Spitzer LIGHTING WRAPAROUND Series Installation Manual

WRAPAROUND SERIES
WRAPAROUND LUMINAIRE

PRODUCT PARAMETER

INPUT VOLTAGE 120 - 277V
DRIVER SIMON POWER
MATERIAL STEEL BODY

PRE - INSTALLATION

•Carefully remove the fixture from the carton.
•Before beginning assembly, installation, or operation of product, make sure all parts
are present. Compare parts with package contents list and diagram on previous
page. If any part is missing or damaged, do not attempt to assemble, install or
operate the product. Contact customer service for replacement parts.
• Tools required for assembly (Not Included): screwdriver, phillips screwdriver, pliers,
electrical tape, wire cutters, safety glasses, ladder, wire stripper.
SURFACE MOUNT INSTALLATION (Caution: Before beginning installation turn off the circuit breaker and light switch)
www.spitzerlighting.com
I N S T A L L A T I O N M A N U A L
BE SURE THE POWER IS OFF! RISK OF ELECTRICAL SHOCK: Always use the switch to power off. Do not perform
any operations while this unit is powered on. The electrical system you want to connect the device to must be
grounded. Read the instructions before using or powering this device. The safety instructions must remain with
the unit in case of transfer. Any damage to the device linked to an inappropriate use is excluded from support by
the warranty. Before connecting, make sure that the current and voltage are compatible with this device. We highly
recommend that all installations are made by QUALIFIED ELECTRICIAN. We are NOT responsible by any means for
the use or misuse of the following information. We are NOT responsible in whole or part for any harm or damage
that may or may not be caused. We reserve the right to revise the components of any product, due to part availability
or change ETL, CUL, UL standards without assuming any obligation or liability to modify any products previously
manufactured and without notice. These instructions do not cover all details of variations in equipment, nor do they
provide every possible contingency to be met. Turn off / unplug power when installing or service device.
WARNING: Read all safety precautions and installation instructions carefully before installing or servicing this
fixture. Failure to comply with these instructions could result in a potentially fatal electric shock, fire, and/or
property damage.
• To reduce the risk of death, personal injury or property damage from fire, electric shock, falling parts, cuts/
abrasions, and other hazards read all warnings and instructions included with and on the fixture box and all fixture
labels
• Before installing, servicing, or performing routine maintenance upon this equipment, follow these general
precautions
• Commercial Installation, service and maintenance of luminaires should be performed by a qualified licensed
electrician
• For the installation: If you are unsure about the installation or maintenance of the luminaires, consult a qualified
licensed electrician and check your local electrical code
• To prevent wiring damage or abrasion, do not expose wiring to edges of sheet metal or other sharp objects
• Do not make or alter any open holes in an enclosure of wiring or electrical components during the kit installation
• Turn off electrical power at fuse or circuit breaker before wiring fixture to the power supply
• Verify that supply voltage is correct by comparing it with the luminaire label information
WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance
could void the user authority to operate the equipment.
NOTES: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
702 Interchange Blvd., Newark, DE 19711

SAFETY INFORMATION

WARNING
FCC WARNING
1. Remove the product from the packaging.
2. Remove the lens by pulling from one side of the fixture and hinge
on the other
3. For mounting, using the provided mounting holes on each end of
the fixture housing.
4. Follow electrical codes when establishing connections.
5. Install the channel cover.
6. Install lens on one side of the fixture and rotate to engage the
opposite side.
Specification is subject to change without notice
1/2
