaker/LED Display (2 options of sensor heads) The brain box is installed under the glove compartment - 6 -...
- Page 8 For Trucks Optional Distance Display LED004 (includes a speaker) /SPK004 (Speaker) The Control Box is not waterproof. It is recommended to place it under the driver sheet. There are 8 LED Display Options LED DISPLAY OPTIONS - 7 -...
-
Page 9: Installation
Three installation options ： a. 4 digital parking sensors for rear. (PSR4000) b. 2 digital parking sensors for front, 2 for rear. (PSR4000) c. 4 digital parking sensors for rear, 4 for front. PSR4000 and PSK4 /PSK4 Flush) - 8 -... - Page 10 (A) first to prevent from paint to chip, then drill the hole in clockwise direction PSR4000/PSK4 sensors MUST be installed from outside of the bumper. Please check the direction dot (WHITE) and make sure of the correct orientation.
- Page 11 PSK4 Flush sensors MUST be installed inside the bumper plastic skin and only the sensor head to exposed to outside. Bumper removal is required for this installation. Top view 5) It is important not to drill the hole larger than the measurement indicated. MUST use the hole saw provided.
- Page 12 Programming the Control Box with a Spare Tire or Bicycle in Back of Vehicle In case the vehicle carrying a spare tire or a bicycle, the control unit can be pre- adjusted to indicate the alternative STOP position. There are five adjustment levels (0.5 feet for each level): 0.0(level 0 as Default) =>1.0(level 1, -0.5 feet) =>2.0 (level 2, -1 feet) =>3.0(level 3, -1.5 feet) =>4.0(level 4, -2 feet) =>5.0(level 5, OFF) =>...
-
Page 13: Technical Support Contact Info
(Parking Sensor Systems) only to the original purchaser as described by the following: Warranty Peri od Rydeen warrants this product for a period of one (1) year from the original purchase date. Warranty Coverage This warranty covers all defects in material and workmanship except as specified below. - Page 14 2701 Plaza Del Amo, Suite 705, Torrance, California 90503 USA Phone: 1-877-777-8811 Fax: 1-310-943-3778 Copyright © 2014 Rydeen North America Inc. All Rights Reserved. These materials are protected by copyright law and international treaties. Any unauthorized use, reproduction or distribution of these materials, or any portion...
