Safety and Warnings / Sécurité et Avertissements..................................

Overview.............................................................................................................

Mustang Installation.........................................................................................

Mustang Operation...........................................................................................

Start-Up..............................................................................................

Sanitizing and Cleaning.......................................................................

Electrical Schematic............................................................................

Installation Schematics........................................................................

MUSTANG MANUAL.pub

CONTENTS

™

ATTENTION

Unplug the Dispenser's

power cord from the

electrical supply before

removing any covers, making

any adjustments, or

performing any service on

this dispenser.

Beverage Tower Dispenser

For Dispensers with model number

WB-MU-(A)-(B)-(1)-(2)

Wunder-Bar

Mustang Tower

(A) =01: Clamp with Front Display

02: Clamp with Front Display and Rear Display

03: Countertop Mount with Front Display

04: Countertop Mount with Front and Rear Display

(B) = 01: No Drain

02: Drain

(1)

= Number of Post-Mix BASE Beverages (0 to 8)

(2)

= Number of Flavor Concentrate Additives (0 to 8)

100-240 VAC, 50/60 Hz, 1.4A

PAGE NUMBER

3-4

5-9

10-11

12-15

16-17

19-24

REV071519

Need help?

Do you have a question about the WB-MU-02-01 and is the answer not in the manual?

Questions and answers

Summary of Contents for Wunder-Bar WB-MU-02-01

Page 1 Beverage Tower Dispenser For Dispensers with model number WB-MU-(A)-(B)-(1)-(2) Wunder-Bar Mustang Tower (A) =01: Clamp with Front Display 02: Clamp with Front Display and Rear Display 03: Countertop Mount with Front Display 04: Countertop Mount with Front and Rear Display...
Page 2 ™ ATTENTION! • Read all Instructions before setting up or operating the dispenser. • This dispenser is not to be used by persons (including children) with reduced physical, sensory, or mental capabilities, or lack of experience or knowledge, unless they have been given supervision or instruction.
Page 3 ™ 02-01 04-01 TOWERS WITH REAR DISPLAY WB-MU-02-01 (BAR CLAMP W/ REAR DISPLAY) WB-MU-04-01 (COUNTERTOP W/ REAR DISPLAY) The Mustang Tower can be configured to dispense 6 carbonated post-mix beverages, 2 non-carbonated beverages (tap water, carbonated water) and 2 Flavor Shots.
Page 4 ™ Fig. 1 PRE-INSTALLATION PLANNING GENERAL: Determine and confirm the appropriate location for mount- ing the Mustang Tower with the store manager. Typically, this will be the same location where all other soft-drink and beverage dispensers are located. MUSTANG TOWER WITH DRAIN FITTING: Ensure that the drain hose assembly is within distance of a drain according to federal, state, and local codes and regulations.
Page 5 7. Secure the Mustang Tower in place with the included hardware: 1/4 Washers and 1/4-20 Nuts. 8. Take the provided 1/4” Wire Loom (Wunder-Bar p/n MU-5K) and cut to appropriate length to cover any exposed threads. Cut any excess loom. (Fig. 5)
Page 6 5. Connect the water and syrup lines. 6. Take the provided 3/8” Wire Loom (Wunder-Bar p/n MU-3R-1) and cut them to length to cover the threaded rods so that they are not exposed. Make sure both sides of the threaded rods are covered.
Page 7 ™ ATTACHING THE REAR DISPLAY— CONFIG. -02-XX AND –04-XX Fig. 8 #29 Drill 1. The rear display can be attached to either base configuration and is sold as an add-on. 2. Unplug the power to the unit. 3. Remove the four (4) 6-32 screws securing the Rear Cover onto the Mustang Tower and the two (2) 4-40 screws near the Display Head.
Page 8 ™ ATTACHING THE REAR DISPLAY— CONFIG. –02-XX AND –04-XX 11. Connect the green connector with the label “Rear Display” with the green port on the display of the Rear Assembly. (Fig. 12) 12. Fish the end of the USB through the front of the solenoids, then down the slot on the bottom of the housing the same way the power cord and the Front Display USB are done.
Page 9 ™ ATTACHING THE DRAIN FITTING — CONFIG. XX-02 1. The drain feature can be attached to either configuration. Fig. 17 2. Set the Drip Tray Basin down. Drill a hole using a 53/64” size drill bit at the center of the countersunk portion. See Figure 17. 3.
Page 10 ™ OPERATING STANDARD Normal operation mode: 1. Initialization Connect the power supply harness to the power supply. Do not touch any area of the Touchscreen during the Startup Sequence. Fig. 21 2. Beverage dispensing (up to 8 Brands) for SELF-SERVE A.
Page 11 ™ OPERATING STANDARD Fig. 19 3. Beverage dispensing (up to 8 Brands) for CREW SERVE A. Press any brand to enter the Dispense Beverage Screen. B. Select and dispense the desired Beverage: Fig. 24 For systems with flavor additives: select the desired flavor, then press next.
Page 12 ™ CALIBRATION AND SETTING CHANGES: Flow rate calibration and certain setting changes are performed in the following mode: Fig. 28 1. Flow Calibration Mode: There are 4 “hidden” buttons on the Dispense Screen which must be entered in proper sequence to enter the Service Screen.
Page 13 ™ CALIBRATION AND SETTING CHANGES: Flow rate calibration and certain setting changes are performed in the following mode: Fig. 31 E. Press and hold the “Prime Dispense” Button to prime the lines. Make sure that air is purged completely from the line before moving on to the brix calibration.
Page 14 ™ ADJUST FLOW REGULATORS Fig. 34 1. To gain access to the syrup, carbonated water, and still water flow regulators, remove the four screws located on the front cover and set aside. (Fig. 34) Fig. 35 2. Lift the lower part of the cover up and away from the tower. (Fig. 35) 3.
Page 15 ™ ™ CALIBRATION AND SETTING CHANGES Fig. 37 3.Enabling/Disabling Multi-Flavor: A. Enter the service technician screen as detailed in the Flow Regulator and Calibration Settings Fig.32 section. B. Swipe the screen to the left to get to the second page and select the “Enable Multi-Flavor” feature if the unit can dispense multiple flavors at once.
Page 16 100 PPM chlorinating sanitizer solution when mixed with water. Examples of sanitizers with 100 PPM available chlorine are: Kay 5 Sanitizer (Wunder-Bar p/n Kay-5), by Kay Chemicals division of Ecolab, Inc., or B-T-F Chloromelamine Disinfectant (Wunder-Bar p/n CD-SA-8), by National Chemicals, Winona, MN.
Page 17 100 PPM chlorinating sanitizer solution when mixed with clean water. Examples of sanitizers with 100 PPM available chlorine are: Kay 5 Sanitizer (Wunder-Bar p/n Kay-5), by Kay Chemicals division of Ecolab, Inc., or B-T-F Chloromelamine Disinfectant, (Wunder-Bar p/n CD-SA-8) by National Chemicals, Winona, MN.
Page 18 ™...
Page 19 ™...
Page 20 ™...
Page 21 ™...
Page 22 ™...
Page 23 ™...
Page 24 ™...
