Installation - Huawei SCharger-7KS-S0 User Manual

Installation Precautions
Before installation, carefully read the
precautions in this manual and prepare for the

installation.

Only professionals with local qualifications are
allowed to disassemble and install chargers.
Ensure that all installation operations are performed
correctly to avoid accidents such as fire and electric
shock.
Ensure that the installation surface is solid enough
to hold the charger. It is recommended that the wall
have a bearing capacity of at least 100 kg.
Ensure that the wall is flat and reserve sufficient
space around the installation position to ensure
good ventilation.
Ensure that the wall is larger than the rear cover of
the charger.
When installing the product, install the ground cable
first. When uninstalling the product, remove the
ground cable last. Do not work on the product in the
absence of a properly installed ground cable.
Do not install or remove power cables with power on.
Before switching on the upstream RCBO, ensure that
cables are correctly connected to the charger.
After the upstream RCBO is switched on, do not
touch the terminals on the rear cover directly or with
conductors.
Use cables that comply with local regulations and
ensure that the insulation layer is intact.
When installing the product, use a screwdriver with
a proper torque to tighten the screws. When using a
screwdriver, ensure that the screwdriver does not tilt
and the torque error does not exceed 10% of the
specified value.
When routing power cables, ensure that there is no
coiling or twisting.
Keep cables at least 30 mm away from
heat-generating components or heat source areas.
Do not join or weld power cables. If necessary, use a
longer cable.
Seal unused power cable holes with rubber plugs
after the installation is complete.
In case of short-circuit, the value of I²t at the EV
socket-outlet of the charging station shall not
exceed 75000 A2s.
Scan the QR code to get the installation video.
