Replacing Air Intake Temperature
Sensor
Copyright © 2017 Huawei Technologies Co., Ltd. All rights reserved.
Step 1 Open the rear door;
Step 2 Remove the air f lters;
Step 3 Use a Phillips screwdriver to remove
the R-shaped pipe clip that secures the air
intake
temperature sensor on the rear door post, as
shown in Figure;
Step 4 Remove the waterproof connector from
the sensor cable;
Step 5 Secure a new air intake temperature
sensor to the original position using the R-
shaped pipe
clip;
Step 6 Reconnect the waterproof connector to
the sensor cable;
Step 7 Install the air f lters. For details, see 5.5
Follow-up Procedure;
Step 8 Close and lock the rear door.
