Door removal
In order to gain easier access to the oven cavity for cleaning and maintenance purposes, the
door can be removed.
To remove the door, first tilt the safety catch part of the hinge upwards. Gently close the door
approximately halfway, lift the door and pull it out towards you.
Follow these steps in reverse to replace the door.
When replacing the door, ensure that the notch of the hinge (see illustration) inserts into the
hinge slot in the cavity frame. Once the door has been re-fitted, remember to lower down the
safety catch. Failure to do this may damage the hinge when closing the door.
Tilting the hinge safety catches
Inner glass panel removal
Remove the screw from either side of the metal top trim (see illustration). Slide the trim
towards you to remove it.
Lift the edge of the inner glass slightly and then slide it from its lower clips. The middle glass
panel can then also be removed. Follow these steps in reverse to replace the glass.
Removal of the internal glass panel
Door removal
24
Troubleshooting
In the event of an emergency, you should:
Switch off the power to the oven from the mains.
Please refer to the troubleshooting guide below to see if the issue can be resolved
before requesting a service.
POSSIBLE CAUSE(S)
PROBLEM
No power.
The oven doesn't work.
No function has been set.
The display flashes "00:00".
The oven was disconnected from
the mains or there was a power
cut.
The bulb is loose, damaged or
The oven lighting doesn't
defective.
work.
When a fault, conflict or other fault occurs, some error codes are displayed in the time
display area.The meanings are as follows:
DISPLAY ERROR
No temperature sensor/open
E01
circuit
Temperature sensor short
E02
circuit
E04
Abnormal communication
If the suggestions above do not resolve your issue, please contact Customer Care to
arrange a repair.
Important: All repairs must be carried out by qualified personnel.
ACTION(S) TO TAKE
Check the fuse, replace if
blown.
Check the mains supply is
switched on.
Ensure a function has been
selected and temperature set.
Set the current time (see
"Setting the clock").
Replace the bulb (see
"Replacing the oven light
bulb").
POSSIBLE CAUSE(S)
The control board detects that there is no
temperature sensor, the oven will stop
heating .
The temperature is below -15°C.
A short circuit of the sensor is detected
and the oven stops heating.
The communication between the power
module and the display module is abnormal
