Summary of Contents for Hobot LEGEE-D8
- Page 1 Vacuum Mop ECO Compactor User Manual ECO COMPACTOR™ TANGLESS™ SUCTION HSSPL™ MOPPING...
-
Page 2: Table Of Contents
Table of Contents Important Safety Instructions --------------------------------------------------------------------- - 1 - Laser Safety -------------------------------------------------------------------------------------------- - 2 - Copyright & Trademarks ---------------------------------------------------------------------------- - 3 - Disclaimer ---------------------------------------------------------------------------------------------- - 3 - Limited Warranty ------------------------------------------------------------------------------------- - 3 - Product Overview ------------------------------------------------------------------------------------ - 4 - Installation --------------------------------------------------------------------------------------------- - 6 - App Instructions -------------------------------------------------------------------------------------- - 7 - Maintenance ------------------------------------------------------------------------------------------ - 8 -... -
Page 3: Laser Safety
Replace the whole unit if it is damaged or exposed to high moisture. Consult local HOBOT dealer for help and maintenance. Make sure the device, power adapter and charging station are not trapped under heavy objects. -
Page 4: Copyright & Trademarks
Copyright & Trademarks Copyright © 2022 by HOBOT® Technology Inc. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of this company. -
Page 5: Product Overview
Product Overview TOP VIEW LiDAR Sensor Bumper Control Buttons/LED Indicator Start/Pause Cleaning Home Stop Cleaning/Child Lock (Press 3sec.) Switch Talent Clean Modes FDS Array Sensors Orange Battery Charging Orange Flashing Low Battery Green Battery Fully Charged Blue Wet Mopping White Dry Mopping White Flashing Connecting... - Page 6 BOTTOM VIEW Side Brush Front Cliff Sensors Universal Wheel Charging Contacts Front Suction Brushroll Spray Nozzles Caterpillar Belts Rear Cliff Sensors Auto Lifting Mopping Pad TRASH BIN Screen Filter Release Latch Dust Sheet Compressor/Scraper High Efficiency Filter CHARGING STATION Charging Indicator Blue Stand-by Blue Flashing...
-
Page 7: Installation
Installation Important Notes Before Cleaning Put away objects including wires, cloths, slippers, fragile objects…etc. on the floor to improve cleaning efficiency and safety. 1. Position the Charging Station Peel off the backings paper from the bottom of the charging station and keep the charging station on a level surface, flat against a wall. -
Page 8: App Instructions
HOBOT account. When you log into your HOBOT account on another smartphone, HOBOT account will help you to link to the devices associated to your account and retrieve the data stored on your device for you. -
Page 9: Maintenance
Maintenance Please maintain LEGEE according to the following guidelines for optimum performance; contact a local retailer or authorized dealer for additional consumable spare parts. Part Care Frequency Replacement Condition* Trash Bin & Screen Clean as needed Filter When it is too dirty (when the App shows High Efficiency Filter Clean as needed that the trash bin is full even after you’ve... - Page 10 Side Brush Pull off the side brush If necessary, rinse the side Reinstall the side brush. from the device and brush with warm water to Push down until you hear remove any tangled hair clean dirt off and restore a click sound. or debris.
- Page 11 Ag+ion Cleaning Cloth You can wash the cleaning cloth in two ways: Wash under 40°C (104°F) Hand washing: Thoroughly wash the cloth with warm water and general-purpose laundry Do not bleach detergent. Do not tumble dry Do not iron. Washing machine: Wash using the warm cycle, then air dry.
-
Page 12: Common Issues (Faq)
Universal Wheel Pull up the universal wheel and clear the hair, rinse and dry when needed. Spray Nozzle Test the spray nozzles using the button in the App To unclog the spray nozzle: To replace the spray nozzle: Clean the spray nozzle with Use a screwdriver to loosen Replace the old nozzles... - Page 13 obstacles. - Please check if there are virtual barriers blocking the way so LEGEE considered the task completed. - Check if you have only chosen specific rooms instead of the entire house for the current cleaning task. Place the charging station in an open space or clear the objects around it and clean the sensors with clean dry cloth.
- Page 14 The sound frequency at which a human can hear ranges between 20 Hz to 20,000 Hz, you are likely to hear buzzing noises amplified from your charger. All power adapters or transformers will make a buzzing sound to some degree, the device may still be used without any concern as there is no need to worry from a safety point of view.
-
Page 15: Product Specifications And Accessories
If any problems occur and this manual cannot provide the solution you need, please contact a local retailer or authorized dealer. Product Specifications and Accessories Model LEGEE-D8 LEGEE-D8 Wi-Fi 802.11a/b/g/n/bt Charging station Dimensions (L × W × H) 344 ×...
