To Set Up
cont.
Installing Grate Supports
Slide 4 GRATE SUPPORTS into
channels on base. Push down
firmly.
Installing Control Knob
Push KNOB onto regulator as
shown.
6
Turn KNOB to off position.
Installing Windscreen
Align notch on WINDSCREEN
with channel on base. Push down
to secure.
Installing Water Pan, Grilling
Surface and Warming Rack
Position WATER PAN on grate
supports as shown.
Fill to line indicated on WATER
PAN
Place GRILLING SURFACE over
water pan as shown.
A
Position WARMING RACK into
holes on windscreen.
Be sure hooks on WARMING
RACK are facing upward.
