Pent Shed Assembly Manual
Pressure Treated Tanalised Timber for Longer Lasting Life!
Ready To Build - 6ft Range
Thank you for purchasing your Total Shed.
All of our sheds are made from only the finest selected timber which are
(Tanalised), specially pressure treated for a longer and lasting durable life
span to the elements.
Each shed is carefully packed and delivered on a pallet
ready to be assembled.
FEATURES NEW FLEXIBLE,
INTER-CHANGEABLE DESIGN
FOR YOUR INDIVIDUAL STYLE.
2 Persons Recommended for Assembling Shed
Tools Required:
DRILL DRIVER
HAMMER
HAND SAW
PLEASE NOTE: Use extreme caution when using any tools. Always wear safety gear where
necessary. It is advisable that at least 2 or more persons assemble the shed for health and safety
purposes. We are not responsible for any injuries caused whilst assembling this shed.
Ready to Build Shed
Featured Build of the Pent 7ft x 6ft Shed
Includes 4x6ft to 20x6ft Instructions
STANLEY KNIFE
Total Sheds
Unit 1 Park Lane,
West Bromwich, B21 8LE
Tel: 01902 636 529
Email: info@totalsheds.co.uk
Version 1.4
DELIVERED FLAT PACKED IN
EASY TO INSTALL SECTIONS
www.totalsheds.co.uk
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for total sheds Pent Shed 7ft x 6ft
Summary of Contents for total sheds Pent Shed 7ft x 6ft
- Page 1 Pent Shed Assembly Manual Pressure Treated Tanalised Timber for Longer Lasting Life! Ready To Build - 6ft Range Total Sheds Unit 1 Park Lane, West Bromwich, B21 8LE Tel: 01902 636 529 Email: info@totalsheds.co.uk Version 1.4 Thank you for purchasing your Total Shed.
-
Page 2: Pre-Assembly
PRE-ASSEMBLY STEP • 1 Unpacking your Parts Recommended: Paint shed in an oil based treatment to Unpack all of the components and check that prevent water ingress into you have all the parts required. Please use the checklist on previous page. the timber. - Page 3 STEP • 2 STEP • 3 IMPORTANT 2ft RIGHT SIDE PANEL All Sheds With 4 or Place first panel againts More Floor Pannels far right of shed floor have the smallest Floor as shown. Panel on the Right End. (2ft wide blank panel) As shown on this diagram.
- Page 4 STEP • 4 STEP • 5 4ft SIDE PANEL SIDE & REAR PANELS Place second panel againts Fix 4ft Wide Blank far right of shed floor as Sections. Create a Corner shown. (4ft wide blank for Balance. panel) 4ft SIDE PANEL SIDE &...
-
Page 5: Left Side Panel
STEP • 6 STEP • 7 LEFT SIDE PANEL 3ft REAR PANEL Fix 3ft Wide Blank Section Fix 2ft and 4ft Wide Blank Back Panel 3ft Section Panel (Left) (This panel might be 4ft depending on the shed ) 3ft REAR PANEL LEFT PANEL 6a. - Page 6 STEP • 8 STEP • 9 FRONT DOOR PANEL FRONT WINDOW PANEL Attach Door Front Panel Attach Front (3ft Door Panel) Window Panel (This panel might be 4ft depending on the (4ft Window Panel) shed ) FRONT DOOR PANEL 4ft FRONT WINDOW PANEL 8a.
- Page 7 STEP • 10 STEP •11 SIDE PENT ANGLE TOPS PENT FRONT TOPS Now attach all the 6ft Place the front tops of shed in relation to the Side Tops of Pent Shed End Panels. (Over the top fronts panels of both side panels). 6ft SIDE PENT ANGLE TOPS PENT FRONT TOPS 11a.
- Page 8 STEP • 12 STEP •13 PENT ROOF PANELS SIDE & CORNER STRIPS Hide the panel edges. Place 4ft Roof section. Cover the framework & Repeat for all Roof Panels seams. PENT ROOF PANELS SIDE & CORNER STRIPS 13b. Fix the strips down by using 3 screws to secure 13a.
- Page 9 15b. Using a hammer, tack down the felt with the tacks provided in a neat fashion. Example: Pent Shed 7ft x 6ft The 7 by 6 needs 3 sheets of felt. All at 8ft each. Build Depth 4ft (x2)
- Page 10 ATTACH FELT STRIPS DIAMOND CAPS Create the Final Roof Add the Finishing Edges. Final steps Touch. (Optional) finishing off the roof. Total Sheds Unit 1 Park Lane, West Bromwich, B21 8LE Tel: 01902 636 529 Email: info@totalsheds.co.uk FELT STRIPS DIAMOND CAPS 16a.
