LOAA(Lab on An Array) Real-Time PCR Instrument
Instructions For Use
LAM301-01
LOAA Analyzer
For in vitro Diagnostic (IVD) Use
Page 1 / 47
IFU-3M001-EN-00 (2021.03.05)
