Intelbras Twibi Giga - Wireless Mesh Router Installation Guide
- User manual (27 pages)
Advertisement
Download the Wi-Fi Control Home app
Before you start installing Twibi, download the Wi-Fi Control Home app in the App Store® or Google® Play. You can search for the app on the store or read the QR Code below.
Connecting a Twibi to your modem
- Connect one end of the network cable on your modem (LAN port) and the other end on the Twibi's WAN port;
- Connect the power supply to the Twibi and then plug it into the electrical outlet.
Connect your smartphone to Twibi
Go to your device's Wi-Fi network list and search for the Twibi Wi-Fi network. By default, the network has no password, just click on it to connect.
Configuring Twibi
Open the Wi-Fi Control Home app and follow the steps to set up your Twibi. When it is properly connected to the internet, the LED will turn green.
Adding another Twibi
- Position the new Twibi up to 15 meters from another already installed Twibi;
- Connect the power supply to the Twibi and then plug it into the electrical outlet;
- Hold on 1 minute until the product LED starts flashing in blue color and open the Wi-Fi Control Home app. A screen should displayed informing you that a new Twibi has been found, click on Allow to add Twibi to your network.
![]()
Note: if the screen above does not appear, click on Settings and then on Add Twibi, follow the displayed steps to add the new Twibi to your network.
Meaning of LED
Note: if you have not yet set up your Twibi, it will be flashing in blue color for a period and then it will turn red. Follow the steps described here in the guide to configure your Twibi.
Frequently asked questions
| How do I restore a Twibi to factory default? | Plug in the Twibi into the outlet and hold on for it to start, grab the reset button for 10 seconds until the LED turns grey. |
| Can I add another Twibi? | We recommend using a maximum of 6 Twibis for a good network performance, however, more Twibis can be used. To add a new Twibi to your network, just follow the steps of item Adding another Twibi |
| How to access the web management page? | Twibi does not have a web management interface, all configuration is done using the Wi-Fi Control Home app |
| What is the coverage area of Twibi Giga? | Each Twibi Giga covers an area of up to 180 m². Add more modules if you want to cover a larger area. |
| How many devices can I connect to the Mesh system? | Twibi Giga's Mesh system supports up to 60 devices. |
| Can I connect the Twibi Giga's Mesh system via cable? | Yes, Twibi Giga's Mesh system allows you to make the connection between Twibis via cable. This connection is known as Ethernet backhaul. |
| How can I clean my Twibi? | We recommend cleaning Twibi with the combination of damp cloth + neutral soap. |
Technical specifications
Hardware
2 internal antennas of 3 dBi
1 WAN/LAN gigabit port
1 LAN gigabit port
Chipset Realtek® RTL8197FS+RTL8812BR+RTL8363
16 MB flash Memory
RAM memory 128 MB
Wireless parameters
Power supply
Attention: this equipment is not entitled to protection from harmful interference and shall not cause interference in duly authorized systems.
