Summary of Contents for TAWI Light60
- Page 1 TAWI Lightweight Lifting Trolley This is the original version of the TAWI High Frequency Lifter user manual.
- Page 2 TAWI AB Address: Transportgatan 1, 434 23 Kungsbacka, Sweden This declaration is applicable only if the product(s) has/have been installed according to TAWI’s instructions and provided that the product(s) has/have not been modified in any way. Signature: Place and date:...
-
Page 3: Table Of Contents
Contents Safety & important information WEEE, RoHS and REACH Do not make modifications Markings and labels on the TAWI Light Trolley 2 Warranty 3 Overview Loading 4 Assembly Unpacking Mounting 5 User instructions Start the lifter Charge the battery Battery charging indicator... -
Page 4: Safety & Important Information
1 Safety & important information This chapter presents safety information about the TAWI Light Trolley lifter (hereafter referred to as lifters). Some of the information is divided in Warning, Caution and Important. This division is based on the severity of the consequences that may occur if the instructions are not followed. Stickers and labels are explained in this chapter and information is provided about directives that TAWI follows. - Page 5 During all service and maintenance, lay the lifter down on the floor (on its back). • In order to deal with the lifter’s cables and wiring, a good knowledge of electricity and TAWI elec- trical schedules of the lifters is required. Faults can cause damage to people and property.
- Page 6 Children should be supervised to ensure that they do not play with the lifters. • Use only TAWI original spare parts. • Always follow any local/national recommendations as well as the instructions in this manual.
-
Page 7: Weee, Rohs And Reach
Appropriate changes to the capaci- ty stickers, labels and user manual must be made, see Markings and labels on the TAWI Light Trolley. A permanent and visible label must be fastened on the lifter that states how the lifter has been modified/ altered together with the date it was performed. - Page 8 Labels on TAWI Light Trolley Do not use as a passenger lift! Do not Risk of hands and feet getting caught stand underneath a raised tool. in machine! Do not put hands or fingers on the mast or close to the sleigh or belt.
-
Page 9: Warranty
This chapter presents warranty information about the TAWI Light Trolley . If a TAWI Light Trolley is used according to all instructions in this manual it will perform well for many years. TAWI offers a one year limited guarantee, excluding transportation charges, provided that the lifter has been used under normal working conditions (one shift and then recharged) and in accordance with the instructions in this manual. -
Page 10: Overview
3 Overview a. Mast Rear wheels with brakes b. Control panel g. Battery charging indicator c. Emergency stop h. Handle d. Leg Platform e. Identification plate Front wheels Page 10... -
Page 11: Loading
Description Specifications Lifting capacity 60kg Min/max lifting height 120mm - 1705mm Weight of unit 35kg Total height of unit 1980mm Battery charger 100-240V, 40W, 50-60Hz Battery 2x12V 7Ah Lifts per charge 60kg x 1m x 100 times Up and down motions Push buttons Front wheels Swiveling... -
Page 12: Assembly
4 Assembly This chapter presents what comes in the package and how to assemble the trolley and fasten the tool. The following images shows how to fasten the legs and the platform to the base unit. Unpacking a. 1 x Base unit b. -
Page 13: Mounting
Mounting Following is images of how to fasten the legs and the platform. The following images shows how to fasten the legs and the platform to the base unit.vthe legs and the platform to the base unit. 1. Fasten the legs 2. -
Page 14: User Instructions
5 User instructions This chapter describes how to operate the TAWI Light Lifting Trolley. Start the lifter • The lifter can be stopped at any time by pressing the emergency stop on the control panel. • Only run the lifter when it is completely assembled. -
Page 15: Battery Charging Indicator
• The lifter can be switched on or off when charging the battery. It is recommended that the lifter is switched off when not in use. • To make sure not to damage the cord when pulling it out of the electrical outlet - grab, and apply the force to the plug. -
Page 16: Brakes
Service must be carried out on a yearly basis. • If any damage/wear is detected on the lifter, this must immediately be reported to TAWI or au- thorisedTAWI representative. The lifter must be taken out of commission and not be used until the damage has been repaired. -
Page 17: Inspections
Double check (carry out) all daily inspections mentioned in Daily inspections by operator. 2. Check all screws and nuts for damage/wear. Yearly inspections by TAWI authorised service technician Check that CE mark and serial number on the identification plate are visible. -
Page 18: Troubleshoot
7 Troubleshoot This chapter provides information on how to investigate or rectify problems that may occur. Actions marked with (*) must be carried out by PIAB or a TAWI authorised service technician. Problem Likely caused by Action required Main switch is turned off. - Page 19 1. Platform surface 4305349 2. Platform frame 4305348 3. Lifting belt 4305344 4. Battery 4305296 5. Front wheel 4305308 6. Rear wheel 4305235 7. Emergency stop 4305294 8. Up/down button 4305297 9. Top cover 4305360 10. Motor 4305301 11. Limit switch module 4305320 12.
- Page 20 TAWI AB Box 102 05 Transportgatan 1 434 23 Kungsbacka Tel: +46 (0) 300 -185 00 la.info@piab.com tawi.com A brand by Piab Group...
