- Page 2 Operating instructions The STABILA REC-120 Line is a simple-to-use receiver for the rapid capture of laser lines. The STABILA REC-120 Line can only receive pulse modulated laser beams. The receiver will not work with rotation lasers. We have endeavoured to explain the unit's handling and functioning in as clear and comprehensible manner as possible.
- Page 3 Getting started Press the ON/OFF button (1). An audio signal and a short flash from the display will confirm, that the instrument is switched on. Press the ON/OFF button (1) quickly once to switch the instrument off. If the instrument is not used, it will automatically switch itself off after 30 minutes.
- Page 4 Measuring modes Construction mode The construction mode is active each time the instrument is switched on. Construction mode display The icons appear permanently Super-fine Fine Medium Wide Construction mode accuracy ± 0,50 mm ± 1,0 mm ± 2,0 mm ± 3,0 mm Industrial mode The more sensitive industrial mode has a Exact centre display...
- Page 5 Replacing the batteries Anzeige Full: Half: Empty: Flashing: Batteries Initial Approximately Change Warning 30 Minutes Batteries! Remaining Slide the battery cover (8) in the direction of the arrow and insert new batteries in accordance with the symbols in the battery compartment.
- Page 6 If working at distances of less than 3 m from the receiver, always use the “close-up” mode. Recycling programme for our EU customers: In accordance with the WEEE regulations, STABILA provides a disposal programme for electronic products at the end of their service life. For more details, please contact: www.STABILA.de / Recycling...
- Page 7 Stabila provides a guarantee against deficiencies and faults in the assured characte- ristics because of material or manufacturing faults for a period of 24 months from date of purchase. Any faults will be eliminated at Stabila's own discretion either by repairing or replacing the unit. Stabila accepts no wider claims.
