Summary of Contents for Dectris EIGER 2 XE CdTe 16M
- Page 1 Technical Specifications ® DECTRIS EIGER 2 XE CdTe 16M Document Version v1.8.1 DECTRIS Ltd. 5405 Baden-Daettwil Switzerland www.dectris.com...
- Page 2 Document Version v1.8.1 © Copyright 2023 DECTRIS Ltd.
-
Page 3: Table Of Contents
Mounting the Detector Control Unit ........22 TEMPERATURE AND HUMIDITY CONTROL ® DECTRIS EIGER 2 XE CdTe 16M Technical Specifications v1.8.1... - Page 4 Cleaning and Maintenance ......... . 25 SAFETY INSTRUCTIONS FOR CDTE SENSORS TROUBLESHOOTING ® DECTRIS EIGER 2 XE CdTe 16M Technical Specifications v1.8.1 ii | 29...
-
Page 5: Document History
Fixed EIGER2 vacuum operation and updated trademarks. v1.8.0 2022-03-22 Documenting new features from release 2022.1 v1.8.1 2023-02-10 Updated frame rates and 8 bit mode for X and XE systems. ® DECTRIS EIGER 2 XE CdTe 16M Technical Specifications v1.8.1 iii | 29... -
Page 6: General Information
1. GENERAL INFORMATION 1.1. Contact and Support Address: DECTRIS Ltd. Taefernweg 1 5405 Baden-Daettwil Switzerland Phone: +41 56 500 21 02 Fax: +41 56 500 21 01 Homepage: http://www.dectris.com/ Email: support@dectris.com Should you have questions concerning the system or its use, please contact us via telephone, mail or fax. -
Page 7: Warranty Information
(in particular information, images or ® materials), unless otherwise indicated. Without the written permission of DECTRIS it is prohibited to integrate the protected contents in this publication into other programs or other websites or to use them by any other means. -
Page 8: Use Of The Eiger2 Xe Cdte 16M
® We recycle DECTRIS detector systems that are no longer suitable for use. If you are not using your DECTRIS detector system any more, send it back to us. We will make sure that your system is responsibly and safely recycled. This is free for ®... -
Page 9: Technical Specifications
HTTP REST interface (via network connection) Dimensions (W x H x D) 400 mm x 430 mm x 500 mm Weight 53 kg Single threshold. Using two thresholds halves the frame rate. ® DECTRIS EIGER 2 XE CdTe 16M Technical Specifications v1.8.1 4 | 29... -
Page 10: Ratings
External trigger input impedance 47 kΩ High level: 2.3 V to 3.3 V Detector trigger output Low level: 0.0 V to 0.6 V Max. current: 24 mA ® DECTRIS EIGER 2 XE CdTe 16M Technical Specifications v1.8.1 5 | 29... -
Page 11: Detector Control Unit
3.2.4. Thermal Stabilization Unit Information Please consult the user documentation of the SMC HRS-012A thermal stabilization unit for details. Caution The maximum allowable coolant pressure is 3 bar. ® DECTRIS EIGER 2 XE CdTe 16M Technical Specifications v1.8.1 6 | 29... -
Page 12: Ambient Conditions
• Make sure the temperature and the humidity inside the transport box does not exceed the specified range (use of a drying agent is required). • Ensure that no condensation moisture develops if the detector is stored at low temperature. ® DECTRIS EIGER 2 XE CdTe 16M Technical Specifications v1.8.1 7 | 29... -
Page 13: Detector Dimensions And Connectors
Information ® 3D step files of the EIGER2 XE CdTe 16M detector are available on request. Please contact DECTRIS technical support for more information. Figure 4.1: Drawing of the EIGER2 XE CdTe 16M Detector (also printed separately in the user documentation folder) ®... -
Page 14: Front Side Of The Detector
Figure 4.2: The EIGER2 XE CdTe 16M Detector with the Cover Removed (front view) ® DECTRIS EIGER 2 XE CdTe 16M Technical Specifications v1.8.1 9 | 29... -
Page 15: Back Side Of The Detector
4.1.3. Back Side of the Detector Figure 4.3: The EIGER2 XE CdTe 16M Detector (back view) ® DECTRIS EIGER 2 XE CdTe 16M Technical Specifications v1.8.1 10 | 29... -
Page 16: Status Leds
Do not replace the optical transceivers, as proper function of the detector system cannot be guaranteed otherwise. Please contact support@dectris.com if you need replacement transceivers. POWER AC power connector (see table 3.2) EXT IN External trigger input (see table 3.2) ®... -
Page 17: Detector Control Unit
Using the web front end, it is possible to restart the EIGER2 control service, trigger an update, and to shut down and to reboot the detector control unit. Any further control of the detector is carried out via the SIMPLON API (see separate documentation). ® DECTRIS EIGER 2 XE CdTe 16M Technical Specifications v1.8.1 12 | 29... - Page 18 Briefly pushing the power button on the front panel will shut down the detector control unit. May take up to 1 min. Figure 4.5: Back view of detector control unit with labeled network interfaces. ® DECTRIS EIGER 2 XE CdTe 16M Technical Specifications v1.8.1 13 | 29...
