1 CAN-AP
®
Bluetooth
access point to the Wurm system
1.1
Front view
Fig. 1: Front view
1.2
Features
•
Access point to the CAN bus system
•
Wireless communication with mobile end devices using the Frida App and Bluetooth
Energy
•
Range of at least 10 metres, can be extended via several CAN-APs in a CAN bus system
•
Wall installation, e.g. in the sales room
•
One-key operation or operation via the Frida app
•
Dew-point driven integrated power controller for operation of glass and handrail heaters
•
Room temperature and humidity sensor signals via Wurm CAN communication bus
(C-BUS)
•
Heater control through CAN bus switch module BSM001 and ECA970
•
Connection of several heaters per channel
•
For all standard refrigeration units
•
8 different control characteristics per channel
•
Adjustable minimum operating time per channel
•
Logging of history data in an internal memory for evaluation with FRIGODATA
•
Enthalpy shift for rack controller DCC-XP from version 5 and DSC-XP
•
Connection to the Wurm system via C-BUS and FRIGODATA XP
Scope of supply
•
CAN-AP
•
Plug switching power supply
Version and validity of the documentation
Version
Date
V2.0.1
2022-11
Any versions not listed are special solutions for individual projects and are not described in detail in this document.
This document will automatically cease to be valid if a new technical description is issued.
Manufacturer: Wurm GmbH & Co. KG Elektronische Systeme, Morsbachtalstraße 30, D-42857 Remscheid
You can find more information on our website at
All trademarks hereby referenced are the property of their respective owners.
CAN-AP_V2.0.1_PI_2022-11_EN
Documentation status
www.wurm.de
Subject to technical changes
®
Bluetooth
access point to the Wurm system
®
Low
CAN-AP
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for WURM CAN-AP
Summary of Contents for WURM CAN-AP
- Page 1 Any versions not listed are special solutions for individual projects and are not described in detail in this document. This document will automatically cease to be valid if a new technical description is issued. Manufacturer: Wurm GmbH & Co. KG Elektronische Systeme, Morsbachtalstraße 30, D-42857 Remscheid You can find more information on our website at www.wurm.de...
- Page 2 Wurm GmbH & Co. KG Elektronische Systeme. Keep these instructions ready to hand for quick reference and pass them on with the device if the product is sold.
- Page 3 CAN-AP ® Bluetooth access point to the Wurm system MALFUNCTIONS DUE TO INCORRECT HANDLING! CAUTION • Keep the openings on the device clear. • Do not install the device above radiators, near windows or doors, on surfaces that are exposed to strong vibrations or direct sunlight, on exterior walls, on chimneys, or in walls or alcoves.
- Page 4 CAN-AP ® Bluetooth access point to the Wurm system Connection diagram 74451223A CAN-AP C-Bus C-Bus Power DC 1 2 3 4 D Fig. 3: Connection diagram C-BUS connection via RJ45 socket C-BUS connection via RJ45 socket C-BUS connection via 4-pin, plug-in screw terminal:...
