Quick Guide
Roughneck AI V2360W-12-1
Outdoor Panoramic Camera
XX318-70-06
Cybersecurity Notification:
accessing the device. To that end, these network cameras do not have a default password. A user defined
password with minimum password strength requirements must be set to access the device. See page 13 of
this Quick Guide for set-up instructions.
Be sure to check Vicon's website to be see if you have the most up-to-date camera firmware.
Vicon Industries Inc. does not warrant that the functions contained in this equipment will
meet your requirements or that the operation will be entirely error free or perform precisely as
described in the documentation. This system has not been designed to be used in
life-critical situations and must not be used for this purpose.
Document Number: 8009-8318-70-06 Product specifications subject to change without notice.
Issued: 2/2023 Copyright © 2023 Vicon Industries Inc. All rights reserved.
All network connected devices should use best practices for
Vicon Industries Inc.
Tel: 631-952-2288) Fax: 631-951-2288
Toll Free: 800-645-9116
24-Hour Technical Support: 800-34-VICON
UK: 44/(0) 1489-566300
www.vicon-security.com
(800-348-4266)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vicon Roughneck AI V2360W-12-1
Summary of Contents for Vicon Roughneck AI V2360W-12-1
- Page 1 See page 13 of this Quick Guide for set-up instructions. Be sure to check Vicon’s website to be see if you have the most up-to-date camera firmware. Vicon Industries Inc.
-
Page 2: Table Of Contents
V2360W-12-1 Panoramic Fisheye | Quick Guide Table of Contents Product Overview Physical Characteristics Installation, Mounting and Connections Package Contents Installation 2.2.1 Checking Appearance 2.2.2 Mounting Camera Connection Network System Requirements Connecting Process 3.3.1 Accessing the Camera 3.3.2 Connecting from a Computer PRONTO Device Manager... - Page 3 V2360W-12-1 Panoramic Fisheye Series | Quick Guide WARNING This camera operates at 12 VDC/24 VAC/PoE+ (IEEE 802.3at Class 4). Installation and service should be performed only by qualified and experienced technicians and comply with all local codes and rules to maintain your warranty. We are NOT liable of any damage arising either directly or indirectly from inappropriate installation which ...
- Page 4 V2360W-12-1 Panoramic Fisheye | Quick Guide FCC Compliance Statement Information to the user: This unit has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
-
Page 5: Product Overview
V2360W-12-1 Panoramic Fisheye Series | Quick Guide 1 Product Overview 1.1 Physical Characteristics 56.99 (2.2) Ø150 (5) Figure 1 - 1: Physical Dimension Unit: mm (in.) - Page 6 V2360W-12-1 Panoramic Fisheye | Quick Guide Outer View Figure 1 - 2: Outer View Pictorial Index Name Description Dome Cover The upper dome-shape cover provides protection Lens The proprietary fisheye lens provides wide hemispheric view Cabling Cutout The cutout hole for cables threading Microphone Vent The hole for built-in microphone to receive audio input Loosen the 2 screws to open the side cap to access inner...
- Page 7 V2360W-12-1 Panoramic Fisheye Series | Quick Guide Inner View Figure 1 - 3: Inner View Pictorial Index Interface Description Connect to several external devices for audio and alarm input/output DI/DO Terminal Ports functions, which can expand usability of camera for a variety of field applications.
- Page 8 V2360W-12-1 Panoramic Fisheye | Quick Guide Name Port AU/I AUDIO IN AU/O AUDIO OUT AL/I ALARM IN AL/O ALARM OUT AL/C Table 1 - 3: I/O Port Definitions Note Power supply terminal/adaptor for IO connectors and field wiring should comply with the Class 2 Circuit standard for ensuring safety from electrical fires and providing acceptable protection against electrical shock.
-
Page 9: Installation, Mounting And Connections
V2360W-12-1 Panoramic Fisheye Series | Quick Guide 2 Installation, Mounting and Connections Package Contents Check if all items listed below are included in the packing box. Network Fisheye Camera * 1 Flat Bracket * 1 Safety Wire * 1 ... -
Page 10: Mounting Camera
V2360W-12-1 Panoramic Fisheye | Quick Guide 2.2.2 Mounting Camera Attach the Guide Pattern to the mounting surface. Drill 4 relative holes on a clean flat surface (ceiling or wall). Insert 4 plastic anchors into the drilled holes. Attach the flat bracket onto the surface by fixing it tightly with the 4 screws (TP4). Be sure to plug the drilled holes with the 4 plastic anchors prior to securing the bracket with the screws. - Page 11 V2360W-12-1 Panoramic Fisheye Series | Quick Guide Attach the rear side of camera to the fixed flat bracket and align the 3 screws with the corresponding holes on the bracket as shown in figure below. Rotate the camera clockwise until it clicks into place so that camera will be firmly mounted onto the bracket.
- Page 12 V2360W-12-1 Panoramic Fisheye | Quick Guide Security Lock After mounting the camera onto the flat bracket, bolt the security lock by fastening the security screw counterclockwise, as the figure shown below, so that camera will be mounted to bracket securely. To disassemble camera from flat bracket, loosen the security screw clockwise first.
-
Page 13: Connection
V2360W-12-1 Panoramic Fisheye Series | Quick Guide 3 Connection Network The camera, which is equipped with Ethernet RJ-45 network interface, can deliver live view image in real time via both Internet and Intranet manners. Review the topology drawings shown below. System Requirements The table below lists the minimum requirement to implement and operate the camera. -
Page 14: Connecting Process
The camera can be accessed directly from its web page or using Vicon’s PRONTO Device Manager, which can be found on Vicon’s website. Note that when accessing the camera for the first time, a message will display to reset the password. -
Page 15: Pronto Device Manager
V2360W-12-1 Panoramic Fisheye Series | Quick Guide PRONTO Device Manager PRONTO is Vicon’s device manager (Discovery tool) that can be used to discover all Vicon cameras on a system. The complete User Manual can be found on Vicon’s website. Figure 3 - 2: PRONTO Interface Upon startup of the PRONTO Device Manager, the tool’s auto-discovery function generates a list of...
