Gorenje NRS8182KX Detailed Instructions For Use

Upright refrigerator and freezer
Hide thumbs
Table of Contents

Advertisement

Quick Links

EN
DETAILED
INSTRUCTIONS FOR USE
OF UPRIGHT
REFRIGERATOR AND
FREEZER
www.gorenje.com
www.gorenje.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NRS8182KX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Gorenje NRS8182KX

Summary of Contents for Gorenje NRS8182KX

  • Page 1 DETAILED INSTRUCTIONS FOR USE OF UPRIGHT REFRIGERATOR AND FREEZER www.gorenje.com www.gorenje.com...
  • Page 2 Please visit our website where you can enter your appliance model number, indicated on the rating plate or the warranty sheet, to find detailed description of your appliance, tips on use, troubleshooting, service information, instructions for use etc. http://www.gorenje.com Important safety warning...

  • Page 3: Table Of Contents

    CONTENTS INTRODUCTION 4 IMPORTANT NOTES AND PRECAUTIONS 4 SAFETY AND WARNING INFORMATION APPLIANCE 11 INSTALLING YOUR NEW APPLIANCE DESCRIPTION 17 APPLIANCE DESCRIPTION 18 OPERATING THE APPLIANCE 20 USING YOUR APPLIANCE 24 HELPFUL HINTS AND TIPS DEFROSTING AND CLEANING 25 CLEANING AND CARE THE APPLIANCE MISCELLANEOUS 28 TROUBLESHOOTING...

  • Page 4: Important Notes And Precautions

    IMPORTANT NOTES AND PRECAUTIONS SAFETY AND WARNING INFORMATION For your safety and correct usage, before installing and first using the appliance, read this user manual carefully, including its hints and warnings. To avoid unnecessary mistakes and accidents, it is important to make sure that all people using the appliance are thoroughly familiar with its operation and safety features.
  • Page 5 According to IEC standard This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. •...
  • Page 6 • WARNING — Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance. • WARNING — If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. •...
  • Page 7 flammable. During transportation and installation of the appliance, ensure that none of the components of the refrigerant circuit becomes damaged. The refrigerant (R600a) is flammable. • WARNING — Refrigerators contain refrigerant andgases in the insulation. Refrigerant and gases must be disposed of professionally as they may cause eye injuries or ignition.
  • Page 8 • You must not operate the appliance without the interior lighting lamp cover. • The fridge is only applied with power supply of single phase alternating current of 220~240V/50Hz. If fluctuation of voltage in the district of user is so large that the voltage exceeds the above scope, for safety sake, be sure to apply A.C.
  • Page 9 • Keep buring candles,lamps and other items with naked flames away from the appliance so that do not set the appliance on fire. • The appliance is intended for keeping food stuff and/ or beverages in normal household as explained in this instruction booklet The appliance is heavy.Care should be taken when moving it.
  • Page 10 Installation Important! • For electrical connection carefully, follow the instructions given in this manual. • Unpack the appliance and check if there are damages on it. Do not connect the appliance if it is damaged. Report possible damages immediately to the place you bought it.

  • Page 11: Installing Your New Appliance

    INSTALLING YOUR NEW APPLIANCE • Before using the appliance for the first time, you should review the following tips. Ventilation of appliance Install the appliance in a plane and stable surface. Assure good ventilation. We recommend letting a space at least: - 50 -70mm from the back to the wall - 100mm from the top to the wall - 100mm from its side to the wall...
  • Page 12 Leveling of appliance • For sufficient leveling and air circulating in the lower rear section of the appliance, the bottom feet may need to be adjusted, You can adjust them by your fingers or a suitable spanner. • To allow the doors to self-close, tilt the top backwards by 10-15 mm. Adjustable bottom feet Adjustable Rear roller...
  • Page 13 Warning! For proper installation, this refrigerator must be placed on a level surface of hard material that is the same height as the rest of the flooring. This surface should be strong enough to support a fully loaded refrigerator. The rollers, which are not castors, should be only used for forward or backward movement.
  • Page 14 Disassembling the doors Some models may be slightly different from pictures. If some parts show in the picture cannot found in your appliance, please ignore the relevant description. Since the steps to disassemble the fridge door are similar to the freezer door, the instructions below are only for disassembling the freezer door except step 2.
  • Page 15 3. Remove the 3 screws fixed on the hinge with a Wrench (8mm). Then remove the upper hinge. 4. Open the freezer door for a small angle, then lift it up with both hands and take it off. Be careful of racks while remove the door.
  • Page 16 5. Remove all shelves and drawers inside the appliance. Tip the refrigerator backwards, remove the screws fixed on the hinge with a Wrench. Then remove the lower hinge. Re-attach the door You could re-attach the door in reverse order of disassembling the door.