-
Page 19: Connectors
4 x 30 m fiber optics cables. There is no particular order to be maintained for the connections to the switch. ® DECTRIS EIGER 2 XE CdTe 16M Technical Specifications v1.8.1 14 | 29... - Page 20 Connection to detector DATA ports 1-16 (the order of the con- nections does not matter) Slots 19 & 20 Connection to DCU as indicated in figure 4.4 Figure 4.7: Connection schematics. ® DECTRIS EIGER 2 XE CdTe 16M Technical Specifications v1.8.1 15 | 29...
-
Page 21: Thermal Stabilization Unit
Use opaque hoses to avoid the growth of algae. Caution Do not set the temperature of the thermal stabilization unit below the recommended operating temperature. Condensing moisture can develop and damage the detector. ® DECTRIS EIGER 2 XE CdTe 16M Technical Specifications v1.8.1 16 | 29... -
Page 22: Installing The Detector System
It is strictly forbidden to add any threads to the detector base plate or to the detector housing. The detector should be mounted using the four internal M6x1 threads as shown in figure 5.1 (indicated with yellow circles). ® DECTRIS EIGER 2 XE CdTe 16M Technical Specifications v1.8.1... -
Page 23: Mounting From Above
Caution Make sure the mounting brackets are mounted and properly tightened using the screws provided. The placement of the screws is indicated with diamonds in figure 5.2. ® DECTRIS EIGER 2 XE CdTe 16M Technical Specifications v1.8.1 18 | 29... -
Page 24: Grounding Of The Detector
The EIGER2 XE CdTe 16M detector has to be connected to a dry air (or nitrogen) source to avoid humidity and condensation damage when it is outside of the storage box. For information on system connections, refer to the section 4.1.5 and for ® DECTRIS EIGER 2 XE CdTe 16M Technical Specifications v1.8.1... -
Page 25: Fiber Optic Cable Installation
. Detectors used in vacuum need different optical cables. For information about vacuum cables, refer to the vacuum ® feedthrough set specifications or contact DECTRIS support. 5.5.1. Installing the Cables The fiber optic cables come with a pulling eye to make cable installation easier and a cable sock to protect the connectors. -
Page 26: Checking The Connection
Do not add any component other than those supplied by DECTRIS to the cooling circuit. Using the wrong material in the ® cooling circuit leads to galvanic corrosion, which can permanently damage the detector. Contact DECTRIS support at support@dectris.com in case the supplied components are not compatible with your setup. -
Page 27: Mounting The Detector Control Unit
The mains plug of the detector control unit has to be connected to a grounded power outlet. The detector control unit can be mounted in a standard 19 inch rack, which has to be properly grounded. ® DECTRIS EIGER 2 XE CdTe 16M Technical Specifications v1.8.1... -
Page 28: Temperature And Humidity Control
5.4. Then restart the software. Information A free-flowing air stream is mandatory in order to properly cool the electronics inside the detector. Do not cover any ventilation holes. ® DECTRIS EIGER 2 XE CdTe 16M Technical Specifications v1.8.1 23 | 29... -
Page 29: Operation Procedure
• Do not remove the nitrogen/dry air connection. It is a requirement that it is left at the recommended flow rate according to section 5.4. Warning As long as the detector power cable is connected, the detector has to be considered under power. ® DECTRIS EIGER 2 XE CdTe 16M Technical Specifications v1.8.1 24 | 29... -
Page 30: Storing The Detector
® ® The Mylar foil must not be touched or cleaned. If it is damaged, please contact DECTRIS technical support. The detector housing can be cleaned with a soft tissue. The EIGER2 XE CdTe 16M detector does not require any mainte- nance. -
Page 31: Safety Instructions For Cdte Sensors
• Do not inhale Cadmium Telluride (CdTe) dust when sensor is broken or burnt. • Do not ingest Cadmium Telluride (CdTe). • Avoid skin contact. For recycling, see section 2.1. ® DECTRIS EIGER 2 XE CdTe 16M Technical Specifications v1.8.1 26 | 29... -
Page 32: Troubleshooting
Table 9.1 provides an overview of possible problems with the detector system and instructions in order to solve the problems. If the problem you are experiencing is not listed below or if the instructions do not help, please contact support@dectris.com. - Page 33 Ambient humidity around the detector Shut down the detector immediately exceeds the operating conditions. and check the humidity. Power up the detector only when the ambient hu- midity has been reduced. ® DECTRIS EIGER 2 XE CdTe 16M Technical Specifications v1.8.1 28 | 29...
- Page 34 ”DECTRIS INSTANT RETRIGGER”, ”DECTRIS MYTHEN”, ”DECTRIS PILATUS”, ”DECTRIS QUADRO”, ”DECTRIS SANTIS”, ”DECTRIS SÄNTIS”, ”DECTRIS SINGLA”, ”DECTRIS TITLIS”, ”DETECTING THE FUTURE” © 2/ 2023 DECTRIS Ltd., all rights reserved • Subject to technical modifications. ® DECTRIS EIGER 2 XE CdTe 16M Technical Specifications v1.8.1...
