OWI AMP04TRP Specifications

AMPLIFIED SPEAKER:
TRUMPET
OWI Incorporated
®
17141 Kingsview Avenue, Carson, CA 90746 USA
Tel: 310.515.1900
Toll Free: 800.638.1694
Fax: 310.515.1606
Web: www.owi-inc.com
E-mail: info@owi-inc.com
GENERAL SPECIFICATIONS
MODEL NUMBER:
POWER:
FREQUENCY RESPONSE: 20 Hz - 30 kHz +0-2 dB
NOISE FLOOR:
DISTORTION:
INPUT:
INPUT CONFIGURATION:
VOLUME CONTROL:
PROTECTION:
MAXIMUM POWER
SUPPLY WIRE LENGTH:
MULTIPLE AMPLIFIERS:
EACH AMPLIFIER
MAY POWER:
INPUT/OUTPUT:
CONNECTOR TYPE:
CONDUIT ENTRY:
TYPICAL LINE LEVEL
SOURCES:
HOOK UP FOR
ADDITIONAL HORNS:
FOR FOUR HORNS:
POWER SUPPLY:
COLOR:
ARCHITECTS AND ENGINEERS
SPECIFICATIONS / TECHNICAL DATA
AMP04TRP
25 Watts
Better than 90 dB
Better than .1% at 10 Watts
Line Input -10 to +4 dB
Differential, Balanced
DC Isolated
Step for Mechanical Level Memory
Short Circuit, Heat and
Over Current
400 Ft. with 16 Gauge Wire
Yes, Line Input In Parallel
Four Speaker Total per Amp
Each Amplifier has a Line Level
Input and Output
Phoenix Connector
Two 1/2" Conduit Access Holes
with Knock Outs
CD Player, Audio Mixer, Background
Music Service, Telephone PBX
Dry Audio Pair Hooked to the
Balanced +,- Input. There is No
Shield on a Telephone Input.
Wired through the Conduit Entry,
Use the 4 Way Binding Posts for
Additional High Level Speakers
Hooked up to the Amplifier.
Wire them Series Parallel to
Achieve a 4 Ohm Load Impedance
12 Volts
White