  • Page 17: Appliance Description

    APPLIANCE DESCRIPTION 9 10 1. Freezer door 10. Fridge wind channel part 2. Freezer glass shelf 11. Upper fridge rack 3. Freezer rack 12. Fridge glass shelf 4. Freezer wind channel part 13. Fridge rack 5. Freezer drawer cover 14. Fridge door 6.

  • Page 18: Operating The Appliance

    OPERATING THE APPLIANCE Use your appliance according to the following control guidelines, your product has a control panel as shown in the diagram below. Controlling the temperature We recommend that when you start your refrigerator for the first time, the temperature for the refrigerator is set to 4°C and the freezer to 18°C.
  • Page 19 3. Mode Holiday If you are going to be away for a long period of time, you can activate this function. Important! Do not store any food in the fridge during this time. Super Freeze Super Freeze will quickly lower the temperature within the freezer so food will freeze faster.

  • Page 20: Using Your Appliance

    USING YOUR APPLIANCE This section tells you how to use most of the useful features. We recommend that you read through them carefully besfore using the appliance. Using your refrigerator compartment The refrigerator compartment is suitable for storage of vegetables and fruit. Food inside shall be pasked to store in order to avoid losing muisture or flavor permeating into the foods.
  • Page 21 Drawers These are suitable for storage of fruits and vegetable. And it can be taken out to be cleaned. Using your freezer compartment The freezer compartment is suitable for storage of foods required to be frozen, such as meat, fish, ice cream and other perishable items. Caution! Ensure that bottles are not left in the freezer for longer than needed as freezing may cause the bootles to break.
  • Page 22 Order Compartments Target storage Appropriate food TYPE temp.[°C] Fridge +2 ≤ +8 Eggs, cooked food, packaged food, fruits and vegetables, dairy products, cakes, Drinks and other foods which are not suitable for freezing. (***)* – ≤ –18 Seafood (fish, shrimp, shellfish), Freezer freshwater aquatic products and meat products (recommended...
  • Page 23 –2 ≤ +3 Chill Fresh/frozen pork, beef, chicken, freshwater aquatic products, etc. (7 days below 0 °C and above 0 °C is recommended for consumption within that day, preferably no more than 2 days). Seafood (less than 0 for 15 days, it is not recommended to store above 0 °C) Fresh Food 0 ≤...

  • Page 24: Helpful Hints And Tips

    HELPFUL HINTS AND TIPS Energy saving tips We recommend that you follow the tips below to save energy. • Try to avoid keeping the door open for long periods. • Ensure the appliance is away from any sources of heat (Direct sunlight, electric oven or cooker etc.) •...

  • Page 25: Cleaning And Care

    CLEANING AND CARE For hygienic reasons the appliance (including exterior and interior accessories) should be cleaned regularly (at least every two months). Warning! The appliance must not be connected to the mains during cleaning. Danger of electrical shock! Before cleaning switch the appliance off and remove the plug from the mains socket.
  • Page 26 Thoroughly dry all surfaces and removable parts before putting them back into place. Although this appliance automatically defrosts, a layer of frost may occur on the freezer compartment’s interior walls if the freezer door is opened frequently or kept open too long. If the frost is too thick, choose a time when the freezer is nearly empty and proceed as follow: 1.
  • Page 27 Warning! Do not use sharp objects to remove frost from the freezer compartment. Only after the interior is completely dry should the appliance be switched back on and plugged back into the mains socket. Door seals cleaning Take care to keep door seals clean. Sticky food and drinks can cause seals to stick to the cabinet and tear when you open the door.

  • Page 28: Troubleshooting

    TROUBLESHOOTING If you experience a problem with your appliance or are concerned that the appliance is not functioning correctly, you can carry out some easy checks before calling for service, please see below. You can carry out some easy checks according to this section before calling for service. Warning! Don't try to repair the appliance yourself.
  • Page 29 Problem: Possible cause & Solution It is normal to frequently hear the sound of the motor, it will need to run more during following circumstances: • Temperature setting is set colder than necessary. The motor runs • Large quantity of warm food has recently been continuously stored within the appliance.
  • Page 30 Problem: Possible cause & Solution • The LED light may be damaged. Refer to replace LED lights in cleaning and care chapter. The light is not • The control system has disabled the lights due working to the door being kept open too long, close and reopen the door to reactivate the lights.

  • Page 31: Disposal Of The Appliance

    Gorenje, d.o.o. Partizanska 12 SI - 3320 Velenje, Slovenija info@gorenje.com...
