Calibrating
Calibrating gathers information from all connected devices for
faster switching times. For the best experience, always perform
a calibration as soon as all devices are connected. The system
should also be calibrated after any new devices (source or zone
equipment) are added or port allocations changed. Failure to
correctly calibrate the system may cause interruption to zone
audio and video when other zones are switched to a source that
is already in use.
To calibrate your switch:
1
Manually power on all devices connected to the HDMI switch
inputs and outputs, and set them to the appropriate inputs.
2 In Composer Pro, click the Calibrate button on the driver's
Actions tab. This process may take several minutes,
depending on the number of devices connected. To view
calibration status, view the Calibration Status field on the
driver's Properties tab.
NOTE: Calibration forces all video outputs on the
HDMI switch to the lowest TV/display common
denominator. This calibration is bypassed when an
output zone is locked to a source.
More help
For the latest version of this guide and to view additional
materials, open the URL below or scan the QR code. Your device
must be able to view PDFs. A dealer login may be required.
MOST RECENT VERSION HDMI MATRIX QUICK START GUIDE
ctrl4.co/hdmisw-ig
control4.com | 888.400.4070
©2014, Control4 Corporation. All rights reserved. Control4, the Control4 logo, and the 4-ball logo, are registered trademarks or trademarks of
Control4 Corporation in the United States and/or other countries. All specifications subject to change without notice.
ctrl4.co/hdmisw-qsg
Troubleshooting
Resets
• Reboot—Disconnect the power adapter to reboot (power
cycle) the device.
Restore
• Factory Restore—Power off the HDMI switch, then press and
hold the ID button while reconnecting power. Continue to hold
the ID button until the Status (left-most) LED on the front
flashes rapidly. During the factory restore process, the Status
LED stays solid, and the Power (right-most) LED flashes
slowly.
Regulatory/Safety information
To review regulatory information for your particular Control4
products, see the information located on the Control4 website at:
www.control4.com/regulatory/.
Warranty
For complete warranty information, including details on
consumer legal rights as well as warranty exclusions, review the
Warranty card or visit www.control4.com/warranty.
200-00002-LEA-E 10/14/2014 DH
