MM8301**E
CHAUMONT LED
ILLUMINATED MIRROR
900 X 600 X 55MM
LANDSCAPE
ALL ILLUSTRATIONS OF THE PRODUCT ARE FOR REFERENCE ONLY. COMPONENTS
SUPPLIED WITH INDIVIDUAL PRODUCTS MAY DIFFER
ALL PRODUCT DIMENSIONS DETAILED IN THIS INSTALLATION AND MAINTENANCE
CONTACT DETAILS (UK)
Croydex
Central Way
Andover
Hampshire
SP10 5AW
UK
ALWAYS CHECK THE PACKAGING FOR FIXINGS AND PARTS BEFORE RECYCLING OR
PLEASE READ THROUGH AND FULLY UNDERSTAND THE INSTRUCTION LEAFLET BEFORE
ENSURE YOU HAVE ALL THE FIXINGS AND PARTS BEFORE ATTEMPTING TO ASSEMBLE OR FIT
MANUAL ARE APPROXIMATE
Tel: +44 (0)1264 365881
Email: info@croydex.co.uk
Web: www.croydex.com
DISPOSAL.
STARTING THE INSTALLATION OF THIS MIRROR.
THIS PRODUCT.
1
PORTRAIT - LEFT
PORTRAIT - RIGHT
CONTACT DETAILS (EU)
MIL
Unit 8 Purcellsinch Ind Est
Dublin Road
Kilkenny
R95 HP71
Ireland
MIR 039 R07

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CHAUMONT MM8301 E Series and is the answer not in the manual?

Questions and answers

Related Manuals for Croydex CHAUMONT MM8301 E Series

Summary of Contents for Croydex CHAUMONT MM8301 E Series

  • Page 1 ALL PRODUCT DIMENSIONS DETAILED IN THIS INSTALLATION AND MAINTENANCE MANUAL ARE APPROXIMATE CONTACT DETAILS (UK) CONTACT DETAILS (EU) Croydex Tel: +44 (0)1264 365881 Central Way Unit 8 Purcellsinch Ind Est Email: info@croydex.co.uk Andover Dublin Road Hampshire Kilkenny Web: www.croydex.com SP10 5AW R95 HP71...

  • Page 2: Section 1 - Introduction

    SECTION 1 - INTRODUCTION Thank you for purchasing this Croydex product. Please follow the fixing and care instructions to ensure that your product is fitted safely and that it retains its high quality finish. PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE.
  • Page 3 WALL FIXING PACK x1 Wall Plugs x2 Countersink x2 Hang 'n' Lock x1 Pan-Head Screw Wall Plug Screw x1 L-Bracket x2 Rivet Plug Screws x1 L-Bracket x1 Hang 'n' Lock x2 Cam x2 Toggle Bolts Bracket - Left IMPORTANT WARRANTY INFORMATION In some circumstances the Building Regulations 2010 require the installer to give the occupier of the premises in which this product has been installed a certificate to confirm that the requirements of regulations 4 and 7 have been satisfied, or the installation of this product must...

  • Page 4: Section 2 - Mounting Using Hang 'N' Lock

    SECTION 2 - MOUNTING USING HANG 'N' LOCK Assemble the Hang ‘n’ Lock bracket fig. 2 sections making sure all parts are slotted tightly together. (See Fig. 2) Note: The Hang 'n' Lock bracket may vary in size. Place the Hang 'n' Lock bracket onto the fig.
  • Page 5 Drill the marked holes to a depth of 45mm. fig. 6 Insert the wall plugs level with the surface of If you are fitting to a tiled surface, the wall. insert the wall plugs below the surface of the tile to avoid cracking the tiles. Wall plugs (See supplied are for use on solid walls only.

  • Page 6: Section 3 - Side Rivet Cover

    Place the L bracket over the threaded fig. 10 rivet located at the bottom of the mirror. Using a pencil mark the position of the L bracket onto the wall. (See Fig. 10) Gently remove the mirror, place the L fig.

  • Page 7: Section 4 - Shaver Supply Unit

    SECTION 4 - SHAVER SUPPLY UNIT NOTE: The shaver supply unit is suitable for use with electric razors, toothbrushes and similar low power appliances only. Operation: Flip open socket cover and plug in desired device. SECTION 5 - TOGGLE BOLT INSTALLATION TOGGLE BOLT INSTALLATION During , if toggle bolts are used, follow the steps bellow:...

  • Page 8: Section 6 - Connecting The Electrical Supply

    SECTION 6 - CONNECTING THE ELECTRICAL SUPPLY REMOVE THE MIRROR FROM THE WALL. ENSURE THAT THE DOMESTIC ELECTRICAL MAINS SUPPLY TO WHICH THE MIRROR IS TO BE CONNECTED IS TURNED OFF. Connect the flexible mains supply cable on the mirror to the domestic electrical mains supply ensuring that: •...

  • Page 9: Section 8 - Technical Information

    The EU Low Voltage Directive (LVD) 2014/35/EU The EU Electromagnetic Compatibility (EMC) Directive 2014/30/EU The EU Restriction of Hazardous Substances (RoHS) Directive 2011/65/EU The following UKCA and CE Declarations of Conformity can be downloaded from www.croydex.com or requested from info@croydex.co.uk: UKCA electrical safety and EMC (UKCA-DoC-00001-Safety-EMC.pdf) UKCA RoHS (UKCA-DoC-00001-RoHS.pdf)
