Technical Specifications - Huawei SCharger-7KS-S0 User Manual

Technical Specifications
Operating voltage range
Frequency
Supported earthing system
Rated output power
(current)
Operating temperature*
(without direct sunlight)
Weight
Dimensions (H x W x D)
Network type
Bluetooth
Ethernet port
RFID
Transportation and
storage temperature
Relative humidity
Altitude*
IP rating
Standard compliance
*When the altitude ranges from 2000 m to 4000 m, the output power of the charger is derated.
*SCharger-7KS-S0: When the operating temperature ranges from 45°C to 55°C, the output power of the charger is derated.
*SCharger-22KT-S0 (Mode A): When the operating temperature ranges from 40°C to 55°C, the output power of the charger is derated.
*SCharger-22KT-S0 (Mode B): When the operating temperature ranges from 50°C to 55°C, the output power of the charger is derated.
*SCharger-22KT-S0 (Mode C): When the operating temperature ranges from 45°C to 55°C, the output power of the charger is derated.
180 mm
Mode A
Three-phase 400/230 V AC
(±20%)
50/60 Hz±1 Hz
Three-phase five-wire; TN, TT
Three-phase: 22 kW (32 A),
–35°C to +40°C
About 3.1 kg
335 mm x 180 mm x 145 mm
WiFi 2.4 GHz
BLE 5.0
FE 100 Mbit/s
IEC 14443 Type A
–40°C to +70°C
5%–95% RH (non-condensing)
0–2000 m
IP54
EN 61851-1 2019, IEC 62955 2018, IEC 61008-1 2010, IEC/EN 62196-1
145 mm
SCharger-22KT-S0
Mode B
Three-phase 400/230 V AC
(±20%)
50/60 Hz±1 Hz
Three-phase five-wire; TN, TT
Three-phase: 11 kW (16 A),
–35°C to +50°C
5
335 mm
SCharger-7KS-S0
Mode C
Single-phase 230 V AC (±20%)
50/60 Hz±1 Hz
Single-phase, three-wire; TN, TT, IT
Single-phase: 7.4 kW (32 A)
–35°C to +45°C
About 3.0 kg
