- Page 1 Operating Instructions & Service Manual Football Scoreboard Model MP-3499R With MP-3000R Radio Control EFFECTIVE S.N. 16,775 August 17, 2000...
-
Page 2: Table Of Contents
TABLE OF CONTENTS PAGE GENERAL INFORMATION DESCRIPTION IDENTIFICATION DAMAGE DAMAGE CLAIM PROCEDURE CARE OF EQUIPMENT INSTALLATION GENERAL INFORMATION INSPECTION PRE-TEST INSTALLATION ELECTRICAL CONNECTIONS CONTROL CONSOLE OPERATION TIMER POWER CONSOLE DISPLAY CONSOLE POWER TIME SETTING AND CONTROL DIMMER OPERATION MAINTENANCE AND TROUBLESHOOTING INTRODUCTION TEST EQUIPMENT TROUBLESHOOTING... -
Page 3: General Information
GENERAL INFORMATION 1.1 Description Your All American Scoreboard has been carefully inspected and tested before leaving the factory. It is possible, however, that components may be loosened or forced out of adjustment in transit. If this occurs, follow the troubleshooting guide (section 4). If equipment then fails to operate, contact immediately: ALL AMERICAN Service Department EVERBRITE Corporation P.O. -
Page 4: Installation
If damage is discovered after delivery, you should call the delivery company. Have them make out a Concealed Damage Report. Fifteen days after delivery are allowed, so this should be done PROMPTLY or it is impossible to process this claim. Advise EVERBRITE corporation of necessary replacement parts or repairs. -
Page 5: Control Console Operation
NOTE To protect the control from damage, it is advisable that you disconnect the control and store in a dry secure area when not in use. NOTE This equipment is ETL (Electronics Testing Laboratories) CSA and NRTL approved and complies with the requirements in part 15 of the FCC rules for a class A computing device. Operation of this equipment in a residential area may cause unacceptable interference to radio and television reception, requiring the operator to take whatever steps are necessary to correct the interference. -
Page 6: Time Setting And Control
A = 0 B = 0 The timer display will now show “00” . Time Setting and Control The control console can store two preset time periods. One or both of these time periods must be set each time the console is turned on. To set a 45 second, and a 5 second period, key in the following: Push SET A ENTER . -
Page 7: Maintenance And Troubleshooting
MAINTENANCE AND TROUBLESHOOTING 4.1 Introduction This section gives maintenance and troubleshooting information. Included are troubleshooting guides for typical scoreboard malfunctions. If the cause of a problem cannot be determined, please contact the Customer Service Department. 4.2 Test Equipment A simple analog or digital voltmeter will be sufficient for all user repairable problems. Printed circuit boards requiring troubleshooting should be returned to the factory. - Page 8 (c) If the continuity test checks good, check the voltage between the green wire and the white wire in the junction box, using a voltmeter set on the 12 VAC or higher scale. If the voltage is 0 VAC see the controller parts list for a transformer assembly. If the voltage is less than 8 VAC consult the controller wiring diagram for instructions on long cable compensation.
-
Page 9: Replacement Parts List
REPLACEMENT PARTS 5.1 Scoreboard Display Parts figure 1 DISPLAY ASSEMBLY s:\shared\stacey\scoreboard manuals\incomplete manuals\mp-3499r.indd 401 South Main Street • Pardeeville, WI 53954 • 800-356-8146 07/31/02... - Page 10 REPLACEMENT PARTS LIST (MP-3499R D.O.G. Timer) fig.& MFG PART VENDOR fig.& MFG PART VENDOR index NUMBER DESCRIPTION PART # index NUMBER DESCRIPTION PART # 159056X Display Assy, MP-3499R 159056X 850027 Lamp, 40W/130V IF 40A19IF 150624X Controller Assembly, MP-3499R 150624X *****SEE DETAIL FIGURE 2***** SU00038 Fuse box Assy.
-
Page 11: Scoreboard Controller Assembly Parts
5.2 Scoreboard Controller Assembly Parts figure 2 CONTROLLER ASSEMBLY REPLACEMENT PARTS LIST (MP-3499R) Controller Assembly fig.& MFG PART VENDOR fig.& MFG PART VENDOR index NUMBER DESCRIPTION PART # index NUMBER DESCRIPTION PART # 150624X Controller Assembly 150624X 150040 Receiver PCB Assembly 150040 ***** PROGRAM DG_RCV.HEX ***** 118922... -
Page 12: Diagrams
DIAGRAMS 6.1 Control Console Keyboard and Slipsheet Layout CONSOLE KEYBOARD s:\shared\stacey\scoreboard manuals\incomplete manuals\mp-3499r.indd 401 South Main Street • Pardeeville, WI 53954 • 800-356-8146 07/31/02... - Page 13 6.2 Scoreboard System Layouts This is the normal setup. This setup requires an additional 5 Pin connector installed in the control and a hand held control with 10’ cable or 200’ cable. SYSTEM LAYOUT s:\shared\stacey\scoreboard manuals\incomplete manuals\mp-3499r.indd 401 South Main Street • Pardeeville, WI 53954 • 800-356-8146 07/31/02...
-
Page 14: Power Wiring
6.3 Power Wiring POWER WIRING s:\shared\stacey\scoreboard manuals\incomplete manuals\mp-3499r.indd 401 South Main Street • Pardeeville, WI 53954 • 800-356-8146 07/31/02... - Page 15 6.4 Controller Assembly Wiring CONTROLLER ASSEMBLY s:\shared\stacey\scoreboard manuals\incomplete manuals\mp-3499r.indd 401 South Main Street • Pardeeville, WI 53954 • 800-356-8146 07/31/02...
-
Page 16: Microprocessor 4X 7 Lamp Pattern (8 Bit)
6.5 Microprocesor 4 X 7 Lamp Pattern (8 Bit) MICROPROCESSOR 4 X 7 (8 BIT) LAMP PATTERN s:\shared\stacey\scoreboard manuals\incomplete manuals\mp-3499r.indd 401 South Main Street • Pardeeville, WI 53954 • 800-356-8146 07/31/02... -
Page 17: Figuregram Wiring Diagram
6.6 Figuregram Wiring FIGUREGRAM WIRING s:\shared\stacey\scoreboard manuals\incomplete manuals\mp-3499r.indd 401 South Main Street • Pardeeville, WI 53954 • 800-356-8146 07/31/02... - Page 18 6.7 Jumper Location on 3 Position System All of the 3 position drivers and receivers are identical except for the jumper on each board. Make sure the jumpers are set for the model of scoreboard you are installing them into. On the receiver board (refer to figure);...
-
Page 19: Triac Placement Diagram
6.8 Triac Placement The triac is the switch that controls the figuregram lamps. The triacs for any given figuregram are adjacent to the twelve pin connector on the driver board that controls that figuregram. Shown below is the triac placement and bit designation relative to the figuregram bit pattern. PN. -
Page 20: Installation Drawing
6.9 Installation Drawing 6" 36" 6" 1.25" 7" 28" 48" USE 1/2" DIA. HARDWARE (NOT FURNISHED) FOR MOUNTING THE SCOREBOARD DISPLAY INSTALLATION DRAWING s:\shared\stacey\scoreboard manuals\incomplete manuals\mp-3499r.indd 401 South Main Street • Pardeeville, WI 53954 • 800-356-8146 07/31/02...
