Klein Tools 29610 Instructions

ENGLISH
• 29610 PowerHub 1
• Instruction Sheet
• Hang Tag

GENERAL SPECIFICATIONS

• AC Input: NEMA 5-15P, Nominal 120V AC, 15A, 60Hz. Use with 15A rated, 5-25'
(1.5-7.6 m) long cord
• Maximum Total Power Output: 1875W
• AC Output: 6 × NEMA 5-15R, Nominal 120V AC, 15A, 60Hz, Max. output 1875W
• Surge Protection: 2160 Joules
• GFCI Type: Auto monitor. Auto reset, trip time 0.025 seconds (nominal)
• Overcurrent Protection: 15A
• USB Output (Total Wattage): 42W
• USB-A: 1× 12W (5V DC, 2.4A) or 2 × 6W (5V DC, 1.2A)
• USB-C: 2× 15W max (5V DC, 3.0A max)
• LED Work Light Output: 5,000 Lumens
• Rotational Range of Work Light: +75°, -15° from horizontal
• Operating Temperature: 14°F to 122°F (-10°C to 50°C)
• Storage Temperature: -4°F to 158°F (-20°C to 70°C)
• Operating / Storage Maximum Altitude: 2,000 m (6,562')
• Operating / Storage Maximum Humidity: 85% non-condensing
• Dimensions: 14" × 14" × 25" (35.6 cm × 35.6 cm × 63.5 cm)
• Weight: 15.1 lb (6.9kg)
• Device Shelf Max Capacity: 5 lbs (2.3kg)
• Drop Protection: 3.3' (1m)
• Standards: CONFORMS TO UL STD, 1363, 1449, 153,
CERTIFIED TO CSA STD, C22.2#308:2018, C22.2#269.3:2017,
C22.2#250.4:2020
Read, understand, and follow these instructions to ensure safe
operation and service of the PowerHub 1.
Failure to observe these warnings can result in fire, electric shock,
property damage, serious injury and/or death.
• TO REDUCE THE RISK OF ELECTRIC SHOCK, USE ONLY INDOORS. DO
NOT EXPOSE TO RAIN OR SNOW.
• RISK OF ELECTRIC SHOCK. DO NOT PLUG INTO ANOTHER
RELOCATABLE POWER TAP. PLUG INTO ONLY ONE 15A RATED
EXETNSION CORD, 5-25' (1.5-7.6m) IN LENGTH
• DO NOT exceed maximum power rating of device (1875W).
• DO NOT use the product if damaged or modified.
• DO NOT connect to an ungrounded outlet.
• DO NOT use with extension cord adapters that eliminate the
connection to ground.
• DO NOT use near flammable liquids or gases.
• Avoid touching or placing any objects on hot surfaces near LED work
light or its housing.
• DO NOT attempt to insert other USB connector types into the USB-C
or USB-A ports.
• DO NOT look directly into the LED work light.
• Keep away from high voltage devices.
• CAUTION - DO NOT install this device if there is not at least 10
meters (33') or more of wire between the electrical outlet and the
electrical service panel.
• This device features an internal protection that will disconnect the
surge protective component at the end of its useful life, but will
maintain power to the load – now unprotected.
Find Quality Products Online at:
CONTENTS

WARNINGS

GlobalTestSupply
www.
PowerHub 1 - Instructions
PowerHub 1 - Instrucciones
PowerHub 1 – Instructions
3
5
8
10

MAINTENANCE

CLEANING: Be sure device is disconnected from all power sources and
devices. Use clean, dry, soft, lint-free cloth to wipe down the entire unit.
Do not use abrasive cleaners or solvents.
STORAGE: Store at temperatures between -4°F and 158°F (-20°C and
70°C), less than 85% relative humidity, and away from direct sunlight
(See GENERAL SPECIFICATIONS). Leaving in a vehicle or other confined
spaces in extreme hot temperatures can lead to decrease in service
life, overheating, or fire. Extreme cold temperatures below the specified
storage range can also harm performance and service life. Keep away
from corrosive chemicals and gases. After taking out of storage, inspect
visually to make sure device and all accessories look satisfactory. Allow
unit to return to ambient conditions before using.

DISPOSAL / RECYCLE

Do not place equipment and its accessories in the trash or in
curbside recycle bin. Items must be properly recycled of in
accordance with local regulations. Please see
for additional information.
Operating Instructions
PLEASE SEE REVERSE SIDE.
.com
29610
FRONT / FRENTE / AVANT
FIG. A
4
3
11
12
13
2
6
7
9

SYMBOLS ON PRODUCT

Warning or Caution
13
Risk of Electrical Shock
Read Instructions
Level VI Efficiency Standard

FEATURE DETAILS (FIG.A)

1. Work Light
2. Work Light ON/OFF Button
3. Work Light Tightening Knob
4. Top Grab Handle
5. Side Grab Handle (×2)
6. Integrated Cord Wrap (×2)
7. Extension Cord Plug Hook (×2)
8. AC Outlet (×6)
9. USB Ports
10. AC Input
11. GFCI Test/Reset Button
12. GFCI Indicator LED
NOTE: GFCI Indicator LED will illuminate
RED to indicate power is on.
13. Device Shelves (×3)
14. 120V Outlet ON/OFF Switch
15. Surge Protected LED Status Indicator
16. Grounded Input LED Indicator
sales@GlobalTestSupply.com
1
14
8
16
15
